Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SSR05C50 thru
SSR05C80 Series
DESIGNER’S DATA SHEET
Part Number / Ordering Information
1/
SSR05C __ __ __
│ │ └
Screening:
__
= Not Screened
│ │
TX = TX Level
│ │
TXV = TXV Level
│ │
S = S Level
│ │
│ └
Package:
D1 = TO-252 (D-Pack)
│
G = Cerpack
│
S.5 = SMD.5
│
S.22 = SMD.22
│
70 = 700 V
└
Voltage
50 = 500 V
60 = 600 V
80 = 800 V
5 AMP / 800V
SILICON CARBIDE
SCHOTTKY RECTIFIER
Features:
800V Silicon Carbide Schottky Rectifier
New Semiconductor Material
Switching Behavior Benchmark
No Reverse Recovery
No Forward Recovery
No Switching Time Change Over Temperature
Hermetic Packages Available
Maximum Ratings
Peak Repetitive Reverse and
Peak Surge Reverse Voltage
Average Rectified Forward Current
(Resistive Load, 60 Hz Sine Wave)
Non Repetitive Peak Surge Current
(8.3 ms Pulse, Half Sine Wave)
I
2
t Value
Power Dissipation
Operating & Storage Temperature
Maximum Thermal Resistance
Junction to Case
TO-252 (D1)
Cerpack (G)
@25°C
SSR05C50
SSR05C60
SSR05C70
SSR05C80
Symbol
V
RRM
V
RSM
Io
I
FSM
I
2
t
P
D
Top & Tstg
R
JC
SMD.5 (S.5)
Value
500
600
700
800
5
12.5
0.78
36.5
-55 to +175
4.1
SMD.22 (S.22)
Units
Volts
Amps
Amps
A
2
s
Watts
°C
°C/W
1
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RS0016K
DOC
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SSR05C50 thru
SSR05C80 Series
Electrical Characteristic
Instantaneous Forward Voltage Drop
(I
F
= 5A, T
J
= 25°C, 300
sec
pulse)
Instantaneous Forward Voltage Drop
(I
F
= 5A, T
J
= 150°C, 300
sec
pulse)
Reverse Leakage Current
(V
R
= Rated V
R
, T
J
= 25°C, 300
sec
pulse min)
Reverse Leakage Current
(V
R
= Rated V
R
, T
J
= 100°C, 300
sec
pulse min)
Junction Capacitance
(V
R
=10 V
DC
, T
C
= 25°C, f = 1MHz)
Total Capacitive Charge
Symbol
V
F1
V
F2
I
R1
I
R2
C
J
Q
C
Min
––
––
––
––
––
––
Typ
1.7
2.0
15
40
50
13
Max
2.0
2.7
200
1000
––
––
Units
Volts
Volts
A
A
pF
nC
(V
R
= 400V, I
F
= 5A, di/dt = 200A/s, T
J
= 150°C)
NOTES:
1/ For Ordering Information, Price, and Availability Contact Factory.
2/ For Package Outlines Contact Factory.
3/ All Electrical Characteristics @25oC Unless Otherwise Specified.
Available Part Numbers:
SSR05C50D1 SSR05C50G
SSR05C50S.22
SSR05C60D1 SSR05C60G
SSR05C60S.22
SSR05C70D1 SSR05C70G
SSR05C70S.22
SSR05C80D1 SSR05C80G
SSR05C80S.22
SSR05C50S.5
SSR05C60S.5
SSR05C70S.5
SSR05C80S.5
Package
TO-252 (D1)
Cerpack (G)
SMD.5 (S.5)
SMD.22 (S.22)
PIN ASSIGNMENT
Pin 1
Pin 2
N/C
Anode
Cathode
Cathode
Cathode
Anode
Anode
Anode
Pin 3
Anode
N/A
Anode
Anode
Tab
Cathode
Cathode
N/A
N/A
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RS0016K
DOC
