2-284508-5 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> terminals> 2-284508-5

Preview

2-284508-5: Description12A, STRIP TERMINAL BLOCK, 1 ROW, 1 DECK; CategoryThe connector terminals; File Size47KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

2-284508-5 Overview

12A, STRIP TERMINAL BLOCK, 1 ROW, 1 DECK

2-284508-5 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	unknow
ECCN code	EAR99
Other features	POLARIZATION AVAILABLE
Fastening method	SCREW
Manufacturer's serial number	284508
Installation type	CABLE
Number of layers	1
Rows	1
Number of channels	25
Rated current	12 A
Rated voltage	150 V
safety certificate	UL
Terminal and terminal strip types	STRIP TERMINAL BLOCK
Wire gauge	14 AWG
Base Number Matches	1

Preview

Download Datasheet

View All

2-284508-5 Related Products

	2-284508-5	2-284508-3	284508-3	RIAN14TTEB2701DCDT	RIAN14TTEB272JHDY	RIAN14TTEB272JTDC	RIAN16LTE2202BHDE	RIAN16LTE2202BHGY	RIAN16LTE2202BTDT
Description	12A, STRIP TERMINAL BLOCK, 1 ROW, 1 DECK	12A, STRIP TERMINAL BLOCK, 1 ROW, 1 DECK	12A, STRIP TERMINAL BLOCK, 1 ROW, 1 DECK	Array/Network Resistor, Isolated, Thin Film, 0.6W, 2700ohm, 100V, 0.5% +/-Tol, -50,50ppm/Cel, 3415,	Array/Network Resistor, Isolated, Thin Film, 0.6W, 2700ohm, 100V, 5% +/-Tol, -100,100ppm/Cel, 3415,	Array/Network Resistor, Isolated, Thin Film, 0.6W, 2700ohm, 100V, 5% +/-Tol, -10,10ppm/Cel, 3415,	Array/Network Resistor, Isolated, Thin Film, 0.05W, 22000ohm, 100V, 0.1% +/-Tol, -100,100ppm/Cel, 3915,	Array/Network Resistor, Isolated, Thin Film, 0.05W, 22000ohm, 100V, 0.1% +/-Tol, -100,100ppm/Cel, 3915,	Array/Network Resistor, Isolated, Thin Film, 0.05W, 22000ohm, 100V, 0.1% +/-Tol, -10,10ppm/Cel, 3915,
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	incompatible	incompatible	incompatible
Reach Compliance Code	unknow	unknow	unknow	compliant	compliant	compliant	not_compliant	not_compliant	not_compliant
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Objectid	-	-	-	734951096	734952105	734952126	757570098	757570108	757570123
YTEOL	-	-	-	6.35	6.35	6.35	4.73	4.73	4.73
structure	-	-	-	Rectangular	Rectangular	Rectangular	Molded	Molded	Molded
JESD-609 code	-	-	-	e3	e3	e3	e0	e0	e0
Network Type	-	-	-	Isolated	Isolated	Isolated	Isolated	Isolated	Isolated
Number of terminals	-	-	-	14	14	14	16	16	16
Maximum operating temperature	-	-	-	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C
Minimum operating temperature	-	-	-	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C
Package height	-	-	-	1.6 mm	1.6 mm	1.6 mm	1.6 mm	1.6 mm	1.6 mm
Package length	-	-	-	8.66 mm	8.66 mm	8.66 mm	9.91 mm	9.91 mm	9.91 mm
Package form	-	-	-	SMT	SMT	SMT	SMT	SMT	SMT
Package width	-	-	-	3.81 mm	3.81 mm	3.81 mm	3.81 mm	3.81 mm	3.81 mm
method of packing	-	-	-	TR, 13 Inch	TR, 13 Inch	TR, 13 Inch	Tape, Embossed/Plastic	Tape, Embossed/Plastic	Tape, Embossed/Plastic
Rated power dissipation(P)	-	-	-	0.6 W	0.6 W	0.6 W	0.05 W	0.05 W	0.05 W
resistance	-	-	-	2700 Ω	2700 Ω	2700 Ω	22000 Ω	22000 Ω	22000 Ω
Resistor type	-	-	-	ARRAY/NETWORK RESISTOR	ARRAY/NETWORK RESISTOR	ARRAY/NETWORK RESISTOR	ARRAY/NETWORK RESISTOR	ARRAY/NETWORK RESISTOR	ARRAY/NETWORK RESISTOR
series	-	-	-	R(X)A	R(X)A	R(X)A	KPC	KPC	KPC
size code	-	-	-	3415	3415	3415	3915	3915	3915
technology	-	-	-	THIN FILM	THIN FILM	THIN FILM	THIN FILM	THIN FILM	THIN FILM
Temperature Coefficient	-	-	-	50 ppm/°C	100 ppm/°C	10 ppm/°C	100 ppm/°C	100 ppm/°C	10 ppm/°C
Terminal surface	-	-	-	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Tolerance	-	-	-	0.5%	5%	5%	0.1%	0.1%	0.1%
Operating Voltage	-	-	-	100 V	100 V	100 V	100 V	100 V	100 V
