(Half-wave pulse of sine wave: 11 ms; detection time: 10
µs.)
Min. 980 m/s
2
(Half-wave pulse of sine wave: 6 ms.)
Expected life
Electrical
Inductive load
10 to 55 Hz at double amplitude of 1.0 mm (Detection time: 10
µs.)
10 to 55 Hz at double amplitude of 1.5 mm
Min. 10
6
(at 180 times/min.)
Min. 3×10
4
(35 A 250 V AC) (ON : OFF = 1s : 9s) Min. 3×10
4
(48 A 250 V AC) (ON : OFF = 1s : 9s)
Endurance: 48 A 250 V AC (cos
φ
= 0.8),
Min. 3×10
4
(ON : OFF = 0.1s : 10s)
—
Overload: 72 A 250 V AC (cos
φ
= 0.8),
Min. 50 (ON : OFF = 0.1s : 10s)
Ambient temperature:
–50 to +55°C
–58 to +131°F
(When nominal coil voltage applied)
–50 to +85°C
–58 to +185°F
(When applied coil hold voltage is 50% to 60% of nominal coil voltage)
Humidity: 5 to 85% R.H. (Not freezing and condensing at low temperature);
Atmospheric pressure: 86 to 106 kPa
6 times/min. (at nominal switching capacity ON : OFF = 1s : 9s)
Approx. 80 g
2.82 oz
Conditions
Conditions for operation, transport and
storage*
4
Max. operating speed
Unit weight
Notes: *1. This value can change due to the switching frequency, environmental conditions, and desired reliability level, therefore it is recommended to check this with the
actual load.
*2. Wave is standard shock voltage of
±1.2×50µs
according to JEC-212-1981
*3. Coil hold voltage is the coil voltage after 100 ms following application of the nominal coil voltage.
*4. The upper operation ambient temperature limit is the maximum temperature that can satisfy the coil temperature rise value. Refer to Usage, transport and storage
conditions in NOTES.
*5. Release time will lengthen if a diode, etc., is connected in parallel to the coil. Be sure to verify operation under actual conditions.
