MJ13101 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> MJ13101

MJ13101: DescriptionTransistor; CategoryDiscrete semiconductor The transistor; File Size65KB，1 Pages; ManufacturerMotorola ( NXP ); Websitehttps://www.nxp.com

Download Datasheet Parametric Compare View All

MJ13101 Overview

Transistor

MJ13101 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Motorola ( NXP )
package instruction	,
Reach Compliance Code	unknown
Maximum collector current (IC)	20 A
Configuration	Single
Minimum DC current gain (hFE)	8
JESD-609 code	e0
Maximum operating temperature	200 °C
Polarity/channel type	NPN
Maximum power dissipation(Abs)	175 W
surface mount	NO
Terminal surface	Tin/Lead (Sn/Pb)
Base Number Matches	1

Preview

Download Datasheet

View All

MJ13101 Related Products

	MJ13101	BUV18A	BUS50	MJ11019	BUV60	BUX40
Description	Transistor	Power Bipolar Transistor, 80A I(C), 100V V(BR)CEO, 1-Element, NPN, Silicon, TO-204AE, Metal, 2 Pin	Power Bipolar Transistor, 70A I(C), 125V V(BR)CEO, 1-Element, NPN, Silicon, TO-204AE, Metal, 2 Pin	Power Bipolar Transistor, 15A I(C), 250V V(BR)CEO, 1-Element, PNP, Silicon, TO-204AA, Metal, 2 Pin	Power Bipolar Transistor, 50A I(C), 125V V(BR)CEO, 1-Element, NPN, Silicon, TO-204AE, Metal, 2 Pin	Power Bipolar Transistor, 20A I(C), 125V V(BR)CEO, 1-Element, NPN, Silicon, TO-204AA, Metal, 2 Pin
Maker	Motorola ( NXP )	Motorola ( NXP )	Motorola ( NXP )	Motorola ( NXP )	Motorola ( NXP )	Motorola ( NXP )
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown
Maximum collector current (IC)	20 A	80 A	70 A	15 A	50 A	20 A
Configuration	Single	SINGLE	SINGLE WITH BUILT-IN DIODE	DARLINGTON	SINGLE	SINGLE
Minimum DC current gain (hFE)	8	10	15	100	10	8
Polarity/channel type	NPN	NPN	NPN	PNP	NPN	NPN
surface mount	NO	NO	NO	NO	NO	NO
Is it Rohs certified?	incompatible	-	incompatible	incompatible	incompatible	incompatible
JESD-609 code	e0	-	e0	e0	e0	e0
Maximum operating temperature	200 °C	-	200 °C	175 °C	175 °C	-
Maximum power dissipation(Abs)	175 W	-	350 W	175 W	250 W	-
Terminal surface	Tin/Lead (Sn/Pb)	-	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Base Number Matches	1	1	1	1	-	-
Shell connection	-	COLLECTOR	COLLECTOR	COLLECTOR	COLLECTOR	COLLECTOR
Collector-emitter maximum voltage	-	100 V	125 V	250 V	125 V	125 V
JEDEC-95 code	-	TO-204AE	TO-204AE	TO-204AA	TO-204AE	TO-204AA
JESD-30 code	-	O-MBFM-P2	O-MBFM-P2	O-MBFM-P2	O-MBFM-P2	O-MBFM-P2
Number of components	-	1	1	1	1	1
Number of terminals	-	2	2	2	2	2
Package body material	-	METAL	METAL	METAL	METAL	METAL
Package shape	-	ROUND	ROUND	ROUND	ROUND	ROUND
Package form	-	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT
Maximum power consumption environment	-	250 W	-	175 W	250 W	120 W
Certification status	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Terminal form	-	PIN/PEG	PIN/PEG	PIN/PEG	PIN/PEG	PIN/PEG
Terminal location	-	BOTTOM	BOTTOM	BOTTOM	BOTTOM	BOTTOM
transistor applications	-	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING
Transistor component materials	-	SILICON	SILICON	SILICON	SILICON	SILICON
