LTC4098EUDC-3.6#TRPBF

Description
USB Power Manager 4.35V to 5.5V Automotive 20-Pin QFN EP T/R
File Size500KB,32 Pages
ManufacturerADI
Websitehttps://www.analog.com
Download Datasheet Parametric Compare View All

LTC4098EUDC-3.6#TRPBF Overview

USB Power Manager 4.35V to 5.5V Automotive 20-Pin QFN EP T/R

LTC4098EUDC-3.6#TRPBF Parametric

Parameter NameAttribute value
EU restricts the use of certain hazardous substancesCompliant
ECCN (US)EAR99
Part StatusActive
HTS8542.39.00.01
FunctionUSB Power Manager
Switching Frequency (kHz)1960 to 2650
Minimum Operating Supply Voltage (V)4.35
Maximum Operating Supply Voltage (V)5.5
Minimum Operating Temperature (°C)-40
Maximum Operating Temperature (°C)85
Supplier Temperature GradeExtended
PackagingTape and Reel
Maximum Storage Temperature (°C)125
Minimum Storage Temperature (°C)-65
Standard Package NameQFN
Supplier PackageQFN EP
Pin Count20
MountingSurface Mount
Package Height0.75(Max)
Package Length4
Package Width3
PCB changed20
Lead ShapeNo Lead
FEATURES
n
LTC4098-3.6
USB Compatible Switching
Power Manager/LiFePO
4
Charger
with Overvoltage Protection
DESCRIPTION
The LTC
®
4098-3.6 is a high efficiency USB PowerPath
controller and full-featured LiFePO
4
battery charger. It seam-
lessly manages power distribution from multiple sources
including USB, wall adapter, automotive, Firewire or other
high voltage DC/DC converters, and a LiFePO
4
battery.
The LTC4098-3.6 charge algorithm is optimized for LiFePO
4
by implementing a 1-hour float voltage termination timer
and a 0°C to 60°C NTC-based charge qualification range.
Furthermore, completely discharged batteries are charged
at the full programmed charge current.
The LTC4098-3.6’s switching regulator can automatically
limit its input current for USB compatibility. For automo-
tive and other high voltage applications, the LTC4098-3.6
interfaces with an external switching regulator. Both the
USB input and the auxiliary input controller feature Bat-
Track optimized charging to provide maximum power to
the application and reduced heat in high power density ap-
plications with input supplies from 5V to as high as 38V.
An overvoltage protection circuit guards the LTC4098-3.6
from high voltage damage on the VBUS pin with just two
external components.
The LTC4098-3.6 is available in a 20-lead 3mm
×
4mm
×
0.75mm QFN surface mount package.
L,
LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks and
Bat Track and PowerPath are trademarks of Linear Technology Corporation. All other trademarks
are the property of their respective owners.
n
n
n
n
n
n
n
n
n
n
Switching Regulator with Bat-Track
TM
Adaptive
Output Control Makes Optimal Use of Limited
Power Available from USB Port to Charge Battery
and Power Application
Charge Control Algorithm Specifically Designed
for LiFePO
4
(Lithium Iron Phosphate)
Overvoltage Protection Guards Against Damage
Bat-Track External Step-Down Switching Regulator
Control Maximizes Efficiency from Automotive,
Firewire and Other High Voltage Input Sources
180mΩ Internal Ideal Diode Plus External Ideal Diode
Controller Seamlessly Provide Low Loss PowerPath
TM
When Input Power Is Limited or Unavailable
Preset 3.6V Charge Voltage with 0.5% Accuracy
Instant-On Operation with Discharged Battery
700mA Maximum Load Current from USB Port
2A Maximum Input Current from Internal Switching
Regulator
1.5A Maximum Charge Current with Thermal Limiting
20-Lead 3mm
×
4mm
×
0.75mm QFN Package
APPLICATIONS
n
n
n
High Peak Power Battery-Powered Equipment
Backup Applications
High Reliability Handhelds
TYPICAL APPLICATION
High Efficiency USB Compatible LiFePO
4
Battery Charger with Overvoltage Protection
3.3µH
5V/USB
10µF
6.04k
TO µC
3
OVGATE
OVSENS
D0-D2
CLPROG
0.1µF
3.01k
PROG
500
BAT
GND BATSENS
10µF
LTC4098-3.6
V
OUT
V
BUS
SW
POWER DISSIPATION (W)
SYSTEM
LOAD
3.0
2.5
2.0
1.5
1.0
0.5
LiFePO
4
409836 TA01a
Reduced Power Dissipation
vs Linear Battery Charger
LINEAR BATTERY
CHARGER
V
IN
= 5V
PROG = 500
I
CHRG
= 1.1A
10x MODE
ADDITIONAL POWER
AVAILABLE FOR CHARGING
+
SWITCHING
BATTERY
CHARGER
2.85
3.00 3.15 3.30
BATTERY VOLTAGE (V)
3.45
3.60
409836f
0
2.70
409836 TA01b
1

LTC4098EUDC-3.6#TRPBF Related Products

LTC4098EUDC-3.6#TRPBF LTC4098EUDC-3.6#PBF
Description USB Power Manager 4.35V to 5.5V Automotive 20-Pin QFN EP T/R USB Power Manager 4.35V to 5.5V Automotive 20-Pin QFN EP Tube
EU restricts the use of certain hazardous substances Compliant Compliant
ECCN (US) EAR99 EAR99
Part Status Active Active
HTS 8542.39.00.01 8542.39.00.01
Function USB Power Manager USB Power Manager
Switching Frequency (kHz) 1960 to 2650 1960 to 2650
Minimum Operating Supply Voltage (V) 4.35 4.35
Maximum Operating Supply Voltage (V) 5.5 5.5
Minimum Operating Temperature (°C) -40 -40
Maximum Operating Temperature (°C) 85 85
Supplier Temperature Grade Extended Extended
Packaging Tape and Reel Tube
Maximum Storage Temperature (°C) 125 125
Minimum Storage Temperature (°C) -65 -65
Standard Package Name QFN QFN
Supplier Package QFN EP QFN EP
Pin Count 20 20
Mounting Surface Mount Surface Mount
Package Height 0.75(Max) 0.75(Max)
Package Length 4 4
Package Width 3 3
PCB changed 20 20
Lead Shape No Lead No Lead
