IRF230

Description
9A, 200V, 0.4ohm, N-CHANNEL, Si, POWER, MOSFET, TO-204AA
CategoryDiscrete semiconductor    The transistor
File Size69KB,7 Pages
ManufacturerRenesas Electronics Corporation
Websitehttps://www.renesas.com/
Download Datasheet Parametric Compare View All

IRF230 Online Shopping

Suppliers Part Number Price MOQ In stock
IRF230 - - View Buy Now

IRF230 Overview

9A, 200V, 0.4ohm, N-CHANNEL, Si, POWER, MOSFET, TO-204AA

IRF230 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerRenesas Electronics Corporation
Reach Compliance Codenot_compliant
ECCN codeEAR99
Factory Lead Time1 week
Shell connectionDRAIN
ConfigurationSINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage200 V
Maximum drain current (Abs) (ID)9 A
Maximum drain current (ID)9 A
Maximum drain-source on-resistance0.4 Ω
FET technologyMETAL-OXIDE SEMICONDUCTOR
JEDEC-95 codeTO-204AA
JESD-30 codeO-MBFM-P2
JESD-609 codee0
Number of components1
Number of terminals2
Operating modeENHANCEMENT MODE
Maximum operating temperature150 °C
Package body materialMETAL
Package shapeROUND
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Polarity/channel typeN-CHANNEL
Maximum power consumption environment75 W
Maximum power dissipation(Abs)75 W
Maximum pulsed drain current (IDM)36 A
Certification statusNot Qualified
surface mountNO
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formPIN/PEG
Terminal locationBOTTOM
Maximum time at peak reflow temperatureNOT SPECIFIED
transistor applicationsSWITCHING
Transistor component materialsSILICON
Maximum off time (toff)90 ns
Maximum opening time (tons)80 ns
Semiconductor
IRF230, IRF231,
IRF232, IRF233
8.0A and 9.0A, 150V and 200V, 0.4 and 0.6 Ohm,
N-Channel Power MOSFETs
Description
These are N-Channel enhancement mode silicon gate
power field effect transistors. They are advanced power
MOSFETs designed, tested, and guaranteed to withstand a
specified level of energy in the breakdown avalanche mode
of operation. All of these power MOSFETs are designed for
applications such as switching regulators, switching conver-
tors, motor drivers, relay drivers, and drivers for high power
bipolar switching transistors requiring high speed and low
gate drive power. These types can be operated directly from
integrated circuits.
Formerly developmental type TA17412.
October 1997
Features
• 8.0A and 9.0A, 150V and 200V
• r
DS(ON)
= 0.4Ω and 0.6Ω
• Single Pulse Avalanche Energy Rated
• SOA is Power Dissipation Limited
• Nanosecond Switching Speeds
• Linear Transfer Characteristics
• High Input Impedance
• Related Literature
- TB334 “Guidelines for Soldering Surface Mount
Components to PC Boards”
Symbol
D
Ordering Information
PART NUMBER
IRF230
IRF231
IRF232
IRF233
PACKAGE
TO-204AA
TO-204AA
TO-204AA
TO-204AA
BRAND
IRF230
IRF231
IRF232
IRF233
G
S
NOTE: When ordering, use the entire part number.
Packaging
JEDEC TO-204AA
DRAIN
(FLANGE)
SOURCE (PIN 2)
GATE (PIN 1)
CAUTION: These devices are sensitive to electrostatic discharge. Users should follow proper ESD Handling Procedures.
Copyright
©
Harris Corporation 1997
File Number
1568.2
1

IRF230 Related Products

IRF230 IRF231 IRF232 IRF233
Description 9A, 200V, 0.4ohm, N-CHANNEL, Si, POWER, MOSFET, TO-204AA 9A, 150V, 0.4ohm, N-CHANNEL, Si, POWER, MOSFET, TO-204AA 8A, 200V, 0.6ohm, N-CHANNEL, Si, POWER, MOSFET, TO-204AA 8A, 150V, 0.6ohm, N-CHANNEL, Si, POWER, MOSFET, TO-204AA
Is it Rohs certified? incompatible incompatible incompatible incompatible
Maker Renesas Electronics Corporation Renesas Electronics Corporation Renesas Electronics Corporation Renesas Electronics Corporation
Reach Compliance Code not_compliant not_compliant not_compliant not_compliant
ECCN code EAR99 EAR99 EAR99 EAR99
Shell connection DRAIN DRAIN DRAIN DRAIN
Configuration SINGLE WITH BUILT-IN DIODE SINGLE WITH BUILT-IN DIODE SINGLE WITH BUILT-IN DIODE SINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage 200 V 150 V 200 V 150 V
Maximum drain current (Abs) (ID) 9 A 9 A 8 A 8 A
Maximum drain current (ID) 9 A 9 A 8 A 8 A
Maximum drain-source on-resistance 0.4 Ω 0.4 Ω 0.6 Ω 0.6 Ω
FET technology METAL-OXIDE SEMICONDUCTOR METAL-OXIDE SEMICONDUCTOR METAL-OXIDE SEMICONDUCTOR METAL-OXIDE SEMICONDUCTOR
JEDEC-95 code TO-204AA TO-204AA TO-204AA TO-204AA
JESD-30 code O-MBFM-P2 O-MBFM-P2 O-MBFM-P2 O-MBFM-P2
JESD-609 code e0 e0 e0 e0
Number of components 1 1 1 1
Number of terminals 2 2 2 2
Operating mode ENHANCEMENT MODE ENHANCEMENT MODE ENHANCEMENT MODE ENHANCEMENT MODE
Maximum operating temperature 150 °C 150 °C 150 °C 150 °C
Package body material METAL METAL METAL METAL
Package shape ROUND ROUND ROUND ROUND
Package form FLANGE MOUNT FLANGE MOUNT FLANGE MOUNT FLANGE MOUNT
Peak Reflow Temperature (Celsius) NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
Polarity/channel type N-CHANNEL N-CHANNEL N-CHANNEL N-CHANNEL
Maximum power consumption environment 75 W 75 W 75 W 75 W
Maximum power dissipation(Abs) 75 W 75 W 75 W 75 W
Maximum pulsed drain current (IDM) 36 A 36 A 32 A 32 A
Certification status Not Qualified Not Qualified Not Qualified Not Qualified
surface mount NO NO NO NO
Terminal surface Tin/Lead (Sn/Pb) Tin/Lead (Sn/Pb) Tin/Lead (Sn/Pb) Tin/Lead (Sn/Pb)
Terminal form PIN/PEG PIN/PEG PIN/PEG PIN/PEG
Terminal location BOTTOM BOTTOM BOTTOM BOTTOM
Maximum time at peak reflow temperature NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
transistor applications SWITCHING SWITCHING SWITCHING SWITCHING
Transistor component materials SILICON SILICON SILICON SILICON
Maximum off time (toff) 90 ns 90 ns 90 ns 90 ns
Maximum opening time (tons) 80 ns 80 ns 80 ns 80 ns
