Part Number

Search

891626 RD013

Description
HOOK-UP STRND 16AWG RED 5000'
CategoryWire/cable
File Size100KB,3 Pages
ManufacturerAlpha Wire
Websitehttp://www.alphawire.com/zh-CN/
Environmental Compliance
Download Datasheet Parametric View All

891626 RD013 Overview

HOOK-UP STRND 16AWG RED 5000'

891626 RD013 Parametric

Parameter NameAttribute value
Cable typeelectronic wire
Wire gauge16 AWG
Number of wire strands26/30
conductor materialCopper, tin plated
Sheath (insulation) materialPolyvinyl chloride (PVC)
Sheath (insulation) diameter0.092"(2.34mm)
Sheath (insulation) thickness0.016"(0.41mm)
length5000'(1524.0m)
Voltage300V
Operating temperature-20°C ~ 105°C
Casing colorred
gradeUL type 1007/1569
characteristic-
Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207
Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com
Customer Specification
PART NO. 891626
Construction
Diameters (In)
1) Component 1
a) Conductor
b) Insulation
1 X 1 HOOKUP
16 (26/30) AWG TC
0.016" Wall, Nom. PVC
0.092+/- 0.002
(1) Print
16 AWG EXXXXX RU AWM STYLE 1569 105C 300V VW-1 OR
AWM 1007 LLXXXXX CSA AWM I A/B 105C 300V FT1
OR TR64 90C
[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]
WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN
ORANGE, SLATE, VIOLET
(2) Color(s)
Applicable Specifications
1) UL
AWM/STYLE 1569
VW-1
AWM/STYLE 1007
2) CSA International
AWM I A/B
FT1
TR-64
90C°C
80C°C / 300 VRMS
105°C / 300 VRMS
105°C / 300 VRMS
Environmental
1) EU Directive 2002/95/EC(RoHS):
All materials used in the manufacture of this part are in compliance with EU Directive
2002/95/EU regarding the restriction of use of certain hazardous substances in electrical and
electronic equipment. Consult Alpha Wire's web site for compliance Date of Manufacture.
2) California Proposition 65:
The outer surface materials used in the manufacture of this part meet the requirements of
California Proposition 65.
Properties
Physical &Mechanical Properties
1) Temperature Range
2) Bend Radius
3) Pull Tension
Electrical Properties
1) Voltage Rating
2) Inductance
3) Conductor DCR
-20 to 105°C
10X Cable Diameter
20.4 Lbs, Maximum
(For Engineering purposes only)
300 VRMS
0.04 µH/ft, Nominal
4.4 /1000ft @20°C, Nominal
Other
