SBG1025L - SBG1030L
10A SCHOTTKY BARRIER RECTIFIER
SPICE MODELS: SBG1025L SBG1030L
Features
NEW PRODUCT
·
·
·
·
·
·
Guard Ring Die Construction for
Transient Protection
Low Power Loss, High Efficiency
High Surge Capability
Very Low Forward Voltage Drop
For Use in Low Voltage, High Frequency
Inverters, Free Wheeling, and Polarity
Protection Applications
Plastic Material: UL Flammability
Classification Rating 94V-0
E
A
4
D
2
PAK
G
H
J
Dim
A
B
C
D
E
G
H
Min
9.65
14.60
0.51
2.29
4.37
1.14
1.14
8.25
0.30
2.03
2.29
Max
10.69
15.88
1.14
2.79
4.83
1.40
1.40
9.25
0.64
2.92
2.79
B
1
2
3
Mechanical Data
·
·
·
·
·
·
Case: D
2
PAK Molded Plastic
Terminals: Solderable per MIL-STD-202,
Method 208
Polarity: See Diagram
Marking: Type Number
Weight: 1.7 grams (approx.)
Ordering Information: See Sheet 2
@ T
A
= 25°C unless otherwise specified
M
D
C
PIN 1
PIN 3
K
L
PIN 2 & 4
J
K
L
M
All Dimensions in mm
Maximum Ratings
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectified Output Current
@ T
C
= 120°C
Non-Repetitive Peak Forward Surge Current
8.3ms Single half sine-wave Superimposed on Rated Load
(JEDEC Method)
Typical Thermal Resistance Junction to Case (Note 1)
Operating Temperature Range
Storage Temperature Range
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
I
FSM
R
qJC
T
j
T
STG
SBG1025L
25
18
10
200
3.0
-65 to +125
-65 to +150
SBG1030L
30
21
Unit
V
V
A
A
°C/W
°C
°C
Electrical Characteristics
Characteristic
Reverse Breakdown Voltage
@ T
A
= 25°C unless otherwise specified
Symbol
SBG1025L
SBG1030L
V
(BR)R
Min
25
30
¾
¾
¾
¾
¾
¾
¾
Typ
¾
¾
¾
0.34
¾
0.48
¾
150
350
Max
¾
¾
0.45
0.36
0.55
0.50
1.0
260
¾
Unit
V
V
V
Test Condition
I
R
= 1mA
@ I
F
= 10A, T
C
= 25°C
@ I
F
= 10A, T
C
= 125°C
@ I
F
= 20A, T
C
= 25°C
@ I
F
= 20A, T
C
= 125°C
@ T
C
= 25°C
@ T
C
= 125°C
f = 1.0MHz, V
R
= 4.0V DC
Forward Voltage
Peak Reverse Current
at Rated DC Blocking Voltage
Typical Junction Capacitance
Notes:
V
FM
I
RM
C
j
mA
pF
1. Thermal resistance: junction to case mounted on heat sink.
DS30127 Rev. 3 - 2
1 of 3
www.diodes.com
SBG1025L - SBG1030L
ã
Diodes Incorporated
10
100
I
F
, INSTANTANEOUS FWD CURRENT (A)
I
(AV)
, AVERAGE RECTIFIED CURRENT (A)
NEW PRODUCT
8
10
6
4
1.0
2
0
0
25
50
75
100
125
150
T
C
, CASE TEMPERATURE (°C)
Fig. 1 Forward Derating Curve
I
R
, INSTANTANEOUS REVERSE CURRENT (mA)
1000
I
FSM
, PEAK FORWARD SURGE CURRENT (A)
T
j
= 125ºC
0.1
0
0.2
0.4
0.6
0.8
1.0
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
300
8.3 ms single half-sine-wave
JEDEC method
100
250
10
T
j
= 100ºC
200
150
1
T
j
= 25ºC
100
0.1
50
0.01
0
5
10
15
20
25
30
35
0
1
10
100
V
R
, REVERSE VOLTAGE (V)
Fig. 3 Typical Reverse Characteristics
1000
NUMBER OF CYCLES AT 60Hz
Fig. 4 Maximum Non-Repetitive Surge Current
C
j
, JUNCTION CAPACITANCE (pF)
500
T
j
= 25°C
f = 1.0MHz
10
0.1
1.0
10
100
V
R
, REVERSE VOLTAGE (V)
Fig. 5 Typical Junction Capacitance
DS30127 Rev. 3 - 2
2 of 3
www.diodes.com
SBG1025L - SBG1030L
