5 to 6 Watt
o Wide Input Range
o Pi Input Filter
24 Pin DIL Package V
2:1 Input Range
o 100 kHz Switching Frequency
o Regulated Output
o Single & Dual Output
o Short Circuit Protection
o Option 3000 VDC I/O-Isolation
o Option Conductive EMI/RFI Meet EN55022 Class B
(Option 3000 VDC I/O-Isolation With Remote Control)
MODEL NUMBER
5VRS12W3.3LC
5VRS12W5LC
6VRS12W12LC
6VRS12W15LC
5VRD12W5LC
6VRD12W12LC
6VRD12W15LC
5VRS24W3.3LC
5VRS24W5LC
6VRS24W12LC
6VRS24W15LC
5VRD24W5LC
6VRD24W12LC
6VRD24W15LC
5VRS48W3.3LC
5VRS48W5LC
6VRS48W12LC
6VRS48W15LC
5VRD48W5LC
6VRD48W12LC
6VRD48W15LC
last up-date 31.10.2011
INPUT
VOLTAGE
OUTPUT
VOLTAGE
3.3VDC
5VDC
12VDC
OUTPUT
CURRENT
1000mA
1000mA
INPUT CURRENT
%EFF
NO LOAD
FULL LOAD
382 mA
541 mA
7.5mA
573 mA
625 mA
541 mA
12mA
554 mA
556 mA
186 mA
260 mA
5mA
280 mA
84
298 mA
260 mA
7.5mA
280 mA
293 mA
93 mA
132 mA
2mA
142 mA
154 mA
130 mA
3mA
142 mA
81
147 mA
80
82
81
74
79
72
77
CAP.
LOAD
4700 µF
82
80
77
83
81
74
80
4700 µF
2200 µF
470mA
400mA
±500mA
±230mA
±190mA
1000mA
1000mA
470mA
400mA
±500mA
±230mA
±190mA
1000mA
1000mA
470mA
400mA
±500mA
±230mA
±190mA
9-18VDC
15VDC
±5VDC
±12VDC
±15VDC
3.3VDC
5VDC
12VDC
18-36VDC
15VDC
±5VDC
±12VDC
±15VDC
3.3VDC
5VDC
12VDC
2200 µF
4700 µF
83
81
80
2200 µF
36-72VDC
15VDC
±5VDC
±12VDC
±15VDC
5 to 6 Watt - 24 Pin DIL - Package V - 2:1 Input Range
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
INPUT SPECIFICATIONS
Input Voltage Range
Input Filter
2/3
2:1
Pi Network
OUTPUT SPECIFICATIONS
Voltage Accuracy
Voltage Balance, Dual Output
Temperature Coefficient
Ripple and Noise, 20MHz BW
Short Circuit Protection
Line Regulation (from High Line to Low Line)
Load Regulation
Single (from Full Load to 10% Load)
Dual (from Full Load to 25% Load)
3.3V, 5V
12V, 15V
±2% max.
±1% max.
±0.05%/°C
100 mV p-p max.
1% p-p max.
Continuous
±0.5%
±0.5%
±1.0%
GENERAL SPECIFICATION
Efficiency
Isolation Voltage
Suffix "H" *
Suffix "B" **
Suffix "HBR"
Isolation Resistance
Isolation Capacitance
Switching Frequency
Operating Temperature Range
Case Temperature
Storage Temperature Range
Humidity
Recommended Reflow Soldering Pb-free***
Derating
Case Material
Case Dimensions
Weight
Suffix "M" *
)
MTBF (MIL-HDBK-217F)
*) Suffix "HM" 1.5 KVDC instead of 3 KVDC Isolation
**) Subject to small Changes for Suffix "B". Please double check with M+R directly!
***) We do not recommend vapor phase soldering!
see table
500 VDC min.
3000 VDC min.
Option EMI/RFI EN55022 Class B
3KVDC + EN55022
+ Remote
Ctlr.
1000 Mohms
250 pF
100 kHz min.
-25°C to +71°C
Plastic Case
Copper Case
95°C max.
100°C max.
-40°C to +100°C
95% RH max. non condensing
see diagram
see Diagram
Non-Conductive Black Plastic
Standard
Suffix "B"+"HBR"
31.8x20.3x10.2 mm
31.8x20.3x12.7 mm
12.5 g
Black Coated Copper with Non-Conductive Base
1.187.000 hrs min.
M + R Multitronik GmbH
Kaninchenbergweg 78 • 23564 Lübeck • Germany
Tel. (+49) 0451 - 60 99 50 • Fax (+49) 0451 - 60 46 95
www.multitronik.com
info@multitronik.com
5 to 6 Watt - 24 Pin DIL - Package V - 2:1 Input Range
S P E C I F I C AT I O N S
All Specifications Typical At Nominal Line, Full Load, and 25°C Unless Otherwise Noted
3/3
MECHANICAL SPECIFICATIONS
CASE "V"
PIN
1 & 24
2 & 23
3 & 22
9 & 16
10 & 15
11 & 14
12 & 13
PIN CONNECTIONS 500 VDC
SINGLE
+INPUT
NC*
NC*
NO PIN
-OUTPUT
+OUTPUT
-INPUT
DUAL
+INPUT
-OUTPUT
COMMON
NO PIN
COMMON
+OUTPUT
-INPUT
*
Option "NO Pin" at Single Output add Suffix "NP"
to Part No.
PIN CONNECTIONS 3KVDC
PIN
1 & 24
2&3
5
9
10 & 15
11
12 & 13
14
16
22 & 23
SINGLE
NO PIN
-INPUT
NP*
NC
NC
NC
NO PIN
+OUTPUT
-OUTPUT
+INPUT
DUAL
NO PIN
-INPUT
NP*
COMMON
NC
-OUTPUT
NO PIN
+OUTPUT
COMMON
+INPUT
* Remote Control at Suffix "BR" + "HBR"
DIAGRAMS
REMOTE ON/OFF CONTROL
Logic Compatibility
Ec-ON
Ec-OFF
Shutdown Idle Current
Input Resistance
Control Common
CMOS or Open Collector TTL
>+5.5VDC or Open Circuit
<1.8VDC
10mA
(Ein 0 to 9VDC)100 kOhm
Referenced to Input Minus
N O T I C E:
The information in this document has been carefully checked. However, no responsibility is assumed for inaccuracies!
Specifications can be changed without notice. The latest and most complete information can be found on our website.
M + R Multitronik GmbH
Kaninchenbergweg 78 • 23564 Lübeck • Germany
Tel. (+49) 0451 - 60 99 50 • Fax (+49) 0451 - 60 46 95
www.multitronik.com
info@multitronik.com
