ICL7135CQI datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > converter> ICL7135CQI

ICL7135CQI: Description1-CH 4-BIT DUAL-SLOPE ADC, PARALLEL ACCESS, PQCC28, PLASTIC, LCC-28; Categoryconverter; File Size7MB，15 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

ICL7135CQI Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ICL7135CQI	-	-	View	Buy Now

ICL7135CQI Overview

1-CH 4-BIT DUAL-SLOPE ADC, PARALLEL ACCESS, PQCC28, PLASTIC, LCC-28

ICL7135CQI Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	QLCC
package instruction	QCCJ,
Contacts	28
Reach Compliance Code	unknown
Is Samacsys	N
Maximum analog input voltage	2 V
Minimum analog input voltage	-2 V
Converter type	ADC, DUAL-SLOPE
JESD-30 code	S-PQCC-J28
JESD-609 code	e0
length	11.505 mm
Humidity sensitivity level	1
Nominal negative supply voltage	-5 V
Number of analog input channels	1
Number of digits	4
Number of functions	1
Number of terminals	28
Maximum operating temperature	70 °C
Minimum operating temperature
Output bit code	BINARY, BINARY CODED DECIMAL
Output format	PARALLEL, 4 BITS
Package body material	PLASTIC/EPOXY
encapsulated code	QCCJ
Package shape	SQUARE
Package form	CHIP CARRIER
Peak Reflow Temperature (Celsius)	240
Maximum seat height	4.57 mm
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	TIN LEAD
Terminal form	J BEND
Terminal pitch	1.27 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	20
width	11.505 mm
Base Number Matches	1
