Oscilent Corporation | 434 Series Surface Mount Crystal Oscillator
Page 1 of 2
SMD Oscillators
Series Number
Package
Description
Last Modified
434
FEATURES
- Ultra Low Jitter 1pS
- Low power consumption
- Tape and Reel
- Miniature profile 5 x 3.2 x 1.0
- 3.3V or 5.0V optional
- RoHs / Lead Free compliant
5 x 3.2 SMD Ceramic
HCMOS / TTL Output
Jan. 01 2007
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PARAMETERS
Output Logic
Input Voltage (Vdd)
Frequency Range (f
O
)
Operating Temperature (T
OPR
)
Storage Temperature (T
STG
)
Frequency Stability
CONDITIONS
-
-
-
-
-
a+b+c+d
(a) Frequency Tolerance
(b) Temperature Stability
(c) Input Voltage Stability
(d) Load Stability
Current Consumption
Aging
Rise Time (T
R
) / Fall Time (T
F
)
-
@ 25°C
< 23.999 MHz
24.00 ~ 70.00 MHz
70.001 ~ 100.00 MHz
-
PIN 1 Tri-State Input Voltage (Option)
-
-
Output Voltage High "1" VOH
Output Voltage Low "0" VOL
Duty Cycle
Start-Up Time (T
S
)
Jitter
TTL Load
HCMOS Load
TTL Load
HCMOS Load
-
-
(12KHz to 20MHz)
CHARACTERISTICS
HCMOS / TTL Output
3.3 ±10%
0.450 ~ 100.00
0 ~ +70 Std. (Ext Temp Avail. See Table Below)
-55 ~ +125
±20, ±25, ±50, ±100 max.
Inclusive of Overall Stability
Inclusive of Overall Stability (Operating Temperature)
Inclusive of Overall Stability (Vdd ±5%)
Inclusive of Overall Stability (RL ±5%)
10 ~ 45 (35) max.
±5 max.
10 max.
6 max.
4 max.
Vh (Pin 1) No Connection : Enables Output
Vh (Vih) > 2.2 Vdc : Enables Output
Vl (Vil) < 0.8 Vdc : Disables Output (High Impedance)
2.4 min.
Vdd * 0.9 min.
0.4 max.
Vdd * 0.1 min.
50 ±10 (Std.) / 50 ±5 (Option)
10 max.
RMS: ±1 max.
VDC
VDC
%
mS
ps
-
nS
15 ~ 85 (50) max.
5.0 ±10%
UNITS
-
VDC
MHz
°C
°C
ppm
-
-
-
-
mA
ppm/Y
PIN CONNECTIONS
Oscilent Corporation | 434 Series Surface Mount Crystal Oscillator
Page 2 of 2
#1 No Connection or
Tri-State Enable
High
#2 Case Ground
#3 Output
#4 Vdd
PART NUMBER GUIDE
Series
Number
Frequency
Voltage Supply
Option
Frequency
Tolerance &
Stability (max.)
Operating Temp.
(°C)
Duty Cycle
Pin 1 Connection
434
- 12.0M
-3
5 = 5VDC
3 = 3.3VDC
D=
E=
F=
G=
E
±100 ppm
±50 ppm
±25 ppm
±20 ppm
N
Blank* = 0~+70
C = -10~+70
D = -20~+70
N = -40~+85
-T
Blank*= 50±10%
T = -50±5%
TS
NC = No
Connnection
TS = Tri-State
Enable High
Enter your desired
Oscilent
SMD
frequency
e.g. 12.0M =
Oscillators
12.000MHz
NOTE:
- Deviations on all parameters available. Please consult Oscilent for details.
DEFINITIONS:
- Click on the characteristic names above, for definitions of the particular characteristic.
*STANDARDS:
- "Blank" part number selections, indicate standard variables for the particular characteristic.
PACKAGING:
- Add
-TR
for Tape/Reel. Click
here
for tape/reel specifications
CALL
949.252.0522
18195 East McDurmott Street . Building D . Irvine . CA 92614 . USA
Fax: 949.252.0599 . E-Mail: Sales@Oscilent.com
