E & E Magnetic Products Limited
SHIELDED SURFACE MOUNT
POWER INDUCTOR
Drum Type, SIS6060 Series
Magnetically Shielded
Miniature in size and high energy storage
Ideal for high current requirements of notebook,
video recorders and other DC-DC conversion
applications
Custom inductance value or tolerance is available
E
LECTRICAL
S
PECIFICATION
@ 25
o
C
Part
Number
SIS6060-2R2MF
SIS6060-3R3MF
SIS6060-4R7MF
SIS6060-5R6MF
SIS6060-6R8MF
SIS6060-8R2MF
SIS6060-100MF
SIS6060-120MF
SIS6060-150MF
SIS6060-180MF
SIS6060-220MF
SIS6060-270MF
SIS6060-330MF
SIS6060-390MF
SIS6060-470MF
SIS6060-560MF
SIS6060-680MF
SIS6060-820MF
SIS6060-101MF
SIS6060-121MF
SIS6060-151MF
SIS6060-181MF
SIS6060-221MF
SIS6060-271MF
SIS6060-331MF
SIS6060-391MF
Inductance
(uH±20%)
2.2
3.3
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
1
Isat (A)
DCR
(
Ω
Max)
0.023
0.032
0.045
0.055
0.060
0.075
0.083
0.100
0.115
0.150
0.160
0.190
0.216
0.290
0.320
0.365
0.480
0.520
0.700
0.800
1.10
1.20
1.40
1.80
2.10
2.20
SRF
(MHz Typ)
65
60
48
44
42
40
38
35
32
26
22
19
18
17
16
15
12.5
12
11.5
11
10
9
8
7.5
6.8
5.4
10% Typ
drop
1.76
1.33
1.08
1.00
0.98
0.90
0.85
0.72
0.67
0.61
0.54
0.48
0.44
0.42
0.38
0.34
0.31
0.27
0.26
0.23
0.21
0.19
0.18
0.15
0.13
0.12
20% Typ
drop
2.08
1.58
1.32
1.20
1.14
1.04
0.98
0.85
0.78
0.72
0.64
0.56
0.52
0.50
0.46
0.42
0.38
0.32
0.30
0.27
0.26
0.23
0.21
0.18
0.17
0.15
2
Irms (A)
3
30% Typ
drop
2.30
1.73
1.42
1.30
1.24
1.18
1.13
0.94
0.86
0.79
0.70
0.62
0.58
0.55
0.51
0.47
0.42
0.35
0.33
0.30
0.28
0.25
0.23
0.20
0.19
0.16
20 C
o
rise Typ
2.00
1.60
1.40
1.30
1.20
1.10
1.00
0.97
0.94
0.89
0.87
0.85
0.80
0.74
0.71
0.70
0.66
0.62
0.55
0.51
0.47
0.43
0.39
0.35
0.32
0.30
Marking
40
o
C
(XXXYF)
rise Typ
3.30
2.90
2.50
2.30
2.16
2.00
1.90
1.60
1.50
1.40
1.30
1.20
1.10
1.00
0.95
0.90
0.85
0.80
0.69
0.62
0.58
0.54
0.50
0.45
0.42
0.38
2R2MF
3R3MF
4R7MF
5R6MF
6R8MF
8R2MF
100MF
120MF
150MF
180MF
220MF
270MF
330MF
390MF
470MF
560MF
680MF
820MF
101MF
121MF
151MF
181MF
221MF
271MF
331MF
391MF
Notes:
1. Inductance is tested at 100kHz, 0.1Vrms, 0Adc.
2. Saturation current, Isat, is the DC current at which the inductance of the component drops at ambient temperature of 25 C.
3. Heating current, Irms, is the current required to raise the part temperature.
4. Operating temperature range: -40ºC to +125ºC.
Ambient temperature: -40ºC to +85ºC with Irms current, +85ºC to +125ºC with derated current.
5. The part temperature (ambient temperature + temperature rise) should not exceed the upper limit of the
operating temperature under worst case operating conditions. Circuit design, component placement, PWB
trace size and thickness, airflow and other cooling provisions all affect the part temperature. Part
temperature should be verified in the end application.
1/F., Harbour View 1, No.12 Science Park East Avenue, Phase II, Hong Kong Science Park, Shatin, N.T. Hong Kong
Tel: (852) 2954 3333
Fax: (852) 2954 3304
O
1
PI160(01)
Revised in 11/08
E & E Magnetic Products Limited
SHIELDED SURFACE MOUNT
POWER INDUCTOR
Drum Type, SIS6060 Series
S
CHEMATICS
M
ECHANICAL
D
IMENSIONS
M
ECHANICAL
D
IMENSIONS
.248
6.30
8
.201
5.10
XXXYF
(DATE)
.079
.217
Typ
2.00
Typ
5.50
.063
1.60
.248
6.30
.201
5.10
.217
Typ
5.50
.122
Max
3.10
8
Notes:
Recommended
Pad Layout
inches
6. All dimensions are specified in mm with higher precedence in mm.
7. Unless otherwise specified, all tolerances are ± .010 .
0.25
8. Dimensions are of the case not including the termination.
For maximum overall dimensions including the termination, add
.035
.
0.90
Weight (in gram)
Tape & Reel
:
:
1.0 typ.
550 / reel
Irms Derating
120
110
100
90
80
70
60
50
40
30
20
10
0
-40
-20
0
20
40
60
80
o
100
120
140
Ambient temperature ( C)
S
CHEMATICS
FOR MORE INFORMATION, PLEASE CONTACT
HEADQUARTER
1/F., Harbour View 1,
No.12 Science Park East Avenue,
Phase II, Hong Kong Science Park, Shatin, N.T.
Hong Kong
Tel: (852) 2954 3333
Fax: (852) 2954 3304
Email: eempl@eleceltek.com
Website: http://www.eleceltek.com
Information herein is for reference only and subject to change without notice. It does not constitute any representation, warranty or commitment of the company in respect
of the products in any aspect. All logos, brands and product names mentioned herein are trademarks or registered trademarks of their respective owners. The company
does not assume any liability arising out of the application or use of any product or circuit described herein. Copyrights 2008, E & E Magnetic Products Limited.
1/F., Harbour View 1, No.12 Science Park East Avenue, Phase II, Hong Kong Science Park, Shatin, N.T. Hong Kong
Tel: (852) 2954 3333
Fax: (852) 2954 3304
5
PI160(01)
Revised in 11/08
