SOT89 PNP SILICON POWER
(SWITCHING) TRANSISTOR
ISSUE 1 - NOVEMBER 1998
FEATURES
FCX1151A
C
*
*
*
*
*
2W POWER DISSIPATION
5A Peak Pulse Current
Excellent H
FE
Characteristics up to 5 Amps
Extremely Low Saturation Voltage E.g. 60mv Typ.
Extremely Low Equivalent On-resistance;
R
CE(sat)
66mΩ at 3A
FCX1051A
151
E
C
B
Complimentary Type -
Partmarking Detail -
ABSOLUTE MAXIMUM RATINGS.
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Peak Pulse Current **
Continuous Collector Current
Base Current
Power Dissipation at T
amb
=25°C
Operating and Storage Temperature Range
SYMBOL
V
CBO
V
CEO
V
EBO
I
CM
I
C
I
B
P
tot
T
j
:T
stg
VALUE
-45
-40
-5
-5
-3
-500
1 †
2 ‡
-55 to +150
UNIT
V
V
V
A
A
mA
W
W
°C
† recommended P
tot
calculated using FR4 measuring 15x15x0.6mm
‡ Maximum power dissipation is calculated assuming that the device is mounted on FR4
substrate measuring 40x40x0.6mm and using comparable measurement methods adopted by
other suppliers.
**Measured under pulsed conditions. Pulse width=300µs. Duty cycle
≤
2%
Spice parameter data is available upon request for these devices
Refer to the handling instructions for soldering surface mount components.
FCX1151A
ELECTRICAL CHARACTERISTICS (at T
amb
= 25°C unless otherwise stated).
PARAMETER
Collector-Base
Breakdown Voltage
Collector-Emitter
Breakdown Voltage
Collector-Emitter
Breakdown Voltage
Collector-Emitter
Breakdown Voltage
Emitter-Base
Breakdown Voltage
Collector Cut-Off Current
Emitter Cut-Off Current
Collector Emitter Cut-Off
Current
Collector-Emitter
Saturation Voltage
SYMBOL MIN.
V
(BR)CBO
V
(BR)CES
V
(BR)CEO
V
(BR)CEV
V
(BR)EBO
I
CBO
I
EBO
I
CES
V
CE(sat)
-45
-40
-40
-40
-5
-0.3
-0.3
-0.3
-60
-120
-140
-200
-985
-850
270
250
180
100
450
400
300
190
45
145
40
170
460
-100
-100
-100
-90
-180
-220
-300
-1050
-950
TYP.
MAX.
UNIT
V
V
V
V
V
nA
nA
nA
mV
mV
mV
mV
mV
mV
CONDITIONS.
I
C
=-100µA
I
C
=-100µA
I
C
=-10mA
I
C
=-100µA, V
EB
=+1V
I
E
=-100µA
V
CB
=-36V
V
EB
=-4V
V
CE
=-32V
I
C
=-0.1A, I
B
=-1.0mA*
I
C
=-0.5A, I
B
=-5mA*
I
C
=-1A, I
B
=-20mA*
I
C
=-3A, I
B
=-250mA*
I
C
=-3A, I
B
=-250mA*
I
C
=-3A, V
CE
=-2V*
I
C
=-10mA, V
CE
=-2V*
I
C
=-0.5A, V
CE
=-2V*
I
C
=-2A, V
CE
=-2V*
I
C
=-3A, V
CE
=-2V*
I
C
=-5A, V
CE
=-2V*
MHz
pF
ns
ns
I
C
=-50mA, V
CE
=-10V
f=50MHz
V
CB
=-10V, f=1MHz
I
C
=-2A, I
B
=-20mA,
V
CC
=-30V
I
C
=-2A, I
B
=±20mA,
V
CC
=-30V
Base-Emitter
Saturation Voltage
Base-Emitter Turn-On
Voltage
Static Forward Current
Transfer Ratio
V
BE(sat)
V
BE(on)
h
FE
800
Transition Frequency
Output Capacitance
Switching Times
f
T
C
cb
t
on
t
off
*Measured under pulsed conditions. Pulse width=300µs. Duty cycle
≤
2%
