LSM OSCILLATOR
700 kHz to 2.1 MHz
Low Power Surface Mount Crystal Oscillator
™
DESCRIPTION
actual size
The LSM oscillator has the highest accuracy, stability and
the lowest current of all STATEK surface mount oscillators.
The design consists of a STATEK crystal, and a CMOS-
compatible integrated circuit. The hybrid design is
hermetically-sealed with a kovar lid in a surface mount
ceramic package. Permanent precision tuning of the
oscillator is accomplished by laser trimming the crystal.
side view
PACKAGE DIMENSIONS
2
FEATURES
3
Low power consumption
Low aging
CMOS compatible
Hermetically sealed package
Full military testing available
3 Volt operation available
DIM
APPLICATIONS
1
4
F
TYPICAL
inches
0.400
0.180
0.071
0.200
0.080
0.050
0.055
mm
10.16
4.57
1.80
5.08
2.03
1.27
1.40
A
B
C*
D
E
F
G
MAXIMUM
inches
0.405
0.185
0.079
0.205
0.085
0.058
0.063
mm
10.29
4.70
2.00
5.21
2.16
1.47
1.60
Industrial, Computer & Communications
General purpose clock oscillator
Data logger
Remote sensor
Medical test and diagnostics
Military
Portable field communication
Military high speed modem
Termination material is Au over Ni (SM1), solder dip
(SM3) also available.
*SM1 Termination; SM3 = 0.084 in. (2.13mm) Max.
SUGGESTED LAND PATTERN
0.075 (1.91)
0.068 (1.73)
0.064 (1.63)
GRID
PLACEMENT
COURTYARD
0.132 (3.35)
inches (mm)
0.200 (5.08)
10154 - Rev B
S
YS
TEM
C
ERT
I
F
I
C
AT
N
IO
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
01
Pb
IS
O
90
SPECIFICATIONS: LSM 2.0 MHz
4
ABSOLUTE MAXIMUM RATINGS
Specifications are typical at 25
O
C unless otherwise noted.
Specifications are subject to change without notice.
Supply Voltage
1
Calibration Tolerance
2
5V
+
_
+
_
+
_
+
_
Supply Voltage V
DD
Storage Temperature
Process Temperature
3.3V to 7V
-55
O
C to +125
O
C
260
O
C 20 sec.
10% (3.3V available)
ELECTRICAL CHARACTERISTICS
LSM 2.0 MHz
100 ppm (0.01%)
300 ppm (0.03%)
1000 ppm (0.1%)
All parameters are measured at ambient temperature
with a 10MΩ and 10pF load at 5V.
SYMBOL PARAMETER
V
OH
V
OL
t
r
t
f
SYM
I
DD
Output Voltage Hi
Output Voltage Lo
Rise Time (10%-90%)
Fall Time (10%-90%)
Duty Cycle
Supply Current
V
DD
=5V
V
DD
=3.3V
Start-Up Time
40
MIN.
4.8
TYP. MAX. UNIT
4.95
0.05 0.2
12
12
50
300
200
20
25
25
60
400
300
V
V
nsec.
nsec.
%
Frequency Stability
3
0
O
C to +70
O
C
_
0.12%
Typ.
_
0.017%
MAX.
+
_
Voltage Coefficient
Aging
Shock, survival
Vibration, survival
Frequency Change vs
10%Output Load Change
Operating Temp. Range
5 ppm/V MAX.
10 ppm/year MAX.
+
_
750 g peak, 0.3 ms,1/2 sine
10 g RMS, 10 - 2000 Hz
µ
A
µ
A
msec.
+
_
1 ppm MAX.
PIN CONNECTIONS
-10
O
C to +70
O
C (Commercial)
-40
O
C to +85
O
C (Industrial)
-55
O
C to +125
O
C (Military)
Pin
1
2
3
4
Connection
NC
Ground
Output
V
DD
1. Contact the factory for lower voltage.
2. Tighter tolerances available.
3. Does not include calibration tolerance. Positive variations are much smaller.
4. Contact the factory for other frequencies.
PACKAGING OPTIONS
LSM
TYPICAL CURRENT CONSUMPTION,
LSM 2.0 MHZ
-Tray Pack
-16mm tape, 7” or 13” reels
(Reference tape and reel data sheet 10109)
CURRENT (uA)
400
OUTPUT WAVE FORM
300
200
100
0
2
DD
V
DD
V
OH
4
V (V)
6
8
90%*
10%*
V
OL
0
* Of
V
DD
t
r
t
f
HOW TO ORDER LSM CRYSTAL OSCILLATORS
LSM
3
3=3.3V
Blank=5V (Std.)
S
“S” if special
or custom
design.
Blank if Std.
SM3
Blank = SM1
= Gold Plated
(Lead Free)
SM3 = Solder Dipped
SM5 = Solder Dipped
(Lead Free)
2.0M
Frequency
,
100
Calibration
Tolerance*
@ 25
O
C
(in ppm)
*Other
calibrations available:
indicate your requirement in ppm.
/
I
Operating Temp. Range:
C = -10
O
C to +70
O
C
I
= -40
O
C to +85
O
C
M = -55
O
C to +125
O
C
S = Customer Specified
10154 - Rev C
S
YS
TEM
C
ERT
I
F
I
C
AT
N
IO
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
01
Pb
IS
O
90
