PHA2729-300M
Radar Pulsed Power Module
300W, 2.7-2.9 GHz, 100μs Pulse, 10%Duty
Features
•
•
•
•
•
•
Includes RC bias circuit
In-Phase combined pulsed power transistors
Input and output matched to 50 W
Soft substrate
ε
R
=10.5 circuit board
Nickel plated copper flange
MTTF > 1x10
6
hrs @ T
flange
=45 °C
M/A-COM Products
Released;
RoHS Compliant
Outline Drawing
ABSOLUTE MAXIMUM RATING AT 25°C
Parameter
Symbol
Rating
Junction Temparature
Thermal Resistance
Power Dissipation
Operating Flange Temp.
Storage Temp.
T
j
θ
JC
P
D
T
C
T
STG
200
TBD
TBD
-10 to +100
-40 to +125
Units
°C
°C/W
W
°C
°C
ELECTRICAL CHARACTERISTICS AT 25°C
Parameter
Input Power
Symbol
P
IN
P
OUT
G
P
Min
-
Max
53.3
Units
Wpk
Test Conditions
V
CC
= 38V, P
out
= 300 Wpk, F =2.7, 2.8, 2.9 GHz
V
CC
= 38V, P
IN
=(P
IN @
Pout = 300 W) + 0.5 dB, F =2.7, 2.8, 2.9 GHz
V
CC
= 38V, P
out
= 300 Wpk, F =2.7, 2.8, 2.9 GHz
V
CC
= 38V, P
out
= 300 Wpk, F =2.7, 2.8, 2.9 GHz
V
CC
= 38V, P
out
= 300 Wpk, F =2.7, 2.8, 2.9 GHz
V
CC
= 38V, P
out
= 300 Wpk, F =2.7, 2.8, 2.9 GHz
V
CC
= 38V, P
out
= 300 Wpk, F =2.7, 2.8, 2.9 GHz
V
CC
= 38V, P
out
= 300 Wpk, F =2.7, 2.8, 2.9 GHz
V
CC
= 38V, P
out
= 300 Wpk, F =2.7, 2.8, 2.9 GHz
V
CC
= 38V, P
out
= 300 Wpk, F =2.7, 2.8, 2.9 GHz
V
CC
= 38V, P
out
= 300 Wpk, F =2.7, 2.8, 2.9 GHz
V
CC
= 38V, P
out
= 300 Wpk, F =2.7, 2.8, 2.9 GHz
V
CC
= 38V, P
out
= 300 Wpk, F =2.7, 2.8, 2.9 GHz
Output Power with .5 dB overtime
Power Gain
Collector Efficiency
Input Return Loss
Pulse Amplitude Droop
2nd Harmonic
Spurious Level
Insertion Phase Deviation
Rise time
Load Miss Match Stability
Load Miss Tolerance
Gain Flatness over Frequency
315
7.5
36
10
-
-
-
-14
-
-
-
-
-
-
-
-
-
.5
-20
-60
+14
1.5:1
2:1
.8
Wpk
dB
%
dB
dB
dBc
dBc
Degrees
N
S
η
C
R
L
D
ROOP
2FC
Spurious
Δϕ
T
R
VSWR-S
VSWR-T
G
P
Flat
-
dB
dB
1
ADVANCED:
Data Sheets contain information regarding a product M/A-COM Technology Solutions
•
North America
Tel: 800.366.2266 / Fax: 978.366.2266
is considering for development. Performance is based on target specifications, simulated results,
•
Europe
Tel: 44.1908.574.200 / Fax: 44.1908.574.300
and/or prototype measurements. Commitment to develop is not guaranteed.
•
Asia/Pacific
Tel: 81.44.844.8296 / Fax: 81.44.844.8298
PRELIMINARY:
Data Sheets contain information regarding a product M/A-COM Technology
Visit www.macomtech.com for additional data sheets and product information.
Solutions has under development. Performance is based on engineering tests. Specifications are
typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available.
M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make
Commitment to produce in volume is not guaranteed.
changes to the product(s) or information contained herein without notice.
PHA2729-300M
Radar Pulsed Power Module
300W, 2.7-2.9 GHz, 100μs Pulse, 10%Duty
M/A-COM Products
Released;
RoHS Compliant
SAMPLE TEST DATA
TEST CONDITIONS: V
CC
=38V
DC
, PULSE WIDTH: 100
μS,
DUTY CYCLE : 10%, POUT: 300 W
PK
, TFLANGE: 50° C
Freg
(GHz)
2.7
2.8
2.9
P
IN
(Wpk)
36.4
39.4
43.1
I
C
(A)
16.43
16.95
17.33
R.Loss
(dB)
16.9
18.2
14.5
P.Drp.
(dB)
0.0
0.0
0.0
G
P
(dB)
9.16
8.82
8.43
Nc
(%)
48.1
46.6
45.6
Po 1 DB
(dB)
351
359
337
Comp.
(dB)
0.68
0.78
0.51
G
P
Flat
(dB)
1.5:1
VSWR
(S,D,L,B)
s
s
s
2.0:1
VSWR
(P,F)
P
P
P
0.73
2
