Power Ring Film Capacitors
SBE Part 700A10896-348
TM
Power Ring Film Capacitor™
1000 µF, 600 Vdc
The 700A10896-348 Power Ring is a
600Vdc, 1000 µF DC Link Capacitor with
an ESR of 125 micro-Ohms at 20kHz and
an ESL of less than 15nH.
Power Ring Film Capacitors
™
Electrical Specifications
SBE Part #:
700A10896-348
SBE Part #: 700D10896-348
Thermal Resistance:
Power Ring Film Capacitor™
Capacitance/Tolerance:
1000 µF ±10%
1000 µF, 600 VDC
DC Voltage Rating:
600 Vdc
Dielectric/Construction:
Metallized polypropylene.
Electrical
Specifications
Single section design
integrated to laminar bus
SBE Part #:
Capacitance/Tolerance:
700D10896-348
0.89°C/W (case cooling only)
and 0.41°C/W (case and bus
side cooling only)
Operating Temperature:
-40°C to +85°C hotspot
temperature at full DC voltage
rating
Voltage, Temperature
De-rate voltage linearly to
De-rating:
400 Vdc from +85°C
to +107°C
with respect to hotspot
temperature
10,000 Amps maximum
Dielectric Withstand:
Units 100% tested at DC
1000 µF
±10%
potential of 750 Volts for
DC
Voltage Rating:
600 VDC
2 minutes at 25°C
Dielectric/Construction:
Dielectric Withstand:
ESL at Output Tabs:
Insulation Resistance:
ESR vs. Frequency:
Less than 15 nH for unit as
Rating (external to the
Unit shall withstand a DC potential
include
for two minutes
shown (value does not
of 750 Volts
capacitor):
effects from additional
100 MΩ Min at +25°C
hardware, bus adaptor, etc.)
RMS Current Rating:
600
Metallized Polypropylene. Single section design,
System Fault
wound
non-inductively
Current
Typical ESR vs. Frequency:
2
500
1.5
Maximum Ripple Current (A rms)
ESR, milliohms
400
Case Side Cooling Only
Case and Bus Side Cooling
1
300
200
700D348 with 20 kHz ripple current
100
Temperature rise due to capacitor losses only
Bus heat load NOT included
0.5
0
0.01
0
0.1
1
10
100
1000
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
Frequency, KHz
SBE reserves the right to amend design data
Case Temperature (
o
C)
At the Leading Edge of Film Capacitor Technology®
Power Ring Film Capacitors
SBE Part 700A10896-348
TM
Mechanical Specifications
Dimensions:
Bus/Terminals:
Encapsulation:
See layout drawing for details
Tin plated copper,
0.136” thick
Capacitors potted with RTV
Marking:
SBE Inc.
SBE company identification
700A348
SBE “short form” part number
1000 µF ±10% Capacitance value and
tolerance
600 Vdc
DC voltage rating
yyww-lot#-unit Serial number (date code,
lot number, unit number)
Layout Details:
Revisions
REV.
01
DESCRIPTION
Initial Release
CHG
BY
-
CHK
BY
-
APR
BY
-
DATE
-
4X 45.00°
6X
9.53±0.13 THRU
7X 33.34
4X 5.00 5.00
Accepts 1/4" Plastite Screw
40 in-lbs MAX Torque
57.15
264.41 NOMINAL
4X 31.75
235.00
Bolt Circle
155.58
323.85 NOMINAL
146.05
8X
5.79±0.13 THRU
NON-TOLERANCED DIMENSIONS ARE BASIC
-
54.79 NOMINAL
3.43 NOMINAL
-
-
-
UNLESS OTHERWISE SPECIFIED:
ALL DIMENSIONS ARE IN MM
SBE, INC.
81 PARKER ROAD
BARRE, VT 05641 USA
802.476.4146 FAX: 802.661.3950
TITLE
GEOMETRIC TOLERANCING PER: Y14.5-2009
DRAWN
CHECKED
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF SBE. ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF SBE IS PROHIBITED.
AGH
MGS
MSB
1/29/2014
6/27/2014
6/30/2014
Horizontal Test Kit, 1000uF,
600VDC
DWG. NO.
ENG APPR.
MATERIAL
FINISH
700A348LV
DO NOT SCALE DRAWING
SIZE
B
REV
01
SHEET 1 OF 1
Contact SBE Inc. to discuss your specific requirements.
#SBE-PR-700A348-07/14
SBE reserves the right to amend design data
SBE Inc. 81 Parker Road
Barre, Vermont 05641 USA
telephone:
802.476.4146
fax:
802.661.3950
web site:
www.SBElectronics.com
e-mail:
PowerRing@SBElectronics.com
