PRF02B056-141GG datasheet, PDF

Datasheet> All Categories > The connector> socket> PRF02B056-141GG

PRF02B056-141GG: DescriptionIC Socket, PGA56, 56 Contact(s), ROHS COMPLIANT; CategoryThe connector socket; File Size147KB，1 Pages; ManufacturerAdvanced Interconnections Corp.; Environmental Compliance

Download Datasheet Parametric View All

PRF02B056-141GG Overview

IC Socket, PGA56, 56 Contact(s), ROHS COMPLIANT

PRF02B056-141GG Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
Contact to complete cooperation	GOLD OVER NICKEL
Contact completed and terminated	Gold (Au) - with Nickel (Ni) barrier
Contact material	BERYLLIUM COPPER
Device slot type	IC SOCKET
Type of equipment used	PGA56
JESD-609 code	e4
Number of contacts	56
Base Number Matches	1

Preview

Download Datasheet

View All

Proteksion

Image Sensor Sockets

Table of Models

Description:

Standard Body (PS or PD)

Material: FR-4 Fiberglass Epoxy Board

Index: -40°C to 140°C (-40°F to 284°F)

Description:

Recessed Body (PR or PL)

Material: FR-4 Fiberglass Epoxy Board

Index: -40°C to 140°C (-40°F to 284°F)

Standard Terminals

Type -01

.072 Dia.

(1.83)

.062 Dia.

(1.57)

Additional standard and custom terminals available.

See Terminals section online or consult factory.

Type -217

Type -141

.072 Dia.

(1.83)

.062

(1.57)

PGA Sockets

PC Board

.062

(1.57)

PC Board

Type -346

.072 Dia.

(1.83)

Features:

.370

(9.40)

.100/(2.54mm) Pitch

.145

(3.68)

.165

(4.19)

.150

(3.81)

.165

(4.19)

.150

(3.81)

Hole Depth

.430

(10.92)

.300

(7.62)

.125

(3.18)

.020 Dia.

(.51)

.020 Dia.

(.51)

.125

(3.18)

.024 Dia.

(.61)

.120

(3.05)

.160

(4.06)

.024 Dia.

(.61)

• Protect sensor performance and

eliminate chance for damage by

inserting after reflow soldering

process.

• Low, medium and high insertion

force contacts available.

• Custom designs available

including custom footprints and

molded or Peel-A-Way

insulators.

Type -385

1.78mm and 1.27mm Pitch

.042 Dia.

(1.07)

.080

(2.03)

.105

(2.67)

Type -674

.042 Dia.

(1.07)

.092

(2.33)

.212

(5.38)

Row to Row Spacing

Pitch (Pin to Pin)

Pitch

(Pin to Pin)

Specifications:

Row to Row

Spacing

(see table for

standard sizes)

.110

(2.79)

.015 Dia.

(.38)

Terminals:

Brass - Copper Alloy

(C36000) ASTM-B-16

Contacts:

Beryllium Copper

(C17200) ASTM-B-194

Plating:

G - Gold over Nickel

M - Matte Tin over Nickel

T - Tin/Lead over Nickel

Gold per MIL-G-45204

Matte Tin per ASTM545-97

Tin/Lead per MIL-P-81728

Nickel per QQ-N-290

.095

(2.41)

.018 Dia.

(.46)

Example Part Number: PLF18A056-141TG

How To Order

PS F 04 A 056 - 141 T G

Model Type

RoHS Compliant Insulators:

Contact Plating

RoHS Compliant:

PS - Dual Row Standard

PR - Dual Row Recessed

PD - Quad Row Standard

PL - Quad Row Recessed

Body Type

F - FR-4

Row to Row Spacing Code

See table

G - Gold

T - Tin/Lead

Terminal Plating

RoHS Compliant:

G - Gold

M - Matte Tin

T - Tin/Lead

Terminal Type

See options

Number of Positions

Total number of pins

per socket

Pitch (Pin to Pin)

A = .100/(2.54mm)

B = .070/(1.78mm) [dual row models only]

C = .050/(1.27mm) [dual row models only]

Note: Terminals plated with Matte Tin are available only with Gold plated contacts.

Visit our web site for footprint specific image sensor sockets.

Code

inch

0.300

0.400

0.450

0.600

0.610

0.700

0.800

0.802

0.880

0.900

0.910

1.005

1.010

1.200

1.300

1.320

1.400

1.410

1.520

1.700

1.800

2.000

2.010

2.600

mmm

7.62

10.16

11.43

15.24

15.49

17.78

20.32

20.37

22.35

22.86

23.11

25.53

25.65

30.48

33.02

33.53

35.56

35.81

38.61

43.18

45.72

50.80

51.05

66.04

inch/(mm)

Products shown covered by patents issued and/or pending. Specifications subject to change without notice.

5 Energy Way, West Warwick, RI 02893 USA

Tel: 800.424.9850 | 401.823.5200

Fax: 401.823.8723

info@advanced.com | www.advanced.com

CAT16-PREVIEW06 Rev. 1/06
