Micro limit snap action switch
Distinctive features and specifications
MAB series
K
Movement differential ≤0.4mm.
change-over functions.
available.
K
Available in normally open, normally closed and
K
Solder lug, quick connect, PCB, and screw terminals
• AC rating: 1(0.3)A...16(4)A, 250VAC
• Electrical life: 50,000 cycles min.
ELECTRICAL SPECIFICATIONS
• Case: PBT/PET (UL94V-0)
• Actuator: Phenolic (UL94V-0)
• Contact spring: CuBe
• Terminals: CuZn Ag plated
• Contacts: AgNi
MATERIALS
•
•
•
•
•
•
Operating temperature: -10°C to +85/125°C
Pretravel: <1.4 mm
Overtravel: 0.75mm min to 1.50mm max.
Movement differential: <0.4mm
Operating position: 14.8±0.6mm
Contact gap: <3mm
GENERAL SPECIFICATIONS
AGENCY APPROVALS
APEM
www.apem.com
1
MAB series
Micro limit snap action switch
MAB
SERIES
Operation
force
0.8N
1.0N
1.5N
2.0N
3.0N
2.5N
3.5N
01
02
A
B
A
B
C
Function
Normally closed
Normally open
Change-over
101
102
103
104
[ENEC-VDE 1(0.3)A 250VAC]
[cULus 5A 125VAC]
[ENEC-VDE 5(2)A 250VAC]
[cULus 10A 125VAC]
[ENEC-VDE 10(3)A 250VAC]
[ENEC-VDE 16(4)A 250VAC]
[cULus 16A 125VAC]
[cULus 1A 125VAC]
Ratings
C
E
D
F
Ambient temp.
10T125
10T85
01
Plunger
Actuators
03
Short hinge lever
05
Long hinge lever
06
Short roller lever
07
Long roller lever
08
Simulated roller
G
H
04
Medium hinge lever
4.0N
A
B
X
Front
Rear
Fixing position
01
No additional actuator
02
03
04
05
0.8x6.3mm quick connects
0.5x4.7mm quick connects
0.8x4.7mm quick connects
Left bend PCB terminals
Solder lug terminals
Screw terminals
5mm pin spacing
0.5x4.7mm solder lug terminals
Right bend PCB terminals
Terminals
B
A
3mm (availible upon request)
<3mm (standard)
Contact Gap
06
08
09
07
Dimensions
: first dimensions are in mm while inches are shown as bracketed numbers.
: please note that not all combinations of above numbers are available. Refer to the following pages for
further information.
NOTICE
ABOUT THIS SERIES
On the following pages, you will find successively :
- model structure of switches
- options in the same order as in above chart
2
www.apem.com
APEM
MAB series
Micro limit snap action switch
COM 1
2 N.C.
4 N.O.
Change-over with plunger
10.30 2.80
(.406) (.110)
Ø
3.10
(
Ø
.122)
3.10
(.122)
NC
1.40
14.80
(.055)
(.583)
OPERATING MAX.
POSITION
2.80
(.110)
20.20
(.795)
4.20
(.165)
MAB
C01B01
NO
2.80
(.110)
3.40
(.134)
22.20
(.874)
27.80
(1.094)
C
10.30
(.406)
2.00
(.079)
Change-over with short hinge lever
10.30 2.80
(.406) (.110)
22.50
(.886)
Ø
3.10
(
Ø
.122)
3.10
(.122)
NC
15.80
1.40
(0.55)
(.622)
OPERATING MAX.
POSITION
4.80
(.189)
MAB
C03B01
NO
2.80
(.110)
3.40
(.134)
22.20
(.874)
27.80
(1.094)
C
10.30
(.406)
2.00
(.079)
Change-over with medium hinge lever
10.30 2.80
(.406) (.110)
35.60
(1.402)
16.30
4.00
(.641)
(.157)
OPERATING MAX.
POSITION
4.80
(.189)
Ø
3.10
(
Ø
.122)
3.10
(.122)
NC
MAB
C04B01
NO
2.80
(.110)
3.40
(.134)
22.20
(.874)
27.80
(1.094)
C
10.30
(.406)
2.00
(.079)
APEM
www.apem.com
15.90
(.626)
15.90
(.626)
15.90
(.626)
3
MAB series
Micro limit snap action switch
Change-over with long hinge lever
10.30 2.80
(.406) (.110)
59.40
(2.339)
17.20
8.00
(.677)
(.315)
OPERATING MAX.
POSITION
4.80
(.189)
Ø
3.10
(
Ø
.122)
3.10
(.122)
NC
MAB
C05B01
NO
2.80
(.110)
3.40
(.134)
22.20
(.874)
27.80
(1.094)
C
10.30
(.406)
2.00
(.079)
1.40
(.055)
MAX.
Change-over with short roller lever
10.30 2.80
(.406) (.110)
20.20
(.795)
4.20
(.165)
Ø4.80
(Ø.189)
10.30
(.406)
4.20
(.165)
Ø4.80
(Ø.189)
10.30
(.406)
4.80
(.189)
10.30
(.406)
15.90
(.626)
NC
MAB
C006B01
NO
2.80
(.110)
3.40
(.134)
22.20
(.874)
27.80
(1.094)
C
2.00
(.079)
10.30 2.80
(.406) (.110)
NC
21.40
(.843)
OPERATING
POSITION
Ø
3.10
(
Ø
.122)
3.10
(.122)
4.00
(.157)
MAX.
Change-over with long roller lever
34.00
(1.339)
21.40
(.843)
OPERATING
POSITION
Ø
3.10
(
Ø
.122)
3.10
(.122)
MAB
C07B01
NO
2.80
(.110)
3.40
(.134)
22.20
(.874)
27.80
(1.094)
C
2.00
(.079)
Change-over with simulated roller
10.30 2.80
(.406) (.110)
32.60
(1.283)
4.00
(.157)
MAX.
NC
19.50
(.768)
OPERATING
POSITION
Ø
3.10
(
Ø
.122)
3.10
(.122)
MAB
C08B01
NO
2.80
(.110)
3.40
(.134)
22.20
(.874)
27.80
(1.094)
C
2.00
(.079)
4
www.apem.com
APEM
15.90
(.626)
15.90
(.626)
15.90
(.626)
MAB series
Fixing position
Micro limit snap action switch
X No additional
actuator
A Front
Terminal options
B Rear
01 0.8x6.3mm quick connect terminals
Ø
2.00
(
Ø
.079)
4.00
(.157)
6.30
(.248)
02 0.5x4.7mm quick connect terminals
Ø
1.50
(
Ø
.059)
3.20
(.126)
4.70
(.185)
6.30
(.248)
0.50
(.020)
11.40
(.449)
8.00
(.315)
7.20 2.10
(.283) (.083)
0.80
(.032)
11.90
(.469)
03 0.8x4.7mm quick connect terminals
Ø
1.50
(
Ø
.059)
3.20
(.126)
4.70
(.185)
7.40
(.291)
04 0.5x4.7mm solder lug terminals
R1.20
(R.047)
3.10
(.122)
R0.50
(R.020)
4.70
(.185)
6.30
(.248)
0.50
(.020)
11.40
(.449)
7.30 5.50 2.95
(.287) (.217) (.116)
6.30
(.248)
7.30 5.20 3.10
(.287) (.205) (.122)
0.80
(.031)
11.40
(.449)
7.30 5.50 2.95
(.287) (.217) (.116)
APEM
www.apem.com
5
