S1A - S1M
Taiwan Semiconductor
CREAT BY ART
1A, 50V - 1000V Surface Mount Rectifiers
FEATURES
- Glass passivated chip junction
- Ideal for automated placement
- Low forward voltage drop
- High surge current capability
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21 definition
MECHANICAL DATA
Case:
DO-214AC (SMA)
Molding compound, UL flammability classification rating 94V-0
Moisture sensitivity level: level 1, per J-STD-020
Part no. with suffix "H" means AEC-Q101 qualified
Packing code with suffix "G" means green compound (halogen-free)
Terminal:
Matte tin plated leads, solderable per JESD22-B102
Meet JESD 201 class 2 whisker test
Polarity:
Indicated by cathode band
Weight:
0.06 g (approximately)
DO-214AC (SMA)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25°C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak forward surge current, 8.3 ms single half sine-wave
superimposed on rated load
Maximum instantaneous forward voltage (Note 1)
@1A
Maximum reverse current @ rated V
R
Typical reverse recovery time (Note 2)
Typical junction capacitance (Note 3)
Non-repetitive peak reverse avalanche
energy at 25°C, I
AS
=1A, L=10mH
Typical thermal resistance
Operating junction temperature range
Storage temperature range
Note 1: Pulse test with PW=300μs, 1% duty cycle
Note 2: Reverse Recovery Test Conditions: I
F
=0.5A, I
R
=1.0A, I
RR
=0.25A
Note 3: Measured at 1 MHz and Applied Reverse Voltage of 4.0V D.C.
T
J
=25°C
T
J
=125°C
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
t
rr
C
J
E
RSM
R
θJL
R
θJA
T
J
T
STG
27
75
- 55 to +175
- 55 to +175
40
1.1
1
50
1.5
12
5
30
85
S1A
50
35
50
S1B
100
70
100
S1D
200
140
200
S1G
400
280
400
1
30
S1J
600
420
600
S1K S1M
800
560
800
1000
700
1000
UNIT
V
V
V
A
A
V
μA
μs
pF
mJ
°C/W
°C
°C
Document Number: DS_D1411068
Version: R15
S1A - S1M
Taiwan Semiconductor
ORDERING INFORMATION
PART NO.
PART NO.
SUFFIX
R3
R2
M2
S1x
(Note 1)
H
F3
F2
F4
E3
E2
Note 1: "x" defines voltage from 50V (S1A) to 1000V (S1M)
G
PACKING CODE
PACKING CODE
SUFFIX
SMA
SMA
SMA
Folded SMA
Folded SMA
Folded SMA
Clip SMA
Clip SMA
1,800 / 7" Plastic reel
7,500 / 13" Paper reel
7,500 / 13" Plastic reel
1,800 / 7" Plastic reel
7,500 / 13" Paper reel
7,500 / 13" Plastic reel
1,800 / 7" Plastic reel
7,500 / 13" Plastic reel
PACKAGE
PACKING
EXAMPLE
PREFERRED
PART NO.
S1MHR3G
PART NO.
S1M
PART NO.
SUFFIX
H
PACKING CODE
R3
PACKING CODE
SUFFIX
G
DESCRIPTION
AEC-Q101 qualified
Green compound
RATINGS AND CHARACTERISTICS CURVES
(T
A
=25°C unless otherwise noted)
FIG.1 FORWARD CURRENT DERATING CURVE
1.2
1
0.8
0.6
0.4
0.2
0
0
25
50
75
100
125
(
°
C)
RESISTIVE OR
INDUCTIVE LOAD
INSTANTANEOUS REVERSE CURRENT
(μA)
AVERAGE FORWARD CURRENT (A)
100
FIG. 2 TYPICAL REVERSE CHARACTERISTICS
10
T
J
=125°C
1
0.1
T
J
=75°C
T
J
=25°C
0.01
150
175
0.001
0
20
40
60
80
100
120
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
140
LEAD TEMPERATURE
PEAK FORWARD SURGE URRENT(A)
8.3ms Single Half Sine Wave
INSTANTANEOUS FORWARD CURRENT
(A)
100
FIG. 3 MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
100
FIG. 4 TYPICAL FORWARD CHARACTERISTICS
10
S1A-S1K
10
S1M
1
Pulse Width=300μs
1% Duty Cycle
0.1
0.4
0.6
0.8
1
1.2
1.4
FORWARD VOLTAGE (V)
1.6
1.8
2
1
1
10
NUMBER OF CYCLES AT 60 Hz
100
Document Number: DS_D1411068
Version: R15
S1A - S1M
Taiwan Semiconductor
CREAT BY ART
