CSPLTRK-212.500 datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> CSPLTRK-212.500

CSPLTRK-212.500: DescriptionPECL Output Clock Oscillator, 150MHz Min, 700MHz Max, 212.5MHz Nom, ROHS COMPLIANT, CERAMIC, SMD, 6 PIN; CategoryPassive components oscillator; File Size54KB，3 Pages; ManufacturerRaltron; Websitehttp://www.raltron.com/; Environmental Compliance

Download Datasheet Parametric View All

CSPLTRK-212.500 Overview

PECL Output Clock Oscillator, 150MHz Min, 700MHz Max, 212.5MHz Nom, ROHS COMPLIANT, CERAMIC, SMD, 6 PIN

CSPLTRK-212.500 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Raltron
package instruction	DILCC6,.2
Reach Compliance Code	compliant
Other features	45/55 SYMMETRY ALSO AVAILABLE; TRI-STATE ENABLE/DISABLE FUNCTION
maximum descent time	1 ns
Frequency Adjustment - Mechanical	NO
frequency stability	20%
JESD-609 code	e4
Manufacturer's serial number	CSPL
Installation features	SURFACE MOUNT
Number of terminals	6
Maximum operating frequency	700 MHz
Minimum operating frequency	150 MHz
Nominal operating frequency	212.5 MHz
Maximum operating temperature	50 °C
Minimum operating temperature
Oscillator type	PECL
Output load	50 OHM
Package body material	CERAMIC
Encapsulate equivalent code	DILCC6,.2
physical size	7.0mm x 5.0mm x 2.0mm
power supply	2.5 V
Certification status	Not Qualified
longest rise time	1 ns
Maximum slew rate	80 mA
Maximum supply voltage	2.625 V
Minimum supply voltage	2.375 V
Nominal supply voltage	2.5 V
surface mount	YES
maximum symmetry	55/45 %
Terminal surface	Gold (Au)

Preview

Download Datasheet

View All

CLOCK

Page 1 of 3

CS9L/CSPL SERIES: ULTRA HF CLOCK OSCILLATOR, PECL, +3.3 VDC or +2.5VDC

DESCRIPTION: A crystal controlled, high frequency, highly stable oscillator, adhering to Positive Emitter

Coupled Logic (PECL) Standards and fundamental crystal or analog multiplication technologies. The output can

be Tri-stated to facilitate testing or combined multiple clocks. The device is contained in a sub-miniature, very low

profile, leadless ceramic SMD package with 6 gold contact pads. This miniature oscillator is ideal for today's

automated assembly environments.

APPLICATIONS AND FEATURES:

Infiniband; Fiber Channel; SATA; 10GbE; Network Processors; SOHO Routing; Switches;

Common Frequencies: 150 MHz; 156.25 MHz; 155.52 MHz; 161.1328 MHz; 212.5MHz; 312.5MHz

+3.3 VDC or +2.5VDC PECL

Frequency Range from 150.000 to 700 MHz

Analog multiplication

Miniature Ceramic SMD Package Available on Tape and Reel

Lead Free and ROHS Compliant

ABSOLUTE MAXIMUM RATINGS:

PARAMETER

SYMBOL

T(stg)

Vcc

SYMBO

Vcc

Connected between each output and Vcc – 2.0 VDC

min

max

Measured at 50% of Vcc

Measured at 20/80% and 80/20% Vcc Levels

Integrated Phase tji RMS, Fj = 12 kHz…20 MHz

Integrated Phase RMS tii offset frequency 50KHz to

80MHz

Fo<320MHz.

Deterministic period Jitter Dj using

wavecrest analyzer

Fo>320MHz.

Fo<320MHz.

Random period Jitter Rj using

wavecrest analyzer

Fo>320MHz.

Fo<320MHz.

Acumm. Peak to Peak Jitter Tp-p

using wavecrest analyzer

Fo>320MHz.

∆f=10

∆f=100

∆f=1

KHz

typ. @212.5MHz

∆f=10

KHz

∆f=100

KHz

∆f>1M

Fo<320MHz.

Load, nom, Supply nom

Fo>320MHz.

Op. Temp., Aging, Load, Supply and Cal. Variations

High Voltage or No Connect

Ground

VALUE

-40…+85

-55…+90

+4.6

Vss-0.5…Vcc+0.5

UNIT

°C

VDC

Operating temperature range

Storage temperature range

Supply voltage

Maximum Input Voltage

Maximum Output Voltage

ELECTRICAL PARAMETERS:

PARAMETER

TEST CONDITIONS

VALUE

150.000 ~ 700.00**

+3.3 or +2.5

±5%

80.0 MAX

PECL

Voh

Vol

tr / tf

Vcc-1.025

Vcc-1.620

40/60 to 60/40 or 45/55 to 55/45

0.7 TYP 1.0 MAX

0.3 TYP**

0.5 TYP**

1 TYP **

8 TYP **

2.5 TYP **

2.5 TYP**

25 TYP**

27 TYP**

-65

-95

-125

-140

-145

-148

-50

-35

±20, ±25, ±50,

±100

MAX

0.7•Vcc MIN

0.3•Vcc MAX

Ω

VDC

dBc/Hz

dBc

ppm

VDC

UNIT

MHz

VDC

Nominal Frequency

Supply Voltage

Supply Current

Output Logic Type

Load

Output Voltage Levels

Duty Cycle

Rise / Fall Time

Jitter

Phase Noise

£(∆f)

Sub Harmonics

Overall Frequency Stability

Pin 1

Output Enabled

Output Disabled

f_sub

∆f/fc

Dis

RALTRON ELECTRONICS CORP.

10651 N.W . 19

Miami, Florida 33172

U.S.A.

phone: (305) 593-6033

fax: (305) 594-3973

e-mail: sales@raltron.com

WEB: http://www.raltron.com
