LCD-320H240C
Vishay
320 x 240 Graphic LCD
FEATURES
• Type: Graphic
• Display format: 320 x 240 dots
• Built-in controller: RA8835 and SRAM
• Duty cycle: 1/240
• Built-in N.V.
• Touch screen option (analog type)
• Temperature compensation option
• Compliant to RoHS directive 2002/95/EC
MECHANICAL DATA
ITEM
Module Dimension
Viewing Area
Dot Size
Dot Pitch
Mounting Hole
Character Size
STANDARD VALUE
148.02 x 120.24
120.14 x 92.14
0.34 x 0.34
0.36 x 0.36
139.98 x 116.61
N/a
mm
UNIT
ABSOLUTE MAXIMUM RATINGS
ITEM
SYMBOL
STANDARD VALUE
MIN.
4.75
- 0.3
TYP.
5.0
-
MAX.
5.25
V
DD
UNIT
Power Supply V
DD
to V
SS
Input Voltage
V
I
Note
• V
SS
= 0 V, V
DD
= 5.0 V
V
ELECTRICAL CHARACTERISTICS
ITEM
SYMBOL
V
DD
V
IO
I
DD
V
0
to V
SS
V
FLS
V
FLD
I
FLD
V
F
I
F
I
EF
CONDITION
L level
H level
V
DD
= + 5.0 V
- 20 °C
25 °C
70 °C
25 °C
25 °C
V
FQ
= 450 V
RMS
, 30 kHz
25 °C
25 °C
V
EL
= 110 V
AC
, 400 Hz
STANDARD VALUE
MIN.
0.7 V
DD
0
-
-
-
20.9
-
-
-
-
-
-
TYP.
-
-
100
-
23.8
-
600
268
5.0
4.2
180
-
MAX.
V
DD
0.3 V
DD
105
26.1
-
-
-
-
-
4.6
360
5.0
V
RMS
V
RMS
mA
RMS
V
mA
mA
V
UNIT
Input Voltage
Supply Current
Recommended LC Driving
Voltage for Normal Temperature
Version Module
CCFL Starting Voltage
CCFL Driving Voltage
CCFL Driving Current
LED Forward Voltage
LED Forward Current
EL Power Supply Current
V
mA
OPTIONS
PROCESS COLOR
TN
STN
Gray
STN
Yellow
STN
Blue
FSTN
B&W
STN
Color
None
BACKLIGHT
LED
EL
CCFL
For detailed information, please see the “Product Numbering System” document.
Document Number: 37387
Revision: 20-Apr-09
For technical questions, contact:
displays@vishay.com
www.vishay.com
1
LCD-320H240C
Vishay
INTERFACE PIN FUNCTION
PIN NO.
1
2
3
4
5
SYMBOL
V
SS
V
DD
V
0
RD
WR
FUNCTION
Ground
Power supply for logic
Driving voltage for LCD
8080 family: Read signal/6800 family: Enable clock
8080 family: Write signal/6800 family: R/W signal
Data type select
For 80 family:
RD = L, WR = H; AO = L: Data read, AO = H: Status read
RD = H, WR = L; AO = L: Data write, AO = H: Command write
For 68 family:
R/W = L; AO = H: Command write, AO = L: Data write
R/W = H; AO = H: Status read, AO = L: Data read
Date bus line
Date bus line
Date bus line
Date bus line
Date bus line
Date bus line
Date bus line
Date bus line
Chip select, active L
Controller reset signal, active L
Negative voltage output (optional)
Frame ground
No connection
No connection
320 x 240 Graphic LCD
6
A
0
7
8
9
10
11
12
13
14
15
16
17
18
19
20
DB0
DB1
DB2
DB3
DB4
DB5
DB6
DB7
CS
RES
V
EE
F
GND
NC
NC
DIMENSIONS
in millimeters
www.vishay.com
2
For technical questions, contact:
displays@vishay.com
Document Number: 37387
Revision: 20-Apr-09
