SMD Wire-wound Chip Inductors - High Q
ctparts.com
CT0805HQ Series
From 2.5 nH to 51 nH
Part
Number
CT0805HQ_-2N5_*
CT0805HQ_-5N6_*
CT0805HQ_-6N2_*
Not shown at actual size.
CT0805HQ_-12N_*
CT0805HQ_-16N_
CT0805HQ_-18N_
CT0805HQ_-20N_
CT0805HQ_-27N_
CT0805HQ_-30N_
CT0805HQ_-39N_
CT0805HQ_-48N_
CT0805HQ_-51N_
SPECIFICATIONS
Please specify tolerance code when ordering.
CT0805HQ-16N_
G = ±2%, J = ±5%, K = ±10%
* J or K only
CT0805HQF
Please specify “F” for RoHS compliant
Inductance
(nH)
2.5
5.6
6.2
12
16
18
20
27
30
39
48
51
L Test
Freq.
(MHz)
250
250
250
250
250
250
250
250
250
250
200
200
Q
Fact.
Min.
80
98
88
80
72
75
70
75
65
65
65
65
Q Test
Freq.
(MHz)
1500
1500
1000
1000
500
500
500
500
500
500
500
500
SRF
Typ.
(MHz)
6000
6000
4750
3000
2950
2550
2050
2000
1950
1600
1400
1400
DCR
Max.
Ω
(Ω)
0.020
0.035
0.035
0.045
0.060
0.060
0.055
0.070
0.095
0.095
0.110
0.120
Irms
Max.
(mA)
1600
1600
1600
1600
1500
1400
1400
1300
1200
1100
1200
1000
Compliant
Available
RoHS
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
2.29
0.090
B
Max.
1.78
0.070
C
Max.
1.52
0.060
D
0.50
0.020
E
1.27
0.050
F
0.44
0.017
G
1.27
0.050
CHARACTERISTICS
Description:
SMD wire-wound chip inductor (High Q)
Applications:
LC resonant circuits such as oscillator and signal
generators, impedance matching, circuit isolation, RF filters, disk
drives and computer peripherals, audio and video equipment, TV,
radio and telecommunication equipment
Operating Temperature:
-40°C to +125°C
Inductance Tolerance:
±2%, ±5%, ±10%
Testing:
Inductance and Q tested on an HP4287A at specified
frequency.
Packaging:
Tape & Reel
Miscellaneous:
RoHS Compliant available.
Marking:
Color dot
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
B
C
F
A
G
F
E
D
Terminal wraparound
Approx. 0.38mm Both ends
PAD LAYOUT
mm
(inch)
1.02
(0.040)
0.76
(0.030)
1.02
(0.040)
1.78
(0.070)
09.18.06
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2006 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
