HD74AC367
Hex Buffer/Driver with 3-State Output
REJ03D0271–0200Z
(Previous ADE-205-392 (Z))
Rev.2.00
Jul.16.2004
Features
•
3-State Outputs Drive Bus Lines or Buffer Memory Address Registers
•
Outputs Source/Sink 24 mA
•
Ordering Information
Part Name
HD74AC367AP
Package Type
DIP-16 pin
Package Code Package Abbreviation Taping Abbreviation (Quantity)
DP-16E, -16FV
FP-16DAV
TTP-16DAV
P
FP
RP
T
—
EL (2,000 pcs/reel)
EL (2,500 pcs/reel)
ELL(2,000 pcs/reel)
HD74AC367AFPEL SOP-16 pin (JEITA)
HD74AC367TELL
TSSOP-16 pin
HD74AC367ARPEL SOP-16 pin (JEDEC) FP-16DNV
Notes: 1. Please consult the sales office for the above package availability.
2. The packages with lead-free pins are distinguished from the conventional products by adding V at the end of
the package code.
Pin Arrangement
OE
1
I
O
I
O
I
O
GND
1
2
3
4
5
6
7
8
(Top view)
16 V
CC
15
OE
2
14 I
13 O
12 I
11 O
10 I
9
O
Rev.2.00, Jul.16.2004, page 1 of 7
HD74AC367
Logic Symbol
OE
I
O
Pin Names
OE
1
,
OE
2
I
O
3-State Output: Enable Input (Active Low)
Inputs
Outputs
Truth Table
Inputs
OE
L
L
H
H
L
X
Z
:
:
:
:
High Voltage Level
Low Voltage Level
Immaterial
High Impedance
L
H
X
I
L
H
Z
Output
O
Absolute Maximum Ratings
Item
Supply voltage
DC input diode current
DC input voltage
DC output diode current
DC output voltage
DC output source or sink current
DC V
CC
or ground current per output pin
Storage temperature
Symbol
V
CC
I
IK
V
I
I
OK
V
O
I
O
I
CC
, I
GND
Tstg
Ratings
–0.5 to 7
–20
20
–0.5 to Vcc+0.5
–50
50
–0.5 to Vcc+0.5
±50
±50
–65 to +150
Unit
V
mA
mA
V
mA
mA
V
mA
mA
°C
Condition
V
I
= –0.5V
V
I
= Vcc+0.5V
V
O
= –0.5V
V
O
= Vcc+0.5V
Recommended Operating Conditions
Item
Supply voltage
Input and Output voltage
Operating temperature
Input rise and fall time
(except Schmitt inputs)
V
IN
30% to 70% V
CC
Symbol
V
CC
V
I
, V
O
Ta
tr, tf
2 to 6
0 to V
CC
–40 to +85
8
Ratings
V
V
°C
ns/V
V
CC
= 3.0V
V
CC
= 4.5 V
V
CC
= 5.5 V
Unit
Condition
Rev.2.00, Jul.16.2004, page 2 of 7
HD74AC367
DC Characteristics
Item
Sym-
bol
V
IH
Vcc
(V)
3.0
4.5
5.5
V
IL
3.0
4.5
5.5
3.0
4.5
5.5
3.0
4.5
V
OL
5.5
3.0
4.5
5.5
3.0
4.5
Input leakage
current
3 State current
I
IN
I
OZ
5.5
5.5
5.5
min.
2.1
3.15
3.85
—
—
—
2.9
4.4
5.4
2.58
3.94
4.94
—
—
—
—
—
—
—
—
Ta = 25°C
°
typ.
1.5
2.25
2.75
1.50
2.25
2.75
2.99
4.49
5.49
—
—
—
0.002
0.001
0.001
—
—
—
—
—
max.
—
—
—
0.9
1.35
1.65
—
—
—
—
—
—
0.1
0.1
0.1
0.32
0.32
0.32
±0.1
±0.5
Ta = –40 to
+85°C
°
min.
2.1
3.15
3.85
—
—
—
2.9
4.4
5.4
2.48
3.80
4.80
—
—
—
—
—
—
—
—
max.
—
—
—
0.9
1.35
1.65
—
—
—
—
—
—
0.1
0.1
0.1
0.37
0.37
0.37
±1.0
±5.0
µA
µA
V
V
OUT
= 0.1 V or V
CC
–0.1 V
Unit
Condition
Input Voltage
V
V
OUT
= 0.1 V or V
CC
–0.1 V
Output voltage
V
OH
V
IN
= V
IL
or V
IH
I
OUT
= –50
µA
V
IN
= V
IL
or V
IH
I
OH
= –12 mA
I
OH
= –24 mA
I
OH
= –24 mA
V
IN
= V
IL
or V
IH
I
OUT
= 50
µA
V
IN
= V
IL
or V
IH
I
OL
= 12 mA
I
OL
= 24 mA
I
OL
= 24 mA
V
IN
= V
CC
or GND
V
IN(OE)
= V
IL
, V
IH
V
IN
= V
CC
or GND
V
OUT
= V
CC
or GND
V
OLD
= 1.1 V
V
OHD
= 3.85 V
V
IN
= V
CC
or ground
Dynamic output
current*
Quiescent supply
current
I
OLD
I
OHD
I
CC
5.5
5.5
5.5
—
—
—
—
—
—
—
—
8.0
86
–75
—
—
—
80
mA
mA
µA
*Maximum
test duration 2.0 ms, one output loaded at a time.
AC Characteristics
Ta = +25°C
C
L
= 50 pF
Item
Propagation delay
Propagation delay
Enable time
Enable time
Disable time
Disable time
Note:
Symbol
t
PLH
t
PHL
t
ZH
t
ZL
t
HZ
t
LZ
V
CC
(V)*
1
Min
3.3
1.0
5.0
3.3
5.0
3.3
5.0
3.3
5.0
3.3
5.0
3.3
5.0
1. Voltage Range 3.3 is 3.3 V ± 0.3 V
Voltage Range 5.0 is 5.0 V ± 0.5 V
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Typ
7.0
5.0
7.0
5.0
9.0
7.0
10.0
8.0
9.5
7.5
9.0
7.0
Max
9.0
7.0
9.0
7.0
12.5
9.0
12.5
10.0
12.0
10.0
12.5
10.0
Ta = –40°C to +85°C
C
L
= 50 pF
Min
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Max
10.0
7.5
10.0
7.5
13.0
9.5
13.5
10.5
12.5
10.5
13.5
10.5
Unit
ns
ns
ns
ns
ns
ns
Rev.2.00, Jul.16.2004, page 3 of 7
HD74AC367
Capacitance
Item
Input capacitance
Power dissipation capacitance
Symbol
C
IN
C
PD
4.5
45.0
Typ
pF
pF
Unit
V
CC
= 5.5 V
V
CC
= 5.0 V
Condition
Rev.2.00, Jul.16.2004, page 4 of 7
HD74AC367
Package Dimensions
As of January, 2003
Unit: mm
19.2
20.32 Max
16
9
6.3
7.4 Max
1
0.89
1.3
8
2.54 Min 5.06 Max
7.62
0.51 Min
2.54 ± 0.25
0.48 ± 0.1
0.25
– 0.05
0˚ – 15˚
Package Code
JEDEC
JEITA
Mass (reference value)
DP-16E
Conforms
Conforms
1.05 g
+ 0.1
Unit: mm
19.2
20.32 Max
16
9
6.3
7.4 Max
1
0.89
1.3
8
2.54 Min 5.06 Max
7.62
0.51 Min
2.54 ± 0.25
*0.48 ± 0.08
*0.25
± 0.06
0
˚
– 15
˚
Package Code
JEDEC
JEITA
Mass (reference value)
DP-16FV
Conforms
Conforms
1.05 g
*NI/Pd/AU Plating
Rev.2.00, Jul.16.2004, page 5 of 7
