NL17SZ16
Single Input Buffer
The NL17SZ16 is a single input Buffer in tiny footprint packages.
Features
•
•
•
•
•
•
Designed for 1.65 V to 5.5 V V
CC
Operation
2.7 ns t
PD
at V
CC
= 5 V (typ)
Inputs/Outputs Overvoltage Tolerant up to 5.5 V
I
OFF
Supports Partial Power Down Protection
Source/Sink 24 mA at 3.0 V
Available in SC−88A, SC−74A, SOT−553, SOT−953 and UDFN6
Packages
•
Chip Complexity < 100 FETs
•
NLV Prefix for Automotive and Other Applications Requiring
Unique Site and Control Change Requirements; AEC−Q100
Qualified and PPAP Capable
•
These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
Compliant
A
1
Y
www.onsemi.com
MARKING
DIAGRAMS
SC−88A
DF SUFFIX
CASE 419A
XX MG
G
SC−74A
DBV SUFFIX
CASE 318BQ
XXX MG
G
Figure 1. Logic Symbol
SOT−553
XV5 SUFFIX
CASE 463B
XX MG
G
SOT−953
P5 SUFFIX
CASE 527AE
UDFN6
1.45 x 1.0
CASE 517AQ
XM
1
1
XM
UDFN6
1.0 x 1.0
CASE 517BX
XX
M
G
XM
1
= Specific Device Code
= Date Code*
= Pb−Free Package
(Note: Microdot may be in either location)
*Date Code orientation and/or position may
vary depending upon manufacturing location.
ORDERING INFORMATION
See detailed ordering, marking and shipping information in the
package dimensions section on page 7 of this data sheet.
©
Semiconductor Components Industries, LLC, 2011
November, 2018
−
Rev. 12
1
Publication Order Number:
NL17SZ16/D
NL17SZ16
NC
1
A
2
GND
3
Y
4
V
CC
5
A
1
GND
2
NC
3
Y
4
GND
(SC−88A/SOT−553/SC−74A)
SOT−953
UDFN6
3
4
Y
A
2
5
NC
V
CC
5
NC
1
6
V
CC
Figure 2. Pinout
(Top View)
PIN ASSIGNMENT
(SC−88A/SOT−553/SC−74A)
Pin
1
2
3
4
5
Function
NC
A
GND
Y
V
CC
PIN ASSIGNMENT
(SOT−953)
Pin
1
2
3
4
5
Function
A
GND
NC
Y
V
CC
PIN ASSIGNMENT
(UDFN)
Pin
1
2
3
4
5
6
Function
NC
A
GND
Y
NC
V
CC
FUNCTION TABLE
A Input
L
H
Y Output
L
H
www.onsemi.com
2
NL17SZ16
MAXIMUM RATINGS
Symbol
V
CC
V
IN
V
OUT
DC Supply Voltage
DC Input Voltage
DC Output Voltage
SC−88A (NLV),
UDFN6, SOT−553
DC Output Voltage
SC−74A, SC−88A, SOT−953
I
IK
I
OK
I
OUT
I
CC
or I
GND
T
STG
T
L
T
J
q
JA
DC Input Diode Current
DC Output Diode Current
DC Output Source/Sink Current
DC Supply Current per Supply Pin or Ground Pin
Storage Temperature Range
Lead Temperature, 1 mm from Case for 10 secs
Junction Temperature Under Bias
Thermal Resistance (Note 2)
SC−88A
SC−74A
SOT−553
SOT−953
UDFN6
SC−88A
SC−74A
SOT−553
SOT−953
UDFN6
Characteristics
UDFN6, SOT−553, SC−88A (NLV)
SC−74A, SC−88A, SOT−953
UDFN6, SOT−553, SC−88A (NLV)
SC−74A, SC−88A, SOT−953
Active−Mode (High or Low State)
Tri−State Mode (Note 1)
Power−Down Mode (V
CC
= 0 V)
Active−Mode (High or Low State)
Tri−State Mode (Note 1)
Power−Down Mode (V
CC
= 0 V)
V
IN
< GND
V
OUT
< GND
Value
−0.5
to +7.0
−0.5
to +6.5
−0.5
to +7.0
−0.5
to +6.5
−0.5
to V
CC
+ 0.5
−0.5
to +7.0
−0.5
to +7.0
−0.5
to V
CC
+ 0.5
−0.5
to +6.5
−0.5
to +6.5
−50
±50
±50
±100
−65
to +150
260
+150
659
555
562
560
382
190
225
222
223
327
Level 1
Oxygen Index: 28 to 34
Human Body Model
Charged Device Model
UL 94 V−0 @ 0.125 in
2000
1000
$100
Unit
V
V
V
V
mA
mA
mA
mA
°C
°C
°C
°C/W
P
D
Power Dissipation in Still Air
mW
MSL
F
R
V
ESD
I
Latchup
Moisture Sensitivity
Flammability Rating
ESD Withstand Voltage (Note 3)
Latchup Performance (Note 4)
−
−
V
mA
Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality
should not be assumed, damage may occur and reliability may be affected.
1. Applicable to devices with outputs that may be tri−stated.
2. Measured with minimum pad spacing on an FR4 board, using 10mm−by−1inch, 2 ounce copper trace no air flow.
3. HBM tested to ANSI/ESDA/JEDEC JS−001−2017. CDM tested to EIA/JESD22−C101−F. JEDEC recommends that ESD qualification to
EIA/JESD22−A115−A (Machine Model) be discontinued per JEDEC/JEP172A.
4. Tested to EIA/JESD78 Class II.
www.onsemi.com
3
NL17SZ16
RECOMMENDED OPERATING CONDITIONS
Symbol
V
CC
V
IN
V
OUT
Positive DC Supply Voltage
DC Input Voltage
DC Output Voltage
Active−Mode (High or Low State)
Tri−State Mode (Note 1)
Power−Down Mode (V
CC
= 0 V)
Characteristics
Min
1.65
0
0
0
0
−55
V
CC
= 3.0 V to 3.6 V
V
CC
= 4.5 V to 5.5 V
V
CC
= 1.65 V to 1.95 V
V
CC
= 2.3 V to 2.7 V
V
CC
= 3.0 V to 3.6 V
V
CC
= 4.5 V to 5.5 V
0
0
0
0
0
0
Max
5.5
5.5
V
CC
5.5
5.5
+125
100
20
20
20
10
5
°C
ns/V
Unit
V
V
T
A
t
r
, t
f
Operating Temperature Range
Input Rise and Fall Time
(SC−88A (NLV), UDFN6, SOT−553)
Input Rise and Fall Time
(SC−74A, SC−88A, SOT−953)
Functional operation above the stresses listed in the Recommended Operating Ranges is not implied. Extended exposure to stresses beyond
the Recommended Operating Ranges limits may affect device reliability.
DC ELECTRICAL CHARACTERISTICS
Symbol
V
IH
V
IL
V
OH
Parameter
High−Level Input
Voltage
Low−Level Input
Voltage
High−Level Output
Voltage
V
IN
= V
IH
or V
IL
I
OH
=
−100
mA
I
OH
=
−4
mA
I
OH
=
−8
mA
I
OH
=
−12
mA
I
OH
=
−16
mA
I
OH
=
−24
mA
I
OH
=
−32
mA
V
IN
= V
IH
or V
IL
I
OL
= 100
mA
I
OL
= 4 mA
I
OL
= 8 mA
I
OL
= 12 mA
I
OL
= 16 mA
I
OL
= 24 mA
I
OL
= 32 mA
V
IN
= 5.5 V or GND
V
IN
= 5.5 V or
V
OUT
= 5.5 V
V
IN
= V
CC
or GND
Condition
V
CC
(V)
1.65 to 1.95
2.3 to 5.5
1.65 to 1.95
2.3 to 5.5
1.65 to 5.5
1.65
2.3
2.7
3.0
3.0
4.5
1.65 to 5.5
1.65
2.3
2.7
3.0
3.0
4.5
1.65 to 5.5
0
5.5
T
A
= 255C
Min
0.65 V
CC
0.70 V
CC
−
−
V
CC
−
0.1
1.29
1.9
2.2
2.4
2.3
3.8
−
−
−
−
−
−
−
−
−
−
Typ
−
−
−
−
V
CC
1.4
2.7
2.5
4.0
2.1
2.4
−555C
3
T
A
3
1255C
Max
−
−
0.35 V
CC
0.30 V
CC
−
−
−
−
−
−
−
0.1
0.24
0.3
0.4
0.4
0.55
0.55
±0.1*
1.0
1.0
Min
0.65 V
CC
0.70 V
CC
−
−
V
CC
−
0.1
1.29
1.9
2.2
2.4
2.3
3.8
−
−
−
−
−
−
−
−
−
−
Max
−
−
0.35 V
CC
0.30 V
CC
−
−
−
−
−
−
−
0.1
0.24
0.3
0.4
0.4
0.55
0.55
±1.0
10
10
V
V
Units
V
V
OL
Low−Level Output
Voltage
V
0.08
0.2
0.22
0.28
0.38
0.42
−
−
−
I
IN
I
OFF
I
CC
Input Leakage Current
Power Off Leakage
Current
Quiescent Supply
Current
mA
mA
mA
Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product
performance may not be indicated by the Electrical Characteristics if operated under different conditions.
*Guaranteed by design.
www.onsemi.com
4
NL17SZ16
AC ELECTRICAL CHARACTERISTICS
(t
R
= t
F
= 3.0 ns)
Symbol
t
PLH
t
PHL
Parameter
Propagation Delay, A to Y
(Figures 3 and 4)
Condition
R
L
= 1 MW, C
L
= 15 pF
R
L
= 1 MW, C
L
= 15 pF
R
L
= 1 MW, C
L
= 15 pF
R
L
= 500
W,
C
L
= 50 pF
R
L
= 1 MW, C
L
= 15 pF
R
L
= 500
W,
C
L
= 50 pF
4.5 to 5.5
V
CC
(V)
1.65 to 1.95
2.3 to 2.7
3.0 to 3.6
T
A
= 255C
Min
−
−
−
−
−
−
Typ
5.3
2.9
2.1
2.9
1.8
2.4
Max
11.4
6.5
4.5
5.0
3.9
4.3
−555C
3
T
A
3
1255C
Min
−
−
−
−
−
−
Max
12.0
7.0
4.7
5.2
4.1
4.5
Units
ns
CAPACITIVE CHARACTERISTICS
(t
R
= t
F
= 3.0 ns)
Symbol
C
IN
C
OUT
C
PD
Parameter
Input Capacitance
Output Capacitance
Power Dissipation Capacitance
(Note 5)
Condition
V
CC
= 5.5 V, V
IN
= 0 V or V
CC
V
CC
= 5.5 V, V
IN
= 0 V or V
CC
10 MHz, V
CC
= 3.3 V, V
IN
= 0 V or V
CC
10 MHz, V
CC
= 5.5 V, V
IN
= 0 V or V
CC
Typical
2.5
2.5
9
11
Units
pF
pF
pF
5. C
PD
is defined as the value of the internal equivalent capacitance which is calculated from the operating current consumption without load.
Average operating current can be obtained by the equation: I
CC(OPR
)
= C
PD
V
CC
f
in
+ I
CC
. C
PD
is used to determine the no−load dynamic
power consumption; P
D
= C
PD
V
CC2
f
in
+ I
CC
V
CC
.
www.onsemi.com
5
