KUIP-14D55-12: DescriptionPOWER/SIGNAL RELAY, 3PDT, MOMENTARY, 0.1A (COIL), 12VDC (COIL), 1200mW (COIL), 10A (CONTACT), 28VDC (CONTACT), PANEL MOUNT, ROHS COMPLIANT; CategoryMechanical and electronic products relay; File Size98KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

KUIP-14D55-12 Overview

POWER/SIGNAL RELAY, 3PDT, MOMENTARY, 0.1A (COIL), 12VDC (COIL), 1200mW (COIL), 10A (CONTACT), 28VDC (CONTACT), PANEL MOUNT, ROHS COMPLIANT

KUIP-14D55-12 Parametric

Parameter Name	Attribute value
Maker	TE Connectivity
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
body width	35.7 mm
body height	48.4 mm
Body length or diameter	38.9 mm
Maximum coil current (DC)	0.1 A
Coil operating voltage (DC)	9 V
Coil power	1200 mW
Coil resistance	120 Ω
Maximum coil voltage (DC)	12 V
Coil/Input Power Type	DC
Contact (AC) maximum rated R load	10A@120VAC
Maximum contact current (AC)	10 A
Maximum contact current (DC)	10 A
Contact (DC) maximum rated R load	10A@28VDC
Maximum contact voltage (AC)	120 V
Maximum contact voltage (DC)	28 V
Contact/Output Power Type	AC/DC
Electrical life	100000 Cycle(s)
Manufacturer's serial number	KUIP
Installation features	PANEL MOUNT
operating hours	15 ms
Maximum operating temperature	95 °C
Minimum operating temperature	-45 °C
physical size	38.9mm X 35.7mm X 48.4mm
Guideline	CSA; UL
Relay action	MOMENTARY
Relay function	3PDT
Relay type	POWER/SIGNAL RELAY
release time	10 ms
seal	DUST PROOF
surface mount	NO
Termination type	QUICK CONNECT

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Relays

Product Feature Selector

> Product Details

KUIP-14D55-12 Product Details

Product Photo

Industrial Relays (General Purpose)

C onve rte d to EU R oHS but not ELV C om plia nt

(

Sta te m e nt of

C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

KUIP-14D55-12

(1-1393115-8)

T E I nternal N umber: 1 - 1 3 9 3 1 1 5 - 8

Product Highlights:

KUIP Series

C ontact Arrangement = 3 Form C , 3PDT, 3 C /O

C ontact C urrent Rating = 10 Amps.

Monostable C oil Magnetic System

Without C oil Suppression Diode

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Obsolete

C ontact Product Information C enter

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

KU KUP Enclosed Relay KUIP 8mm C oil to C ontacts KUGP...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Termination Type

= .187 x .020 Quick C onnect Terminals

Electrical Characteristics:

C ontact C urrent Rating (Amps.)

= 10

C oil Resistance (?)

= 120

Actuating System

= DC

C oil Power, Nominal (W)

= 1.20

Input Voltage (VDC )

= 12

Body Related Features:

Series

= KUIP

Polarized = No

C oil To C ontact Gap (mm [in]) = 8 [0.315]

Contact Related Features:

Mounting Options

= Bracket Mount C ase

Enclosure

= Enclosed

FC C Part 68 Isolation = No

Relay Type = General

C ontact Base Material

= Silver C admium Oxide

Approx. Dimensions (L x W x H) (mm [in]) = 38.90 x 35.70 x 48.40

[1.532 x 1.406 x 1.907]

Wiring Diagram = 3 Form C

Approved Standards = UL Recognized, C SA C ertified

Configuration Related Features:

C ontact Arrangement

= 3 Form C , 3PDT, 3 C /O

C oil Magnetic System

= Monostable

C oil Suppression Diode

= Without

C oil Selection C riteria

= Nominal Voltage

C oil Latching = Without

Status Indicator = None

Industry Standards:

RoHS/ELV C ompliance

= RoHS/Not ELV C ompliant

Lead Free Solder Processes

= Not relevant for lead free process

RoHS/ELV C ompliance History = C onverted to comply with RoHS not

ELV directives

Other:

Brand = Potter & Brumfield

Additional Information:

Product Line Information

Additional Product Images:

Schematic

PC B Layout

Wiring Diagram

Front View

KUIP-14D55-12 Related Products

	KUIP-14D55-12	1-1393115-8
Description	POWER/SIGNAL RELAY, 3PDT, MOMENTARY, 0.1A (COIL), 12VDC (COIL), 1200mW (COIL), 10A (CONTACT), 28VDC (CONTACT), PANEL MOUNT, ROHS COMPLIANT	POWER/SIGNAL RELAY, 3PDT, MOMENTARY, 0.1A (COIL), 12VDC (COIL), 1200mW (COIL), 10A (CONTACT), PANEL MOUNT, ROHS COMPLIANT
package instruction	ROHS COMPLIANT	ROHS COMPLIANT
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
body width	35.7 mm	35.7 mm
body height	48.4 mm	48.4 mm
Body length or diameter	38.9 mm	38.9 mm
Maximum coil current (DC)	0.1 A	0.1 A
Coil power	1200 mW	1200 mW
Coil resistance	120 Ω	120 Ω
Maximum coil voltage (DC)	12 V	12 V
Coil/Input Power Type	DC	DC
Maximum contact current (AC)	10 A	10 A
Maximum contact current (DC)	10 A	10 A
Contact/Output Power Type	AC/DC	AC/DC
Manufacturer's serial number	KUIP	1393115
Installation features	PANEL MOUNT	PANEL MOUNT
physical size	38.9mm X 35.7mm X 48.4mm	38.9mm X 35.7mm X 48.4mm
Guideline	CSA; UL	CSA; UL
Relay action	MOMENTARY	MOMENTARY
Relay function	3PDT	3PDT
Relay type	POWER/SIGNAL RELAY	POWER/SIGNAL RELAY
surface mount	NO	NO
Termination type	QUICK CONNECT	QUICK CONNECT
