DTC114WE/DTC114WUA/DTC114WKA
DTC114WCA/TC114WSA
NPN Digital Transistors (Built-in Resistors)
FEATURES
* Built-in bias resistors enable the configuration of
an inverter circuit without connecting input resistors
(see equivalent circuit).
* Only the on/off confitions need to be set for operation,
making device design easy.
* The bias resistors consis of thin-film resistors with
compete isolation to allow negative biasing of the
input. They also have the advantage of almost
completely eliminating parasitic effects.
PIN CONNENCTIONS AND MARKING
DTC114WE
DTC114WUA
SOT-523
Abbreviated symbol: 84
SOT-323
Abbreviated symbol: 84
DTC114WKA
DTA114ECA
DTC114WCA
SOT-23
SOT-23-3L
Abbreviated symbol: 84
SOT-23
Abbreviated symbol: 84
DTC114WSA
TO-92S
http://www.SeCoSGmbH.com
l
Any changing of specification will not be informed individua
01-Jun-2002 Rev. A
Page 1 of 2
Elektronische Bauelemente
DTC114WE/DTC114WUA/DTC114WKA
DTC114WCA/TC114WSA
NPN Digital Transistors (Built-in Resistors)
Absolute maximum ratings (Ta=25℃)
Parameter
Supply voltage
Input voltage
Output current
Power dissipation
Junction
temperature
Storage temperature
Parameter
Input voltage
Output voltage
Input current
Output current
DC current gain
Input resistance
Resistance ratio
Transition frequency
Symbol
V
CC
V
IN
I
O
I
C(MAX)
Pd
Tj
Tstg
Symbol
V
I(off)
V
I(on)
V
O(on)
I
I
I
O(off)
G
I
R
1
R
2
/R
1
f
T
24
7
0.37
3
Min.
Limits (DTC114W
E
UA
CA
50
-10~30
100
100
150
200
150
-55~150
Typ
Max.
0.8
0.1
0.3
0.88
0.5
10
0.47
250
13
0.57
MHz
Unit
V
V
mA
µA
KΩ
)
KA
SA
Unit
V
V
mA
300
mW
℃
℃
Electrical characteristics (Ta=25℃)
Conditions
V
CC
=5V ,I
O
=100µA
V
O
=0.3V ,I
O
=2
mA
I
O
/I
I
=10mA/0.5mA
V
I
=5V
V
CC
=50V, V
I
=0
V
O
=5V, I
O
=10mA
V
O
=10V, I
O
=5mA, f=100MHz
http://www.SeCoSGmbH.com
Any changing of specification will not be informed individua
01-Jun-2002 Rev. A
Page 2 of 2
