74VHC32 — Quad 2-Input OR Gate
February 2008
74VHC32
Quad 2-Input OR Gate
Features
■
High Speed: t
PD
=
3.8ns (typ.) at V
CC
=
5V
■
Low Power Dissipation: I
CC
=
2 µA (max.) at T
A
=
25°C
■
High Noise Immunity: V
NIH
=
V
NIL
=
28% V
CC
(min.)
■
Power down protection is provided on all inputs
■
Low Noise: V
OLP
=
0.8V (max.)
■
Pin and Function Compatible with 74HC32
General Description
The VHC32 is an advanced high speed CMOS 2-Input
OR Gate fabricated with silicon gate CMOS technology.
It achieves the high speed operation similar to equivalent
Bipolar Schottky TTL while maintaining the CMOS low
power dissipation.
The internal circuit is composed of 4 stages including
buffer output, which provide high noise immunity and
stable output. An input protection circuit ensures that 0V
to 7V can be applied to the input pins without regard to
the supply voltage. This device can be used to interface
5V to 3V systems and two supply systems such as bat-
tery back up. This circuit prevents device destruction due
to mismatched supply and input voltages.
Ordering Information
Order Number
74VHC32M
74VHC32SJ
74VHC32MTC
74VHC32N
Package
Number
M14A
M14D
MTC14
N14A
Package Description
14-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-012, 0.150"
Narrow
14-Lead Small Outline Package (SOP), EIAJ TYPE II, 5.3mm Wide
14-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153,
