5STB17N5000: DescriptionTRIAC, 4200V V(RRM), 1800000mA I(T), 2670A I(T)RMS; CategoryAnalog mixed-signal IC Trigger device; File Size217KB，6 Pages; ManufacturerABB; Websitehttp://www.abb.com/

Download Datasheet Parametric Compare View All

5STB17N5000 Overview

TRIAC, 4200V V(RRM), 1800000mA I(T), 2670A I(T)RMS

5STB17N5000 Parametric

Parameter Name	Attribute value
Maker	ABB
Reach Compliance Code	compliant
Configuration	SINGLE
Maximum DC gate trigger current	400 mA
Maximum DC gate trigger voltage	2.6 V
Quick connection description	0
Description of screw terminals	0
Maximum holding current	250 mA
JESD-30 code	O-CEDB-X6
On-state non-repetitive peak current	31000 A
Number of components	1
Number of terminals	6
Maximum on-state current	1800000 A
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package body material	CERAMIC, METAL-SEALED COFIRED
Package shape	ROUND
Package form	DISK BUTTON
Certification status	Not Qualified
Maximum rms on-state current	2670 A
Repeated peak reverse voltage	4200 V
surface mount	YES
Terminal form	UNSPECIFIED
Terminal location	END
Trigger device type	TRIAC

Preview

Download Datasheet

View All

TAVM

TRMS

TSM

5200 V

1800 A

2830 A

29000 A

1.02 V

0.320 mΩ

Ω

Bi-Directional Control Thyristor

5STB 17N5200

Doc. No. 5SYA1036-03 Sep. 01

•

Two thyristors integrated into one wafer

•

Patented free-floating silicon technology

•

Designed for traction, energy and industrial applications

•

Optimum power handling capability

•

Interdigitated amplifying gate.

The electrical and thermal data are valid for one thyristor half of the device.

Blocking

Part Number

dV/dt

crit

is equal to V

up to T

= 110°C

5STB 17N5200

5200 V

4400 V

5STB 17N5000

5000 V

4200 V

≤

400 mA

≤

400 mA

2000 V/µs

5STB 17N4600

4600 V

4000 V

Conditions

f = 5 Hz, t

= 10ms

f = 50 Hz,t

= 10ms

= 125°C

@ Exp. to 0.67xV

Mechanical data

Mounting force

nom.

min.

max.

Acceleration

Device unclamped

Device clamped

Weight

Surface creepage distance

Air strike distance

50 m/s

100 m/s

2.9 kg

53 mm

22 mm

90 kN

81 kN

108 kN

ABB Semiconductors AG reserves the right to change specifications without notice.

5STB17N5000 Related Products

	5STB17N5000	5STB17N4600
Description	TRIAC, 4200V V(RRM), 1800000mA I(T), 2670A I(T)RMS	TRIAC, 4000V V(RRM), 1800000mA I(T), 2670A I(T)RMS
Maker	ABB	ABB
Reach Compliance Code	compliant	compliant
Configuration	SINGLE	SINGLE
Maximum DC gate trigger current	400 mA	400 mA
Maximum DC gate trigger voltage	2.6 V	2.6 V
Maximum holding current	250 mA	250 mA
JESD-30 code	O-CEDB-X6	O-CEDB-X6
On-state non-repetitive peak current	31000 A	31000 A
Number of components	1	1
Number of terminals	6	6
Maximum on-state current	1800000 A	1800000 A
Maximum operating temperature	125 °C	125 °C
Minimum operating temperature	-40 °C	-40 °C
Package body material	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED
Package shape	ROUND	ROUND
Package form	DISK BUTTON	DISK BUTTON
Certification status	Not Qualified	Not Qualified
Maximum rms on-state current	2670 A	2670 A
Repeated peak reverse voltage	4200 V	4000 V
surface mount	YES	YES
Terminal form	UNSPECIFIED	UNSPECIFIED
Terminal location	END	END
Trigger device type	TRIAC	TRIAC
