Document 196-1
SMT Power Inductors - DO3316H Series
• Soldered self-leaded construction for excellent solderability.
• Very low DCR values and excellent current handling
Designer’s Kit C326
contains 3 of each part
Core material
Ferrite
Core and winding loss
See www.coilcraft.com/coreloss
Terminations
RoHS compliant tin-silver-copper over copper. Other
terminations available at additional cost.
Weight
0.95 – 1.25 g
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+125°C with derated current
Storage temperature
Component: –40°C to +125°C.
Packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
750 per 13″ reel Plastic tape: 24 mm wide,
0.35 mm thick, 12 mm pocket spacing, 6.4 mm pocket depth
PCB washing
Only pure water or alcohol recommended
1
Part
L
number
1
(µH)
DO3316H-121ML_ 0.12
DO3316H-331ML_ 0.33
DO3316H-681ML_ 0.68
DO3316H-102ML_ 1.0
DO3316H-152ML_ 1.5
DO3316H-222ML_ 2.2
DO3316H-272ML_ 2.7
DO3316H-332ML_ 3.3
DO3316H-392ML_ 3.9
DO3316H-472ML_ 4.7
±20%
2
DCR
SRF
3
max
typ
Isat
4
(Ohms) (MHz) (A)
0.0015 200
28
0.002
200
20
0.005
200
13
0.006
100
11
0.008
90
9.0
0.011
80
7.8
0.012
65
7.0
0.014
60
6.4
0.015
50
5.9
0.018
45
5.4
1. When ordering, please specify
termination
and
packaging
codes:
Irms
5
(A)
17
16
12
10
9.0
7.4
6.6
5.9
5.3
4.8
DO3316H-472MLD
Termination: L
= RoHS compliant tin-silver over copper.
Special order: T
= RoHS tin-silver-copper (95.5/4/0.5)
or
S
= non-RoHS tin-lead (63/37).
Packaging: D
= 13″ machine-ready reel. EIA-481 embossed plastic
tape, 750 parts per full reel.
B
= Less than full reel. In tape, but not machine-ready.
To have a leader and trailer added ($25 charge), use
code letter D instead.
2. Inductance tested at 100 kHz, 0.1 Vrms, 0 Adc using an Agilent/HP
4263B LCR meter or equivalent.
3. SRF measured using Agilent/HP 8753D network analyzer.
4. DC current at which the inductance drops 10% (typ) from its value
without current.
5. Current that causes a 40°C temperature rise from 25°C ambient.
6. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Specifications subject to change without notice.
Please check our website for latest information.
Document 196-1
Revised 05/04/09
© Coilcraft, Inc. 2009
