IA_P-1W Series
FIXED INPUT ISOLATED & REGULATED
1W OUTPUT DUAL OUTPUT
DIP PACKAGE
FEATURES
●
High Efficiency up to 73%
●
Dual Voltage Output
●
Small Footprint
●
DIP Package Style
●
Industry Standard Pinout
●
UL94-V0 Package
●
No Heat sink Required
●
1KVDC Isolation
●
Power Density 0.16W/cm
3
●
Temperature Range: -40°C~+85°C
●
No External Component Required
●
RoHS
Compliance
RoHS
multi-country patent protection
PRODUCT PROGRAM
Part
Number
IA0505P-1W
IA0509P-1W
IA0512P-1W
IA0515P-1W
IA1205P-1W
IA1209P-1W
IA1212P-1W
IA1215P-1W
IA2405P-1W
IA2409P-1W
IA2412P-1W
IA2415P-1W
Input
Voltage (VDC)
Nominal
Range
5
5
5
5
12
12
12
12
24
24
24
24
4.75~5.25
4.75~5.25
4.75~5.25
4.75~5.25
11.4~12.6
11.4~12.6
11.4~12.6
11.4~12.6
22.8~25.2
22.8~25.2
22.8~25.2
22.8~25.2
Output
Voltage Current (mA)
(VDC) Max
Min
±5
±9
±12
±15
±5
±9
±12
±15
±5
±9
±12
±15
±100
±56
±42
±33
±100
±56
±42
±33
±100
±56
±42
±33
±10
±6
±5
±4
±10
±6
±5
±4
±10
±6
±5
±4
Efficiency Package
(%, Typ)
Style
69
70
72
72
70
72
73
73
72
72
73
73
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
DIP
APPLICATIONS
The IA_P-1W Series are specially
designed for applications where a group
of polar power supplies are isolated from
the input power supply in a distributed
power supply system on a circuit board.
These products apply to:
1) Where the voltage of the input power
supply is fixed (voltage variation
≤±
5%);
2) Where isolation is necessary between
input and output (isolation voltage
=1000VDC);
3) Where the regulation of the output
voltage and the output ripple noise are not
demanded;
These products don’t apply to:
1) Where the input supply voltage varied
otherwise
our
(variation
≥±
5%),
company’s WRA series is recommended;
COMMON SPECIFICATIONS
Short circuit protection
Temperature rise at full load
Cooling
Operating temperature range
Storage temperature range
Lead temperature
Storage humidity range
Case material
MTBF
1 second
25
°
C MAX, 15
°
C TYP
Free air convection
-40
°
C
~
+85
°
C
-55
°
C
~
+125
°
C
300
°
C (1.5mm from case for 10 seconds)
≤
95%
Plastic (UL94-V0)
>3,500,000 hours
ISOLATION SPECIFICATIONS
MODEL SELECTION
IA0505P-1W
Rated Power
Package Style
Output Voltage
Input Voltage
Product Series
Item
Isolation voltage
Isolation resistance
Test conditions
Tested for 1 minute
Test at 500VDC
Min
1000
1000
Typ
Max
Units
VDC
MΩ
OUTPUT SPECIFICATIONS
Item
Output power
Line regulation
Load regulation
Output voltage accuracy
Temperature drift
Output ripple
Switching frequency
For Vin change of ±5%
10% to 100% full load
See tolerance envelope graph
100% full load
20MHz Bandwidth
Full load, nominal input
10
100
Test conditions
MIN
0.1
TYP
MAX
1
0.25
1
±3
0.03
15
Units
W
%
%
%
%/
°
C
mVp-p
KHz
MORNSUN Science& Technology Ltd.
Address:
8th floor 8th building, Hangzhou
Industrial District, Guangzhou, China
Tel: 86-20-38601850
Fax: 86-20-38601272
http://www.mornsun-power.com
Note:
1.All specifications measured at TA=25
°C
, humidity<75%, nominal input voltage and rated output load unless
otherwise specified.
2.See below recommended circuits for more details.
MORNSUN reserves the copyright
Edition: A
NOV-2005
Page 1 of 2
TYPICAL CHARACTERISTICS
Temperature Derating Graph
Vin
GND
C
L
L
DC DC
<Figure 1>
C
L
C
+Vo
0V
-Vo
Overload Protection
Operating Temp.(
C
)
PIN CONNECTIONS
Bottom View
1 2 3
1011
Pin
1,24
12,13
2,23
Vin
GND
-Vo
0V
+V0
Under normal operating conditions, the
output circuit of these products has no
protection against over-current and
short-circuits. The simplest method is to
connect a self-recovery fuse in series at
the input end or add a circuit breaker to
the circuit.
24 23 22
1514
10,15,3,22
11,14
OUTLINE DIMENSIONS& RECONMENDED FOOTPRINT DETAILS
31.80
0.50
20.30
24 23 22
1514
9.45
1 2 3
10 11 12
15.24
External Capacitor Table
2.00
27.94
2 x 2.54
4.00
V
in
5VDC
12VDC
24VDC
--
External
capacitor
4.7uF
2.2uF
1uF
--
V
out
5VDC
9VDC
12VDC
15VDC
External
capacitor
4.7uF
2.2uF
1uF
0.47uF
(Bottom View)
(Side View)
Note: All Pins on a 2.54mm pitch; all pin diameters are 0.50mm; all dimensions in mm.
APPLICATION NOTE
Filtering
In some circuits which are sensitive to noise and ripple, a filtering capacitor
may be added to the DC/DC output end and input end to reduce the noise and
ripple. However, the capacitance of the output filter capacitor must proper. If
the capacitance is too big, a startup problem might arise. For every channel of
output, providing the safe and reliable operation is ensured, the greatest
capacitance of its filter capacitor refer to the
External Capacitor Table.
To get
an extremely low ripple, an “LC” filtering network may be connected to the
input and output ends of the DC/DC converter, which may produce a more
significant filtering effect. It should also be noted that the inductance and the
frequency of the “LC” filtering network should be staggered with the DC/DC
frequency to avoid mutual interference (see figure 1).
Requirement on output load
To ensure this module can operate efficiently and reliably, a minimum load is
specified for this kind of DC/DC converter in addition to a maximum load
(namely full load). During operation, make sure the specified range of input
voltage is not exceeded, the minimum output load is
not less than 10%
of the
full load, and that this product should never be operated under no load!
MORNSUN Science& Technology Ltd.
Address: 8th floor 8th building, Huangzhou
Industrial District, Guangzhou, China
Tel: 86-20-38601850
Fax: 86-20-38601272
Http: //www.mornsun-power.com
MORNSUN reserves the copyright
Edition: A
NOV-2005
Page 2 of 2
