MC33284P amplifier basic information:
MC33284P is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are PLASTIC, DIP-14
MC33284P amplifier core information:
The MC33284P has a minimum operating temperature of -40 °C and a maximum operating temperature of 85 °C. Its peak reflow temperature is NOT SPECIFIED. Its maximum bias current at 25°C is: 0.0002 µA. Its maximum average bias current is 0.002 µA and its maximum input offset current (IIO) is only 0.001 µA.
How to simply check the efficiency of an amplifier? Looking at its slew rate, the MC33284P has a nominal slew rate of 15 V/us. The manufacturer specifies a maximum slew rate for the MC33284P of 12 mA and a minimum slew rate of 8 V/us. Its minimum voltage gain is 25000. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the MC33284P gain becomes 0.707 times the low-frequency gain is 35000 kHz.
The nominal supply voltage of MC33284P is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of MC33284P is 4000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)
Related dimensions of MC33284P:
The width of MC33284P is: 7.62 mm and the length is 18.86 mm. MC33284P has 14 terminals. Its terminal position type is: DUAL. Terminal pitch is 2.54 mm. Total pins: 14
MC33284P amplifier additional information:
MC33284P adopts the VOLTAGE-FEEDBACK architecture. It belongs to the low-bias class of amplifiers. It does not belong to the low offset class of amplifiers. The frequency compensation status of MC33284P is: YES. Its temperature grade is: INDUSTRIAL.
MC33284P is not Rohs certified. The corresponding JESD-30 code is: R-PDIP-T14. The corresponding JESD-609 code is: e0. The packaging code of MC33284P is: DIP. MC33284P packaging materials are mostly PLASTIC/EPOXY.
The package shape is RECTANGULAR. The MC33284P package pin format is: IN-LINE. Its terminal form is: THROUGH-HOLE. The maximum seat height is 4.69 mm.
MC33284P amplifier basic information:
MC33284P is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are PLASTIC, DIP-14
MC33284P amplifier core information:
The MC33284P has a minimum operating temperature of -40 °C and a maximum operating temperature of 85 °C. Its peak reflow temperature is NOT SPECIFIED. Its maximum bias current at 25°C is: 0.0002 µA. Its maximum average bias current is 0.002 µA and its maximum input offset current (IIO) is only 0.001 µA.
How to simply check the efficiency of an amplifier? Looking at its slew rate, the MC33284P has a nominal slew rate of 15 V/us. The manufacturer specifies a maximum slew rate for the MC33284P of 12 mA and a minimum slew rate of 8 V/us. Its minimum voltage gain is 25000. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the MC33284P gain becomes 0.707 times the low-frequency gain is 35000 kHz.
The nominal supply voltage of MC33284P is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of MC33284P is 4000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)
Related dimensions of MC33284P:
The width of MC33284P is: 7.62 mm and the length is 18.86 mm. MC33284P has 14 terminals. Its terminal position type is: DUAL. Terminal pitch is 2.54 mm. Total pins: 14
MC33284P amplifier additional information:
MC33284P adopts the VOLTAGE-FEEDBACK architecture. It belongs to the low-bias class of amplifiers. It does not belong to the low offset class of amplifiers. The frequency compensation status of MC33284P is: YES. Its temperature grade is: INDUSTRIAL.
MC33284P is not Rohs certified. The corresponding JESD-30 code is: R-PDIP-T14. The corresponding JESD-609 code is: e0. The packaging code of MC33284P is: DIP. MC33284P packaging materials are mostly PLASTIC/EPOXY.
The package shape is RECTANGULAR. The MC33284P package pin format is: IN-LINE. Its terminal form is: THROUGH-HOLE. The maximum seat height is 4.69 mm.
| Parameter Name | Attribute value |
| Is it Rohs certified? | incompatible |
| Parts packaging code | DIP |
| package instruction | PLASTIC, DIP-14 |
| Contacts | 14 |
| Reach Compliance Code | not_compliant |
| ECCN code | EAR99 |
| Is Samacsys | N |
| Amplifier type | OPERATIONAL AMPLIFIER |
| Architecture | VOLTAGE-FEEDBACK |
| Maximum average bias current (IIB) | 0.002 µA |
| Maximum bias current (IIB) at 25C | 0.0002 µA |
| Nominal Common Mode Rejection Ratio | 90 dB |
| frequency compensation | YES |
| Maximum input offset current (IIO) | 0.001 µA |
| Maximum input offset voltage | 4000 µV |
| JESD-30 code | R-PDIP-T14 |
| JESD-609 code | e0 |
| length | 18.86 mm |
| low-bias | YES |
| low-dissonance | NO |
| Negative supply voltage upper limit | -18 V |
| Nominal Negative Supply Voltage (Vsup) | -15 V |
| Number of functions | 4 |
| Number of terminals | 14 |
| Maximum operating temperature | 85 °C |
| Minimum operating temperature | -40 °C |
| Package body material | PLASTIC/EPOXY |
| encapsulated code | DIP |
| Encapsulate equivalent code | DIP14,.3 |
| Package shape | RECTANGULAR |
| Package form | IN-LINE |
| Peak Reflow Temperature (Celsius) | NOT SPECIFIED |
| power supply | +-15 V |
| Certification status | Not Qualified |
| Maximum seat height | 4.69 mm |
| minimum slew rate | 8 V/us |
| Nominal slew rate | 15 V/us |
| Maximum slew rate | 12 mA |
| Supply voltage upper limit | 18 V |
| Nominal supply voltage (Vsup) | 15 V |
| surface mount | NO |
| technology | BIPOLAR |
| Temperature level | INDUSTRIAL |
| Terminal surface | Tin/Lead (Sn/Pb) |
| Terminal form | THROUGH-HOLE |
| Terminal pitch | 2.54 mm |
| Terminal location | DUAL |
| Maximum time at peak reflow temperature | NOT SPECIFIED |
| Nominal Uniform Gain Bandwidth | 35000 kHz |
| Minimum voltage gain | 25000 |
| width | 7.62 mm |
| Base Number Matches | 1 |
| MC33284P | MC33282D | MC33282P | MC33284D | |
|---|---|---|---|---|
| Description | QUAD OP-AMP, 4000uV OFFSET-MAX, 35MHz BAND WIDTH, PDIP14, PLASTIC, DIP-14 | DUAL OP-AMP, 4000uV OFFSET-MAX, 35MHz BAND WIDTH, PDSO8, PLASTIC, SOP-8 | DUAL OP-AMP, 4000uV OFFSET-MAX, 35MHz BAND WIDTH, PDIP8, PLASTIC, DIP-8 | QUAD OP-AMP, 4000uV OFFSET-MAX, 35MHz BAND WIDTH, PDSO14, PLASTIC, SOIC-14 |
| Is it Rohs certified? | incompatible | incompatible | incompatible | incompatible |
| Parts packaging code | DIP | SOIC | DIP | SOIC |
| package instruction | PLASTIC, DIP-14 | PLASTIC, SOP-8 | PLASTIC, DIP-8 | PLASTIC, SOIC-14 |
| Contacts | 14 | 8 | 8 | 14 |
| Reach Compliance Code | not_compliant | not_compliant | not_compliant | not_compliant |
| ECCN code | EAR99 | EAR99 | EAR99 | EAR99 |
| Is Samacsys | N | N | N | N |
| Amplifier type | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER |
| Architecture | VOLTAGE-FEEDBACK | VOLTAGE-FEEDBACK | VOLTAGE-FEEDBACK | VOLTAGE-FEEDBACK |
| Maximum average bias current (IIB) | 0.002 µA | 0.002 µA | 0.002 µA | 0.002 µA |
| Maximum bias current (IIB) at 25C | 0.0002 µA | 0.0002 µA | 0.0002 µA | 0.0002 µA |
| Nominal Common Mode Rejection Ratio | 90 dB | 90 dB | 90 dB | 90 dB |
| frequency compensation | YES | YES | YES | YES |
| Maximum input offset current (IIO) | 0.001 µA | 0.001 µA | 0.001 µA | 0.001 µA |
| Maximum input offset voltage | 4000 µV | 4000 µV | 4000 µV | 4000 µV |
| JESD-30 code | R-PDIP-T14 | R-PDSO-G8 | R-PDIP-T8 | R-PDSO-G14 |
| JESD-609 code | e0 | e0 | e0 | e0 |
| length | 18.86 mm | 4.9 mm | 9.78 mm | 8.65 mm |
| low-bias | YES | YES | YES | YES |
| low-dissonance | NO | NO | NO | NO |
| Negative supply voltage upper limit | -18 V | -18 V | -18 V | -18 V |
| Nominal Negative Supply Voltage (Vsup) | -15 V | -15 V | -15 V | -15 V |
| Number of functions | 4 | 2 | 2 | 4 |
| Number of terminals | 14 | 8 | 8 | 14 |
| Maximum operating temperature | 85 °C | 85 °C | 85 °C | 85 °C |
| Minimum operating temperature | -40 °C | -40 °C | -40 °C | -40 °C |
| Package body material | PLASTIC/EPOXY | PLASTIC/EPOXY | PLASTIC/EPOXY | PLASTIC/EPOXY |
| encapsulated code | DIP | SOP | DIP | SOP |
| Encapsulate equivalent code | DIP14,.3 | SOP8,.25 | DIP8,.3 | SOP14,.25 |
| Package shape | RECTANGULAR | RECTANGULAR | RECTANGULAR | RECTANGULAR |
| Package form | IN-LINE | SMALL OUTLINE | IN-LINE | SMALL OUTLINE |
| Peak Reflow Temperature (Celsius) | NOT SPECIFIED | 235 | NOT SPECIFIED | NOT SPECIFIED |
| power supply | +-15 V | +-15 V | +-15 V | +-15 V |
| Certification status | Not Qualified | Not Qualified | Not Qualified | Not Qualified |
| Maximum seat height | 4.69 mm | 1.75 mm | 4.45 mm | 1.75 mm |
| minimum slew rate | 8 V/us | 8 V/us | 8 V/us | 8 V/us |
| Nominal slew rate | 15 V/us | 15 V/us | 15 V/us | 15 V/us |
| Maximum slew rate | 12 mA | 6 mA | 6 mA | 12 mA |
| Supply voltage upper limit | 18 V | 18 V | 18 V | 18 V |
| Nominal supply voltage (Vsup) | 15 V | 15 V | 15 V | 15 V |
| surface mount | NO | YES | NO | YES |
| technology | BIPOLAR | BIPOLAR | BIPOLAR | BIPOLAR |
| Temperature level | INDUSTRIAL | INDUSTRIAL | INDUSTRIAL | INDUSTRIAL |
| Terminal surface | Tin/Lead (Sn/Pb) | Tin/Lead (Sn/Pb) | Tin/Lead (Sn/Pb) | Tin/Lead (Sn/Pb) |
| Terminal form | THROUGH-HOLE | GULL WING | THROUGH-HOLE | GULL WING |
| Terminal pitch | 2.54 mm | 1.27 mm | 2.54 mm | 1.27 mm |
| Terminal location | DUAL | DUAL | DUAL | DUAL |
| Maximum time at peak reflow temperature | NOT SPECIFIED | 30 | NOT SPECIFIED | NOT SPECIFIED |
| Nominal Uniform Gain Bandwidth | 35000 kHz | 35000 kHz | 35000 kHz | 35000 kHz |
| Minimum voltage gain | 25000 | 25000 | 25000 | 25000 |
| width | 7.62 mm | 3.9 mm | 7.62 mm | 3.9 mm |
| Base Number Matches | 1 | 1 | 1 | 1 |
