Amplified Low Pressure Sensors
1 mbar (0.4 In H2O) to 30 In H2O Pressure Sensors
Military Temperature Grade
Features
• 0 to 1 mbar to 0 to 30 In H2O Pressure Ranges
• Ratiometric 4V Output
• Temperature Compensated
(-40C to 125C)
• Calibrated Zero and Span
Applications
• Medical Instrumentation
• Environmental Controls
• HVAC
General Description
The Amplified line of low pressure sensors is based upon a proprietary technology to reduce all output offset or
common mode errors. This model provides a ratiometric 4-volt output with superior output offset characteristics.
Output offset errors due to change in temperature, stability to warm-up, stability to long time period, and position
sensitivity are all significantly reduced when compared to conventional compensation methods. In addition the
sensor utilizes a silicon, micromachined, stress concentration enhanced structure to provide a very linear output
to measured pressure.
These calibrated and temperature compensated sensors give an accurate and stable output over a wide
temperature range. This series is intended for use with non-corrosive, non-ionic working fluids such as air, dry
gases and the like.
The output of the device is ratiometric to the supply voltage over a supply voltage range of 4.5 to 5.5 volts.
f
408 225 2079
a
16035 Vineyard Blvd. Morgan Hill, CA 95037
p
408 225 4314
e
www.allsensors.com
Physical Dimensions
Pin Size
0.010 x 0.020
(0.25 x 0.50)
0.174 to 0.190
(4.4 to 4.8)
Pin 1 2 3 4
1
0.21
(5.3)
A
1.08
(27.4)
0.66
(16.0)
B
0.42
(10.5)
0.25
(6.4)
0.10 Typical
(2.54)
pin 1: Vsupply
pin 2: Common
pin 3: Voutput
pin 4: do not connect
0.48
(12.2)
0.55
(14.0)
0.80
(20.3)
0.85
(21.6)
1.10
(27.9)
NOTES:
1) Dimensions in inches (millimeters)
All Sensors
DS-0026 Rev A
all sensors
Pressure Sensor Ratings
Supply Supply Voltage VS
Common-mode pressure
Lead Temperature, max
(soldering 2-4 sec.)
+4.5 to +5.5 Vdc
-10 to +10 psig
250°C
Environmental Specifications
Temperature Ranges
Compensated
Operating
Storage
Humidity Limits
-40 to 125° C
-40 to 125° C
-40 to 125° C
0 to 95% RH
(non condensing)
Standard Pressure Ranges
Part Number
1 MBAR-D-4V-MIL
1 INCH-D-4V-MIL
1 INCH-G-4V-MIL
5 INCH-D-4V-MIL
5 INCH-G-4V-MIL
10 INCH-D-4V-MIL
10 INCH-G-4V-MIL
20 INCH-D-4V-MIL
20 INCH-G-4V-MIL
30 INCH-D-4V-MIL
30 INCH-G-4V-MIL
Operating Pressure
±1 mbar
±1 In H2O
0 - 1 In H2O
± 5 In H2O
0 - 5 In H2O
±10 In H2O
0 - 10 In H2O
±20 In H2O
0 - 20 In H2O
±30 In H2O
0 - 30 In H2O
Nominal Span
4V
4V
4V
4V
4V
4V
4V
4V
4V
4V
4V
Proof Pressure
100 In H2O
100 In H2O
300 In H2O
200 In H2O
200 In H2O
200 In H2O
200 In H2O
300 In H2O
300 In H2O
500 In H2O
500 In H2O
Burst Pressure
200 In H2O
200 In H2O
200 In H2O
300 In H2O
300 In H2O
300 In H2O
300 In H2O
500 In H2O
500 In H2O
800 In H2O
800 In H2O
Performance Characteristics for: 1 MBAR-D-4V-MIL
Parameter,
NOTE
1
Operating Range, differential pressure
Output Span,
NOTE
Minimum
Nominal
±1.0
Maximum
Units
mbar
5
±1.80
2.00
±2.0
2.25
±2.20
2.50
±120
volt
volt
mvolt
mvolt
mvolt
mvolt
Offset Voltage @ zero differential pressure
Offset Temperature Shift (-40°C-125°C),
NOTE
2
Offset Warm-up Shift,
NOTE
3
±20
±40
±20
0.05
0.25
±4
Offset Position Sensitivity (±1g)
Offset Long Term Drift (one year)
Linearity, hysteresis error,
NOTE
4
Span Shift (-40°C-125°C),
NOTE
2
%fs
%span
Amplified Low Pressure Sensors Military Grade
Performance Characteristics for 1 INCH-D-4V-MIL
Parameter, note 1
Operating Range, differential pressure
Output Span, note 5
Offset Voltage @ zero differential pressure
Offset Temperature Shift (-40°C-125°C),
NOTE
2
Offset Warm-up Shift,
NOTE
3
Offset Position Sensitivity (±1g)
Offset Long Term Drift (one year)
Linearity, hysteresis error,
NOTE
4
Span Shift (-40°C-125°C),
NOTE
2
±10
±5
±10
0.05
0.25
±2
±1.90
2.15
Minimum
Nominal
±1.0
±2.0
2.25
±2.10
2.35
±60
Maximum
Units
“H2O
volt
volt
mvolt
mvolt
mvolt
%fs
%span
Performance Characteristics for 1 INCH-G-4V-MIL
Parameter, note 1
Operating Range, gage pressure
Output Span, note 5
Offset Voltage @ zero pressure
Offset Temperature Shift (-40°C-125°C),
NOTE
2
Offset Warm-up Shift,
NOTE
3
Offset Position Sensitivity (±1g)
Offset Long Term Drift (one year)
Linearity, hysteresis error,
NOTE
4
Span Shift (-40°C-125°C),
NOTE
2
±10
±15
±10
0.05
0.25
±2
3.90
0.15
Minimum
Nominal
1.0
4.0
0.25
4.10
0.35
±60
Maximum
Units
“H2O
volt
volt
mvolt
mvolt
mvolt
mvolt
%fs
%span
a
16035 Vineyard Blvd. Morgan Hill, CA 95037
p
408 225 4314
e
www.allsensors.com
f
408 225 2079
Performance Characteristics for 5 INCH-D-4V-MIL
Parameter, note 1
Operating Range, differential pressure
Output Span, note 5
Offset Voltage @ zero differential pressure
Offset Temperature Shift (-40°C-125°C),
NOTE
2
Offset Warm-up Shift,
NOTE
3
Offset Position Sensitivity (±1g)
Offset Long Term Drift (one year)
Linearity, hysteresis error,
NOTE
4
Span Shift (-40°C-125°C),
NOTE
2
±5
±5
±5
0.05
0.25
±1
±1.90
2.15
Minimum
Nominal
±5.0
±2.0
2.25
±2.10
2.35
±40
Maximum
Units
“H2O
volt
volt
mvolt
mvolt
mvolt
mvolt
%fs
%span
All Sensors
DS-0026 Rev A
all sensors
mvolt
Performance Characteristics for: 5 INCH-G-4V-MIL
Parameter,
NOTE
1
Operating Range, gage pressure
Output Span,
NOTE
Minimum
Nominal
5.0
Maximum
Units
“H2O
5
3.90
0.15
4.0
0.25
4.10
0.35
±40
volt
volt
mvolt
mvolt
mvolt
mvolt
Offset Voltage @ zero pressure
Offset Temperature Shift (-40°C-125°C),
NOTE
2
Offset Warm-up Shift,
NOTE
3
Offset Position Sensitivity (±1g)
Offset Long Term Drift (one year)
Linearity, hysteresis error,
NOTE
4
Span Shift (-40°C-125°C),
NOTE
2
±5
±5
±5
0.05
0.25
±1
%fs
%span
Performance Characteristics for: 10 INCH-D-4V-MIL
Parameter,
NOTE
1
Operating Range, differential pressure
Output Span,
NOTE
5
Offset Voltage @ zero differential pressure
Offset Temperature Shift (-40°C-125°C),
NOTE
2
Offset Warm-up Shift,
NOTE
3
Offset Position Sensitivity (±1g)
Offset Long Term Drift (one year)
Linearity, hysteresis error,
NOTE
4
Span Shift (-40°C-125°C),
NOTE
2
±5
±5
±5
0.05
0.25
±1
±1.90
2.15
Minimum
Nominal
±10.0
±2.0
2.25
±2.10
2.35
±20
Maximum
Units
“H2O
volt
volt
mvolt
mvolt
mvolt
mvolt
%fs
%span
Performance Characteristics for: 10 INCH-G-4V-MIL
Parameter,
NOTE
1
Operating Range, gage pressure
Output Span,
NOTE
Minimum
Nominal
10.0
Maximum
Units
“H2O
5
3.90
0.15
4.0
0.25
4.10
0.35
±20
volt
volt
mvolt
mvolt
mvolt
mvolt
Offset Voltage @ zero pressure
Offset Temperature Shift (-40°C-125°C),
NOTE
2
Offset Warm-up Shift,
NOTE
3
Offset Position Sensitivity (±1g)
Offset Long Term Drift (one year)
Linearity, hysteresis error,
NOTE
4
Span Shift (-40°C-125°C),
NOTE
2
±5
±5
±5
0.05
0.25
±1
%fs
%span
Amplified Low Pressure Sensors Military Grade
Performance Characteristics for 20 INCH-D-4V-MIL
Parameter, note 1
Operating Range, differential pressure
Output Span, note 5
Offset Voltage @ zero differential pressure
Offset Temperature Shift (-40°C-125°C),
NOTE
2
Offset Warm-up Shift,
NOTE
3
Offset Position Sensitivity (±1g)
Offset Long Term Drift (one year)
Linearity, hysteresis error,
NOTE
4
Span Shift (-40°C-125°C),
NOTE
2
±5
±5
±5
0.05
0.25
±1
±1.90
2.15
Minimum
Nominal
±20.0
±2.0
2.25
±2.10
2.35
±20
Maximum
Units
“H2O
volt
volt
mvolt
mvolt
mvolt
mvolt
%fs
%span
Parameter, note 1
Operating Range, gage pressure
Output Span, note 5
Offset Voltage @ zero pressure
Offset Temperature Shift (-40°C-125°C),
NOTE
2
Offset Warm-up Shift,
NOTE
3
Offset Position Sensitivity (±1g)
Offset Long Term Drift (one year)
Linearity, hysteresis error,
NOTE
4
Span Shift (-40°C-125°C),
NOTE
2
Minimum
Nominal
20.0
Maximum
Units
“H2O
3.90
0.15
4.0
0.25
4.1
0.35
±20
volt
volt
mvolt
mvolt
mvolt
mvolt
±5
±5
±5
0.05
0.25
±1
%fs
%span
Performance Characteristics for 30 INCH-D-4V-MIL
Parameter, note 1
Operating Range, differential pressure
Output Span, note 5
Offset Voltage @ zero differential pressure
Offset Temperature Shift (-40°C-125°C),
NOTE
2
Offset Warm-up Shift,
NOTE
3
Offset Position Sensitivity (±1g)
Offset Long Term Drift (one year)
Linearity, hysteresis error,
NOTE
4
Span Shift (-40°C-125°C),
NOTE
2
±5
±5
±5
0.05
0.25
±1
±1.90
2.15
Minimum
Nominal
±30.0
±2.0
2.25
±2.10
2.35
±20
Maximum
Units
“H2O
volt
volt
mvolt
mvolt
mvolt
mvolt
%fs
%span
All Sensors
DS-0026 Rev A
a
16035 Vineyard Blvd. Morgan Hill, CA 95037
p
408 225 4314
f
408 225 2079
e
www.allsensors.com
Performance Characteristics for 20 INCH-G-4V-MIL
all sensors
