TRIPLE-BALANCED MIXER
SURFACE MOUNT MODEL:
STM-3500
WIDE BANDWIDTH
FEATURES:
►
High Performance
►
High Interport Isolation
►
Broad Bandwidth IF
Conversion Loss (dB)
0
1
2
3
4
5
6
7
8
9
10
11
12
1
361
721
1081
1441
1801
2161
Frequency (MHz)
IF=50 MHz (LO>RF)
2521
2881
3241
3601
1-3500 MHz
APPLICATIONS:
►Narrow
Band & Broadband
Up/Down Conversion
SPECIFICATIONS
Frequency (MHz)
LO/RF
1 - 3500
Freq (MHz)
1 - 100
100 - 1750
1750 - 3500
Typ.
42
Isolation (dB)
Typ.
42
Typ.
27
LO Power
1
1 dB Compression Point
Input IP
3
IF
1 - 3500
Typ.
7.5
8.5
9.5
LO/RF
Max.
9.0
9.5
10.5
Min.
30
Min.
30
Min.
20
Package #
357
Conversion Loss (dB)
LO/IF
RF/IF
+15 to +23 dBm (Nom.)
+14 dBm (Typ.)
+22 dBm (Typ.)
1
PORT CONFIGURATION
RF
8
LO
4
IF
6
GND
All Other
Impedance
Operating Temperature
Range
1
50 Ohms (Nom.)
-40 to +85 °C
Typical measurements made with LO at +15 dBm
Copyright © Synergy Microwave Corporation
201 McLean Boulevard • Paterson, New Jersey 07504 • Tel: (973) 881-8800 • Fax: (973) 881-8361
E-Mail: sales@synergymwave.com • World Wide Web: http://www.synergymwave.com
[ 1 of 5 ]
TRIPLE-BALANCED MIXER
SURFACE MOUNT MODEL:
STM-3500
WIDE BANDWIDTH
1-3500 MHz
0
PERFORMANCE PLOTS
1
2
3
Conversion Loss (dB)
4
5
6
7
8
9
10
11
12
500
1000
1500
2000
Frequency (MHz)
2500
3000
3500
IF=500 MHz (LO>RF)
0
1
2
3
Conversion Loss (dB)
4
5
6
7
8
9
10
11
12
1
401
801
1201
Frequency (MHz)
IF=2000 MHz (LO>RF)
1601
2001
Copyright © Synergy Microwave Corporation
201 McLean Boulevard • Paterson, New Jersey 07504 • Tel: (973) 881-8800 • Fax: (973) 881-8361
E-Mail: sales@synergymwave.com • World Wide Web: http://www.synergymwave.com
[ 2 of 5 ]
TRIPLE-BALANCED MIXER
SURFACE MOUNT MODEL:
STM-3500
WIDE BANDWIDTH
1-3500 MHz
0
PERFORMANCE PLOTS
5
10
15
Isolation (dB)
20
25
30
35
40
45
50
55
1
361
721
1081
1441
1801
2161
Frequency (MHz)
LO-IF
LO-RF
2521
2881
3241
3601
0
5
10
15
Isolation (dB)
20
25
30
35
40
45
1
361
721
1081
1441
1801
2161
Frequency (MHz)
RF-IF
2521
2881
3241
3601
Copyright © Synergy Microwave Corporation
201 McLean Boulevard • Paterson, New Jersey 07504 • Tel: (973) 881-8800 • Fax: (973) 881-8361
E-Mail: sales@synergymwave.com • World Wide Web: http://www.synergymwave.com
[ 3 of 5 ]
TRIPLE-BALANCED MIXER
SURFACE MOUNT MODEL:
STM-3500
WIDE BANDWIDTH
1-3500 MHz
40
PERFORMANCE PLOTS
35
30
Input IP3 (dBm)
25
20
15
10
5
0
1
361
721
1081
1441
1801
2161
Frequency (MHz)
IF=50 MHz (LO>RF)
2521
2881
3241
3601
40
35
30
Input IP3 (dBm)
25
20
15
10
5
0
500
750
1000
1250
1500
1750 2000 2250
Frequency (MHz)
2500
2750
3000
3250
3500
IF=500 MHz (LO>RF)
Copyright © Synergy Microwave Corporation
201 McLean Boulevard • Paterson, New Jersey 07504 • Tel: (973) 881-8800 • Fax: (973) 881-8361
E-Mail: sales@synergymwave.com • World Wide Web: http://www.synergymwave.com
[ 4 of 5 ]
TRIPLE-BALANCED MIXER
SURFACE MOUNT MODEL:
STM-3500
WIDE BANDWIDTH
1-3500 MHz
40
PERFORMANCE PLOTS
35
30
Input IP3 (dBm)
25
20
15
10
5
0
1
201
401
601
801
1001
1201
Frequency (MHz)
IF=2000 MHz (LO>RF)
1401
1601
1801
2001
Copyright © Synergy Microwave Corporation
201 McLean Boulevard • Paterson, New Jersey 07504 • Tel: (973) 881-8800 • Fax: (973) 881-8361
E-Mail: sales@synergymwave.com • World Wide Web: http://www.synergymwave.com
[ 5 of 5 ]
