Micro-D
MIL-DTL-83513 Type
ylbmessA elcatpeceR S52
240-077
Rear Panel Mount Micro-D Filter Connectors
Insulated Wire
Glenair Filtered Insulated Wire Micro-D's
provide EMI
solutions in a miniaturized M83513 Micro-D connector.
These connectors feature ceramic capacitor planar arrays
and ferrite inductors. Insulated wire is factory precision-
crimped to TwistPin contacts for superior reliability in the most
demanding environments.
Choose Pi or C Filter Arrays
in eight filter classes and six
layouts. Glenair filtered Micro-D connectors comply with
applicable MIL-DTL-83513 requirements and are 100%
intermateable with standard connectors.
Choose 9 to 37 Contacts,
with standard cadmium or nickel
plating on the connector housing or choose optional finishes
such as gold or chem film.
240-077
240-077
Aluminum Shell
1
- Cadmium
2
- Nickel
6
- Chem Film
33
- Nickel/PTFE
9, 15, 21, 25, 31, 37
(See Table II)
P
- Pin
S
- Socket
C
- C Filter
P
- Pi Filter
A, B, C,D, E, F, G, J
(See Table I)
4
- 24
6
- 26
8
- 28
0
- 30
K
- M22759/11
J -
M22759/33
E
- NEMA HP3-EB (M16878/4)
1
- White
2 -
Yellow
5 -
Full Color
7
- 10 Color Repeat
18
- 18 Inches
Rear Panel Mount Hardware Option
(See Note 1)
B -
No Hardware
R1-
0.032” (.08) Panel
R2
-
0.047” (.12) Panel
R3
- 0.062” (.16) Panel
R4
- 0.093” (.12) Panel
R5
- 0.125” (.32) Panel
R6
-
0.080” (.20) Panel
G
-
Ground spring installed
N
- No ground spring (N applies to all receptacle assemblies)
(See Note 2)
C
- Conductive
N
- Non-Conductive (Nitrile)
5
- Gold
D
Sample Part Number
Series
Shell Finish
Contact Layout
Contact Type
Filter Type
Filter Class
Wire Gauge
Wire Type
Wire Color/Type
Wire Length
Hardware Option
Plug EMI Ground Spring
O-Ring
ylbmessA gulP P52
How To Order Rear Panel Mount Filter Connectors with Insulated Wire
-2
-25
S
C
F
-6
K
7
-18 R1
N
N
Table I: Micro-D Filter Classes and Performance
Filter Class
C Filter
Pi Filter
A
19000-28000
38000-56000
B
16000-22500
32000-45000
C
D
E
1650-2500
3300-5000
F
400-650
800-1300
G
200-300
400-600
J
35–60
70–120
Capacitance (pF)
9000-16500
4000-6000
18000-33000
8000-12000
© 2013 Glenair, Inc.
Dimensions in inches (millimeters) and are subject to change without notice.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
D-26
E-Mail: sales@glenair.com
240-077
Rear Panel Mount Micro-D Filter Connectors
Insulated Wire
Table II: Dimensions
G
Pi = .750 Max
C = .500 Max
F
C Max
PIN 1
A
B
SKT 1
E MAX
Wire
Length
D
H
Shell Size
9P
9S
15P
15S
21P
21S
25P
25S
31P
31S
37P
37S
A ±.005
in.
mm
0.960
0.960
1.110
1.110
1.260
1.260
1.360
1.360
1.510
1.510
1.660
1.660
24.38
24.38
28.19
28.19
32.00
32.00
34.54
34.54
38.35
38.35
42.16
42.16
B ±.003
in.
mm
0.565
0.565
0.715
0.715
0.865
0.865
0.965
0.965
1.115
1.115
1.265
1.265
14.35
14.35
18.16
18.16
21.97
21.97
24.51
24.51
28.32
28.32
32.13
32.13
C Max
in.
mm
0.334
0.400
0.484
0.550
0.634
0.700
0.734
0.800
0.884
0.950
1.034
1.100
8.48
10.16
12.29
13.97
16.10
17.78
18.64
20.32
22.45
24.13
26.26
27.94
D ±.005
in.
mm
0.480
0.480
0.480
0.480
0.480
0.480
0.480
0.480
0.480
0.480
0.4 80
0.480
12.19
12.19
12.19
12.19
12.19
12.19
12.19
12.19
12.19
12.19
12.19
12.19
E Max
in.
mm
0.184
0.250
0.184
0.250
0.184
0.250
0.184
0.250
0.184
0.250
0.184
0.250
4.67
6.35
4.67
6.35
4.67
6.35
4.67
6.35
4.67
6.35
4.67
6.35
F±.003
in.
mm
0.183
0.195
0.183
0.195
0.183
0.195
0.183
0.195
0.183
0.195
0.183
0.195
4.65
4.95
4.65
4.95
4.65
4.95
4.65
4.95
4.65
4.95
4.65
4.95
G±.005
in.
mm
0.775
0.775
0.925
0.925
1.075
1.075
1.175
1.175
1.325
1.325
1.473
1.473
19.69
19.69
23.50
23.50
27.31
27.31
29.85
29.85
33.66
33.66
37.41
37.41
H Max
in.
mm
0.310
0.310
0.310
0.310
0.310
0.310
0.310
0.310
0.310
0.310
0.310
0.310
7.87
7.87
7.87
7.87
7.87
7.87
7.87
7.87
7.87
7.87
7.87
7.87
Notes
1. Mounting holes fitted with 2x .086-56 threaded insert, .15 min thread.
(T3585-02CPF129).
2. Ground spring not available on cadmium plated assemblies.
3. Interface dimensions per MIL-DTL-83513.
4. Electrical performance:
I.R.: 5000 Megohms min at 100 VDC
D.W.V.: 200 VDC
5. Assembly to be identified with Glenair’s name, part number, date
code, and pin 1 identification.
Materials / Finishes:
•
•
•
•
•
Shell - Aluminum Alloy/See Chart
Insulator - LCP/NA
Contacts - Copper Alloy/Gold Plated
Ground Spring - Stainless Steel/Gold Plated
Socket Interfacial Seal: Flourosilicone
© 2013 Glenair, Inc.
Dimensions in inches (millimeters) and are subject to change without notice.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
D-27
E-Mail: sales@glenair.com
