UNISONIC TECHNOLOGIES CO., LTD
MGBR30S45C
Preliminary
DIODE
DUAL MOS GATED BARRIER
RECTIFIER
DESCRIPTION
The UTC
MGBR30S45C
is a dual mos gated barrier rectifiers,
it uses UTC’s advanced technology to provide customers with low
forward voltage drop and high switching speed, etc.
FEATURES
* Super low forward voltage drop
* High switching speed
SYMBOL
ORDERING INFORMATION
Package
TO-220
TO-252
Pin Assignment
1
2
3
A
K
A
A
K
A
Packing
Tube
Tape Reel
Ordering Number
Lead Free
Halogen Free
MGBR30S45CL-TA3-T
MGBR30S45CG-TA3-T
MGBR30S45CL-TN3-R
MGBR30S45CG-TN3-R
Note: Pin Assignment: A: Anode
K: Common Cathode
MARKING
TO-220 / TO-220F
TO-252
www.unisonic.com.tw
Copyright © 2015 Unisonic Technologies Co., Ltd
1 of 3
QW-R601-168.c
MGBR30S45C
Preliminary
DIODE
ABSOLUTE MAXIMUM RATINGS (PER LEG)
(T
A
=25°C unless otherwise specified)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
PARAMETER
SYMBOL
RATINGS
UNIT
DC Blocking Voltage
V
RM
45
V
Working Peak Reverse Voltage
V
RWM
45
V
Peak Repetitive Reverse Voltage
V
RRM
45
V
Per Leg
15
A
Average Rectified Output Current Per Device
I
O
Total
30
A
Non-Repetitive Peak Forward Surge Current 8.3ms
I
FSM
250
A
Single Half Sine-Wave Superimposed on Rated Load
Operating Junction Temperature
T
J
-65~+150
°C
Storage Temperature
T
STG
-65~+150
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
THERMAL CHARACTERISTICS (PER LEG)
PARAMETER
SYMBOL
TO-220
TO-252
TO-220
TO-252
θ
JA
θ
JC
RATINGS
62.5
110
2
2.5
UNIT
°C/W
°C/W
Junction to Ambient
Junction to Case
ELECTRICAL CHARACTERISTICS (PER LEG)
(T
A
=25°C
unless otherwise specified)
SYMBOL
V
(BR)R
MIN
45
TYP MAX UNIT
V
0.50
V
0.45
V
500
μA
100 mA
PARAMETER
Reverse Breakdown Voltage (Note 1)
TEST CONDITIONS
I
R
=0.50mA
I
F
=15A, T
J
=25°C
Forward Voltage Drop
V
FM
I
F
=15A, T
J
=125°C
V
R
=45V, T
J
=25°C
Leakage Current (Note 1)
I
RM
V
R
=45V, T
J
=125°C
Notes: 1. Short duration pulse test used to minimize self-heating effect.
2. Thermal resistance junction to case mounted on heatsink.
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
2 of 3
QW-R601-168.c
MGBR30S45C
Preliminary
DIODE
UTC assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or
other parameters) listed in products specifications of any and all UTC products described or contained
herein. UTC products are not designed for use in life support appliances, devices or systems where
malfunction of these products can be reasonably expected to result in personal injury. Reproduction in
whole or in part is prohibited without the prior written consent of the copyright owner. The information
presented in this document does not form part of any quotation or contract, is believed to be accurate
and reliable and may be changed without notice.
