Product Brief
MegaRAID
®
SAS 9341-8i & MegaRAID SAS 9341-4i
Cost Effective, Entry Line of Eight-Port and Four-Port 12Gb/s
PCIe 3.0 SATA+SAS RAID Controllers
MegaRAID SATA+SAS Entry Product Line
Key Advantages
■■
MegaRAID SATA+SAS entry controller cards allow small to medium business (SMB) owners
and gaming enthusiasts to enjoy the latest RAID technology at affordable prices with low
power consumption. This product line delivers trusted MegaRAID reliability with minimal
maintenance effort. MegaRAID entry controller cards offer users a straight-forward solution
that includes essential RAID levels and uncomplicated configuration options.
In addition, they are able to connect to combinations of SATA and SAS hard disk drives and
solid state drives, allowing for storage configurations that optimize cost, performance and
robust data protection.
High performance with 12Gb/s data
transfer rates
PCI Express® 3.0 host interface drives
superior system performance
Delivers robust, yet simple RAID
functionality
Flexible SATA+SAS array architecture
optimizes cost
Complete kit package includes
necessary cables and brackets
Includes JBOD Mode support
Applications
Internal storage configurations
1U/2U rack servers
File, Web, database and email servers
High-performance workstations
■■
■■
■■
■■
■■
Enterprise Ready
Along with an extensive list of enterprise RAID capabilities, the 9341 series now offers
advanced drive diagnostic technologies. In the event of a physical drive failure, the drive is
placed in a shielded state and the MegaRAID controller starts drive diagnostics to determine
if the drive is indeed failed or can be restored. This saves customers time, money and lost
compute time associated with transient drive failures and unnecessary drive returns.
■■
■■
■■
■■
Typical Uses
■■
Direct-attach, internal SAS or SATA
hard disk drives (HDDs) and solid state
drives (SSDs)
High volume, “warm data” access
Simple Migration to MegaRAID Enterprise Products
A unique feature of the MegaRAID SATA+SAS entry line is the ability to migrate from these
simple, yet powerful RAID 5 controllers to the more full-featured MegaRAID product lines.
Users can simply plug in a new controller to recognize and import the existing array without
requiring any reconfiguration. Plus, a single management client provides a consistent user
interface to manage any MegaRAID SATA, SAS or SSD array.
■■
Key Features
■■
■■
■■
Eight internal 12Gb/s SATA+SAS ports
x8 PCI Express 3.0 host interface
Two x4 SFF-8643 mini-SAS HD internal
connectors
LSISAS3008 PowerPC 476 controller
@ 1.2GHz
RAID 0, 1, 5, 10, 50 and JBOD mode
Low-profile form factor
Supports up to 64 devices in JBOD
mode
Up to 32 physical devices in RAID
mode
Powerful device monitoring and
maintenance capabilities
12Gb/s SAS and PCI 3.0 Performance Advantages
12Gb/s SAS is designed for backward compatibility with 6Gb/s and 3Gb/s SAS and SATA
hard drives. Regardless of the drive speed, 12Gb/s MegaRAID controllers will deliver
significant performance improvements in both read and write applications compared to their
predecessors.
■■
■■
■■
■■
■■
■■
Product Brief
MegaRAID SAS 9341-8i & 9341-8i
Solution Provided
Physical Dimensions
Connectors
Max Number of Physical Devices
Low-cost, green SATA+SAS RAID solution for high-density servers and workstations with the flexibility to use both
SATA and SAS hard drives and solid state drives
9341-8i & 9341-4i: 2.6” x 6.0”
9341-8i: Two, x4, SFF-8643 mini-SAS HD horizontal connector placement
9341-4i: One, x4, SFF-8643 mini-SAS HD horizontal connector placement
Non-RAID (JBOD Mode): 64
RAID 0: 32 per volume
RAID 1: 2 per volume plus hot spare
8-lane, 5 GT/s PCI Express 3.0 Compliant
Up to 12Gb/s per port
• RAID levels 0, 1, 5, 10, 50 and JBOD mode
• Online Capacity Expansion (OCE)
• Online RAID Level Migration (RLM)
• Auto resume after loss of system power during array
rebuild or RLM
• Single controller multipathing (Load balancing)
• Drive hot plug support
• Drive roaming
• Selectable logical drive as boot drive
• Virtual Disk (VD) Consistency Check
• Fast initialization for quick array setup
• Staggered disk spin up
• Hot Spare support (up to 8)
– Global, dedicated (copy back), enclosure affinity
and emergency SATA support
• Automatic rebuild support
• MegaRAID Storage Manager
™
– Now with single login for domain admin
• StorCLI (command-line interface)
Operating
0°C to 70°C
5 to 90% Non-condensing
3.3V add-in Card
+12V +/-8%
13.0 W (normal), 19.04 W (max)
Bus Master DMA
Internal
Activity/Fault per x4 port – Heartbeat
>2,800,000 hours
EMC: Class B-US (CFR 47, P15B); Canada (ICES-003); Japan (V-3/02.04); Europe (EN55022/EN55024); Australia/New
Zealand (AS/NZS 3548); Safety: EN60950
EN55022, EN55024, EN60950, EN 61000-3-2, EN 61000-3-3; FCC Class A, Class B; UL1950; UL; CSA C22.2; VCCI; RRL for
MIC; BSMI; C-tick
Extensive support includes Microsoft
®
Windows
®
Server 2012/Vista/2008/Server 2003, Linux
®
, Solaris
™
(x86), FreeBSD
®
,
VMware
®
and more.
Visit the download center for the most complete list of supported operating systems: www.lsi.com/support
RAID 5: 32 per volume
RAID 10: 32 per volume
RAID 50: 32 per volume
Host Bus Type
Data Transfer Rates
Key RAID Data Protection Features
• SafeStore Encryption Services for SED HDDs
• Shielded state drive diagnostic technology
• Patrol Read media scan and repair
• Online HDD firmware update
• Error recovery support
• SAS TCQ support
• SATA NCQ support
• Support for native 4K HDDs
• Non disk device support
• >2TB logical drive support
• Soft bad block management
• DDF-compliant Configuration on Disk
• Foreign Configuration Import
• S.M.A.R.T. support
• SES (inband) & SGPIO (sideband) management
• CTRL-R (BIOS configuration utility)
• HII (UEFI Human Interface Infrastructure)
Storage
-45°C to 105°C
5 to 90% Non-condensing
MegaRAID Management Suite
Environments
PCI Card Type
PCI Voltage
PCI Power
PCI Modes
LED Indicators
MTFB
Compliances
Regulatory Certifications
OS Support
Brackets
Warranty
Ordering Information
Full Height and Low-Profile
3 years, advanced replacement option; Free technical support at www.lsi.com/support
LSI SAS 9341-4i Single Pack P/N: LSI00419, LSI SAS 9341-4i Kit P/N: LSI00406
LSI SAS 9341-8i Single Pack P/N: LSI00407, LSI SAS 9341-8i Kit P/N: LSI00408
Visit the Avago Storage by LSI website at:
lsi.com
Avago, Avago Technologies, MegaRAID, and the Storage by LSI logo are trademarks of Avago Technologies. All other trademarks are the
property of their respective owners.
Copyright ©2014 Avago Technologies. All rights reserved. > 10.07.14 PB0079.02
