CY7C1442AV25-250BZI datasheet, PDF

Datasheet> All Categories > storage> storage> CY7C1442AV25-250BZI

CY7C1442AV25-250BZI: DescriptionCache SRAM, 2MX18, 2.6ns, CMOS, PBGA165, 15 X 17 MM, 1.40 MM HEIGHT, FBGA-165; Categorystorage storage; File Size4MB，32 Pages; ManufacturerCypress Semiconductor

Download Datasheet Parametric View All

CY7C1442AV25-250BZI Overview

Cache SRAM, 2MX18, 2.6ns, CMOS, PBGA165, 15 X 17 MM, 1.40 MM HEIGHT, FBGA-165

CY7C1442AV25-250BZI Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Cypress Semiconductor
Parts packaging code	BGA
package instruction	LBGA, BGA165,11X15,40
Contacts	165
Reach Compliance Code	compliant
ECCN code	3A991.B.2.A
Maximum access time	2.6 ns
Other features	PIPELINED ARCHITECTURE
Maximum clock frequency (fCLK)	250 MHz
I/O type	COMMON
JESD-30 code	R-PBGA-B165
JESD-609 code	e0
length	17 mm
memory density	37748736 bit
Memory IC Type	CACHE SRAM
memory width	18
Humidity sensitivity level	3
Number of functions	1
Number of terminals	165
word count	2097152 words
character code	2000000
Operating mode	SYNCHRONOUS
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
organize	2MX18
Output characteristics	3-STATE
Exportable	YES
Package body material	PLASTIC/EPOXY
encapsulated code	LBGA
Encapsulate equivalent code	BGA165,11X15,40
Package shape	RECTANGULAR
Package form	GRID ARRAY, LOW PROFILE
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Celsius)	220
power supply	1.8/2.5,2.5 V
Certification status	Not Qualified
Maximum seat height	1.4 mm
Maximum standby current	0.12 A
Minimum standby current	2.375 V
Maximum slew rate	0.435 mA
Maximum supply voltage (Vsup)	2.625 V
Minimum supply voltage (Vsup)	2.375 V
Nominal supply voltage (Vsup)	2.5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	BALL
Terminal pitch	1 mm
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
width	15 mm

Preview

Download Datasheet

View All

CY7C1440AV25

CY7C1442AV25

CY7C1446AV25

36-Mbit (1M x 36/2M x 18/512K x 72)

Pipelined Sync SRAM

Features

• Supports bus operation up to 250 MHz

• Available speed grades are 250, 200 and 167 MHz

• Registered inputs and outputs for pipelined operation

• 2.5V core power supply

• 2.5V/1.8V I/O powersupply

• Fast clock-to-output times

— 2.6 ns (for 250-MHz device)

• Provide high-performance 3-1-1-1 access rate

•

User-selectable burst counter supporting Intel

Pentium

interleaved or linear burst sequences

• Separate processor and controller address strobes

• Synchronous self-timed writes

• Asynchronous output enable

• Single-cycle Chip Deselect

• CY7C1440AV25, CY7C1442AV25 available in

JEDEC-standard lead-free 100-pin TQFP package,

lead-free and non-lead-free 165-ball FBGA package.

CY7C1446AV25 available in lead-free and non-lead- free

209-ball FBGA package

• IEEE 1149.1 JTAG-Compatible Boundary Scan

• “ZZ” Sleep Mode Option

Functional Description

[1]

The CY7C1440AV25/CY7C1442AV25/CY7C1446AV25 SRAM

integrates 1M x 36/2M x 18/512K x 72 SRAM cells with

advanced synchronous peripheral circuitry and a two-bit

counter for internal burst operation. All synchronous inputs are

gated by registers controlled by a positive-edge-triggered

Clock Input (CLK). The synchronous inputs include all

addresses, all data inputs, address-pipelining Chip Enable

(CE

), depth-expansion Chip Enables (CE

and CE

), Burst

Control inputs (ADSC, ADSP, and ADV), Write Enables (BW

and BWE), and Global Write (GW). Asynchronous inputs

include the Output Enable (OE) and the ZZ pin.

Addresses and chip enables are registered at rising edge of

clock when either Address Strobe Processor (ADSP) or

Address Strobe Controller (ADSC) are active. Subsequent

burst addresses can be internally generated as controlled by

the Advance pin (ADV).

Address, data inputs, and write controls are registered on-chip

to initiate a self-timed Write cycle.This part supports Byte Write

operations (see Pin Descriptions and Truth Table for further

details). Write cycles can be one to two or four bytes wide as

controlled by the byte write control inputs. GW when active

LOW causes all bytes to be written.

The

CY7C1440AV25/CY7C1442AV25/CY7C1446AV25

operates from a +2.5V core power supply while all outputs

may operate with a +2.5V/1.8V supply. All inputs and outputs

are JEDEC-standard JESD8-5-compatible.

Selection Guide

250 MHz

Maximum Access Time

Maximum Operating Current

Maximum CMOS Standby Current

2.6

435

120

200 MHz

3.2

385

120

167 MHz

3.4

335

120

Unit

Notes:

1. For best-practices recommendations, please refer to the Cypress application note

System Design Guidelines

on www.cypress.com.

Cypress Semiconductor Corporation

Document #: 38-05350 Rev. *E

•

198 Champion Court

•

San Jose

CA 95134-1709

•

408-943-2600

Revised June 21, 2006
