Part Number

Search

LTC3125EDCB#TRPBF

Description
Conv DC-DC 1.8V to 5.5V Synchronous Step Up Single-Out 2V to 5.25V 1.2A 8-Pin DFN EP T/R
File Size311KB,18 Pages
ManufacturerADI
Websitehttps://www.analog.com
Download Datasheet Parametric Compare View All

LTC3125EDCB#TRPBF Overview

Conv DC-DC 1.8V to 5.5V Synchronous Step Up Single-Out 2V to 5.25V 1.2A 8-Pin DFN EP T/R

LTC3125EDCB#TRPBF Parametric

Parameter NameAttribute value
EU restricts the use of certain hazardous substancesCompliant
ECCN (US)EAR99
Part StatusActive
HTS8542.39.00.01
TypeSynchronous Step Up
Output TypeAdjustable
Switching Frequency (kHz)1900
Switching RegulatorYes
Number of Outputs1
Output Voltage (V)2 to 5.25
Maximum Output Current (A)1.2
Minimum Input Voltage (V)1.8
Maximum Input Voltage (V)5.5
Typical Quiescent Current (uA)300
Efficiency (%)93
Minimum Operating Temperature (°C)-40
Maximum Operating Temperature (°C)125
Supplier Temperature GradeExtended
PackagingTape and Reel
Pin Count8
Standard Package NameDFN
Supplier PackageDFN EP
MountingSurface Mount
Package Height0.75(Max)
Package Length2
Package Width3
PCB changed8
Lead ShapeNo Lead
LTC3125
1.2A Synchronous Step-Up
DC/DC Converter with
Input Current Limit
FEATURES
n
n
n
n
n
n
n
n
n
n
n
n
n
n
DESCRIPTION
The LTC
®
3125 is a high efficiency, synchronous step-up
DC/DC converter with an accurate programmable average
input current limit. The resistor programmable average
input current limit is 5% accurate at 500mA and is suitable
for a wide variety of applications. In mobile computing,
GSM and GPRS cards demand high current pulses well
beyond the capability of the PC Card and CompactFlash
slots. The LTC3125 in concert with a reservoir capacitor,
keeps the slot power safely within its capabilities providing
a high performance and simple solution.
Synchronous rectification produces high efficiency while
the 1.6MHz switching frequency minimizes the solution
footprint. The current mode PWM design is internally com-
pensated. Output disconnect allows the load to discharge in
shutdown, while also providing inrush current limiting.
Other features include a <1μA shutdown current, short-
circuit and thermal overload protection. The LTC3125 is
offered in a low profile 0.75mm
×
2mm
×
3mm package.
L,
LT, LTC, LTM and Burst Mode are registered trademarks of Linear Technology Corporation.
All other trademarks are the property of their respective owners.
Programmable Average Input Current Limit
5% Input Current Accuracy
200mA to 1000mA Program Range
V
IN
: 1.8V to 5.5V, V
OUT
: 2V to 5.25V
Supports High Current GSM/GPRS Load Burst
V
IN
> V
OUT
Operation
1.6MHz Fixed Frequency Operation
Internal Current Sense Resistor
1.2A Peak Current Limit
Up to 93% Efficiency
Output Disconnect in Shutdown
Soft-Start
Low Quiescent Current Burst Mode
®
Operation
Available in 2mm
×
3mm
×
0.75mm DFN Package
APPLICATIONS
n
n
n
n
GSM/GPRS PCMCIA/CompactFlash PC Card Modems
Wireless Emergency Locators
Portable Radios
Supercap Chargers
TYPICAL APPLICATION
PCMCIA/CompactFlash (3.3V/500mA Max),
4V GSM Pulsed Load
2.2μH
V
IN
3.3V
500mA
CS
V
IN
10μF
CER
OFF ON
SHDN
SW
V
OUT
LTC3125
1.24M
V
OUT
4V
2A PULSED LOAD
2200μF
2
TANT
3125 TA01a
Efficiency vs Load Current
100
90
80
EFFICIENCY (%)
70
60
50
40
30
20
10
0
0.001
0.01
0.1
LOAD CURRENT (A)
V
OUT
= 4V
V
IN
= 3.3V
V
IN
= 2.4V
1
3125 TA01b
1
POWER LOSS (W)
0.1
PROG
44.2k
GND
FB
536k
0.01
0.001
3125fa
1
