12N25W-40M

Description
Fixed Attenuator, 0MHz Min, 12400MHz Max, ROHS COMPLIANT PACKAGE
CategoryWireless rf/communication    Radio frequency and microwave
File Size41KB,1 Pages
ManufacturerCobham PLC
Environmental Compliance
Download Datasheet Parametric View All

12N25W-40M Overview

Fixed Attenuator, 0MHz Min, 12400MHz Max, ROHS COMPLIANT PACKAGE

12N25W-40M Parametric

Parameter NameAttribute value
Reach Compliance Codeunknown
Is SamacsysN
Other featuresN-M, I/P POWER-MAX(PEAK)=500W
Nominal attenuation40 dB
Characteristic impedance50 Ω
structureCOAXIAL
Maximum input power (CW)43.98 dBm
JESD-609 codee4
Maximum operating frequency12400 MHz
Minimum operating frequency
Maximum operating temperature125 °C
Minimum operating temperature-65 °C
RF/Microwave Device TypesFIXED ATTENUATOR
Terminal surfaceGOLD
Maximum voltage standing wave ratio1.3
Base Number Matches1
ATTENUATORS
Type N, up to 18 GHz, 25 Watts
SPECIFICATIONS:
Models: XXN25W-XX, XXN25W-XXF, XXN25W-XXM
Electrical:
Frequency Range
Standard Freq. Values
Standard dB Values*
Attenuation Accuracy
3 - 6 dB
7 - 20 dB
2 - 30 dB
1
3 - 40 dB
1
VSWR
DC - 6 GHz
6 - 1 GHz
2.4
1
2.4 - 18 GHz
Input Power
Peak Power
Impedance
Operating Temp Range
DC - 18.0 GHz
6, 1 & 18 GHz
2.4
3, 6, 10, 20, 30 & 40 dB
6 - 1 GHz
2.4
1
2.4 - 18 GHz
±0.50 dB
±0.75 dB
±0.75 dB
±1.00 dB
±1.00 dB
±1.25 dB
±1.25 dB
±1.50 dB
1.20:1 Max.
1.30:1 Max.
1.40:1 Max.
25 Watts Avg. @ 25°C
Derated Linearly to 5 Watts @ +1
o
C
25
DC - 6 GHz
±0.30 dB
±0.50 dB
±0.75 dB
±1.00 dB
2.65±.02
[67.31±0.51]
SQUARE
500 Watts Max.
(5uSec Pulse, .05% Duty Cycle)
* K is a Trademark of Anritsu Corp.
50 Ohms
-65°C to +125°C
Mechanical:
Type N Connectors
Mates with MIL
-STD-348
Passivated Stainless Steel
Gold Plated Beryllium Copper
Anodized Aluminum
END VIEW
TYPICAL
Units must be Mounted in such a way as to
Allow for Free Air Flow Around fins to Insure
Performance
Conductors
Housing
Model Number:
XXN25W-XX
Male/Female Connectors
Length: 4.50 ±.05 [1 4.3 ±1.3]
1
Pictured
4.50±.05
[114.43±1.27]
1.25
[31.75]
Model Number:
XXN25W-XXF
Female/Female Connectors
Length: 4.58 ±.05 [1
16.3 ±1.3]
Model Number:
XXN25W-XXM
Male/Male Connectors
Length: 4.4 ±.05 [1 2.0 ±1.3]
1
1
.25 [6.35]
2X M4x0.7 TAP
x .50[12.7] DP
.
2X 8-32UNC-2B TAP
x .50[12.7] DP
.
Ordering Examples:
Model Number:
18N25W-20
DC - 18 GHz; 20 dB; Type N - Male/Fem
Connector Configuration
= Male/Female
F = Fem/Fem
M = Male/Male
dB Value
Model Number:
6N25W-03F
DC - 6 GHz; 3 dB; Type N - Fem/Fem
HOW TO ORDER:
Model Number:
XXN25W-XXY
Freq. Range
6 = DC - 6 GHz
1 = DC - 1 GHz
2
2.4
18 = DC - 18 GHz
Note: Dimensions in Brackets are Expressed in Millimeters and are for Reference Only.
*Other dB values, units that operate over a more specific frequency band and/or offer very
low return loss (VSWR) are also available.
XXN25W-ATT: REV L
Aeroflex / Inmet, Inc.
• 300 Dino Drive, Ann Arbor, MI 48103 • U.S.A.
888-244-6638 or 734-426-5553 • FAX: 734-426-5557
www.aeroflex-inmet.com • inmetsales@aeroflex-.com
