S70FL01GSAGBHMC13

Description
NOR FlashNor
Categorysemiconductor    Memory IC    NOR flash memory
File Size432KB,20 Pages
ManufacturerCypress Semiconductor
Environmental Compliance
Download Datasheet Parametric Compare View All

S70FL01GSAGBHMC13 Online Shopping

Suppliers Part Number Price MOQ In stock
S70FL01GSAGBHMC13 - - View Buy Now

S70FL01GSAGBHMC13 Overview

NOR FlashNor

S70FL01GSAGBHMC13 Parametric

Parameter NameAttribute value
MakerCypress Semiconductor
Product CategoryNOR flash memory
Shipping restrictionsThis product may require additional documentation for export from the United States.
Installation styleSMD/SMT
Package/boxBGA-24
seriesS70FL01GS
storage1 Gbit
maximum clock frequency133 MHz
Interface TypeSPI
organize128 M x 8
Timing typeSynchronous
Data bus width8 bit
Supply voltage - min.2.7 V
Supply voltage - max.3.6 V
Supply current—max.200 mA
Minimum operating temperature- 40 C
Maximum operating temperature+ 125 C
qualificationsAEC-Q100
EncapsulationReel
storage typeNOR
speed133 MHz
standardCommon Flash Interface (CFI)
Factory packaging quantity2500
S70FL01GS
1 Gbit (128 Mbyte) 3.0V SPI Flash
Features
CMOS 3.0V Core
Serial Peripheral Interface (SPI) with Multi-I/O
– SPI Clock polarity and phase modes 0 and 3
– Double Data Rate (DDR) option
– Extended Addressing: 32-bit address
– Serial Command set and footprint compatible with
S25FL-A, S25FL-K, and S25FL-P SPI families
– Multi I/O Command set and footprint compatible with
S25FL-P SPI family
READ Commands
– Normal, Fast, Dual, Quad, Fast DDR, Dual DDR, Quad
DDR
– AutoBoot – power up or reset and execute a Normal or
Quad read command automatically at a preselected
address
– Common Flash Interface (CFI) data for configuration
information
Programming (1.5 Mbytes/s)
– 512-byte Page Programming buffer
– Quad-Input Page Programming (QPP) for slow clock
systems
Erase (0.5 Mbytes/s)
– Uniform 256-kbyte sectors
Cycling Endurance
– 100,000 Program-Erase Cycles, minimum
Data Retention
– 20 Year Data Retention, minimum
Security Features
One Time Program (OTP) array of 2048 bytes
Block Protection
– Status Register bits to control protection against program
or erase of a contiguous range of sectors.
– Hardware and software control options
– Advanced Sector Protection (ASP)
– Individual sector protection controlled by boot code or
password
Cypress
®
65 nm MirrorBit
®
Technology with Eclipse
Architecture
Core Supply Voltage: 2.7V to 3.6V
I/O Supply Voltage: 1.65V to 3.6V
Temperature Range / Grade:
– Industrial (40 °C to +85 °C)
– Industrial Plus (40 °C to +105 °C)
– Automotive, AEC-Q100 Grade 3 (40 °C to +85 °C)
– Automotive, AEC-Q100 Grade 2 (40 °C to +105 °C)
– Automotive, AEC-Q100 Grade 1 (40 °C to +125 °C)
Packages (all Pb-free)
– 16-lead SOIC (300 mils)
– BGA-24, 8
6 mm
– 5
5 ball (ZSA024) footprint
General Description
This document contains information for the S70FL01GS device, which is a dual die stack of two S25FL512S die. For detailed
specifications, refer to the discrete die datasheet provided in the
Affected Documents/Related Documents
table.
Affected Documents/Related Documents
Document Title
S25FL512S 512 Mbit (64 Mbyte) 3.0V SPI Flash Memory Datasheet
Publication Number
001-98284
Cypress Semiconductor Corporation
Document Number: 001-98295 Rev. *N
198 Champion Court
San Jose
,
CA 95134-1709
408-943-2600
Revised April 03, 2018

S70FL01GSAGBHMC13 Related Products

S70FL01GSAGBHMC13 S70FL01GSDSBHMC13 S70FL01GSAGBHMC10 S70FL01GSDSMFV013 S70FL01GSAGBHVC13 S70FL01GSDSBHBC13 S70FL01GSDSBHBC10 S70FL01GSAGBHVC10
Description NOR FlashNor NOR FlashNor NOR FlashNor NOR Flash IC 1 Gb FLASH MEMORY NOR FlashNor NOR FlashNor NOR FlashNor NOR FlashNor
Maker Cypress Semiconductor Cypress Semiconductor Cypress Semiconductor Cypress Semiconductor Cypress Semiconductor Cypress Semiconductor Cypress Semiconductor Cypress Semiconductor
organize 128 M x 8 128MX8 128 M x 8 128 M x 8 128 M x 8 128 M x 8 128 M x 8 128 M x 8
Minimum operating temperature - 40 C -40 °C - 40 C - 40 C - 40 C - 40 C - 40 C - 40 C
Maximum operating temperature + 125 C 125 °C + 125 C + 105 C + 105 C + 105 C + 105 C + 105 C
Product Category NOR flash memory - NOR flash memory NOR flash memory NOR flash memory NOR flash memory NOR flash memory NOR flash memory
Installation style SMD/SMT - SMD/SMT SMD/SMT SMD/SMT SMD/SMT SMD/SMT SMD/SMT
Package/box BGA-24 - BGA-24 SO-16 BGA-24 BGA-24 BGA-24 BGA-24
series S70FL01GS - S70FL01GS S70FL01GS S70FL01GS S70FL01GS S70FL01GS S70FL01GS
storage 1 Gbit - 1 Gbit 1 Gbit 1 Gbit 1 Gbit 1 Gbit 1 Gbit
maximum clock frequency 133 MHz - 133 MHz 80 MHz 133 MHz 80 MHz 80 MHz 133 MHz
Interface Type SPI - SPI SPI SPI SPI SPI SPI
Timing type Synchronous - Synchronous Synchronous Synchronous Synchronous Synchronous Synchronous
Data bus width 8 bit - 8 bit 8 bit 8 bit 8 bit 8 bit 8 bit
Supply voltage - min. 2.7 V - 2.7 V 2.7 V 2.7 V 2.7 V 2.7 V 2.7 V
Supply voltage - max. 3.6 V - 3.6 V 3.6 V 3.6 V 3.6 V 3.6 V 3.6 V
Supply current—max. 200 mA - 200 mA 200 mA 200 mA 200 mA 200 mA 200 mA
Encapsulation Reel - Tray Reel Reel Reel Tray Tray
speed 133 MHz - 133 MHz 80 MHz 133 MHz 80 MHz 80 MHz 133 MHz
Factory packaging quantity 2500 - 338 1450 2500 2500 338 338
