Darlington Phototransistors
PNA2602
Darlington Phototransistor
Unit : mm
For optical control systems
ø3.5±0.2
4.5±0.3
Not soldered
4.2±0.3
2.3 1.9
Features
Darlington output, high sensitivity
Easy to combine light emission and photodetection on same
printed circuit board
Small size, thin side-view type package
12.8 min.
10.0 min.
2.8
1.8
1.0
4.8±0.3
2.4 2.4
2-0.98±0.2
2-0.45±0.15
0.45±0.15
2.54
R1.75
1.2
Absolute Maximum Ratings
(Ta = 25˚C)
Parameter
Collector to emitter voltage
Emitter to collector voltage
Collector current
Collector power dissipation
Operating ambient temperature
Storage temperature
Symbol
V
CEO
V
ECO
I
C
P
C
T
opr
T
stg
Ratings
20
5
30
100
–25 to +80
–30 to +100
Unit
V
V
mA
mW
˚C
˚C
1
2
1: Emitter
2: Collector
Electro-Optical Characteristics
(Ta = 25˚C)
Parameter
Dark current
Collector photo current
Peak sensitivity wavelength
Acceptance half angle
Response time
Collector saturation voltage
*1
Symbol
I
CEO
I
CE(L)
λ
P
θ
t
r
, t
f*2
V
CE(sat)
V
CE
= 10V
Conditions
V
CE
= 10V, L = 2 lx
*1
V
CE
= 10V
Measured from the optical axis to the half power point
V
CC
= 10V, I
CE(L)
= 5mA, R
L
= 100Ω
I
CE(L)
= 1mA, L = 100 lx
*1
min
0.2
typ
0.1
1
800
35
100
0.7
max
0.5
Unit
µA
mA
nm
deg.
µs
1.5
V
Measurements were made using a tungsten lamp (color temperature T = 2856K) as a light source.
*2
Switching time measurement circuit
Sig.IN
V
CC
(Input pulse)
Sig.OUT
(Output pulse)
90%
10%
t
d
t
r
t
f
t
d
: Delay time
t
r
: Rise time (Time required for the collector photo current to
increase from 10% to 90% of its final value)
t
f
: Fall time (Time required for the collector photo current to
decrease from 90% to 10% of its initial value)
,,
,,
50Ω
R
L
1
PNA2602
Darlington Phototransistors
P
C
— Ta
120
32
I
CE(L)
— V
CE
10
3
Ta = 25˚C
T = 2856K
I
CE(L)
— L
I
CE(L)
(mA)
V
CE
= 10V
Ta = 25˚C
T = 2856K
P
C
(mW)
100
I
CE(L)
(mA)
P
C
= 100mW
24
10
2
Collector power dissipation
80
Collector photo current
L = 30 lx
16
20 lx
10 lx
8
5 lx
2 lx
1 lx
0
4
8
12
16
20
24
Collector photo current
60
10
40
1
20
0
– 20
0
20
40
60
80
100
0
10
–1
1
10
10
2
10
3
Ambient temperature
Ta (˚C )
Collector to emitter voltage
V
CE
(V)
Illuminance L (lx)
I
CE(L)
— Ta
10
V
CE
= 10V
T = 2856K
10
2
I
CEO
— Ta
100
V
CE
= 10V
Spectral sensitivity characteristics
Ta = 25˚C
I
CE(L)
(mA)
10
1
Dark current I
CEO
(µA)
Collector photo current
10
–1
Relative sensitivity
0
20
40
60
80
100
1
S (%)
10
–2
10
–3
– 20
80
60
40
10
–1
20
10
–2
– 40
0
40
80
120
0
200
400
600
800
1000
1200
Ambient temperature
Ta (˚C )
Ambient temperature
Ta (˚C )
Wavelength
λ
(nm)
Directivity characteristics
0˚
100
Sig.IN
90
80
70
60
50
40
30
20
10˚
20˚
t
r
— I
CE(L)
V
CC
Sig.
OUT
R
L
90%
10%
Sig.IN
Sig.
OUT
50Ω
t
f
— I
CE(L)
V
CC
Sig.
OUT
R
L
90%
10%
Relative sensitivity S (%)
,,
,
30˚
Rise time t
r
(µs)
40˚
50˚
60˚
70˚
80˚
90˚
10
3
Fall time t
f
(µs)
R
L
= 1kΩ
500Ω
,
10
3
10
2
10
10
–2
10
–1
Sig.
OUT
50Ω
t
r
t
d
t
f
t
r
t
d
t
f
R
L
= 1kΩ
500Ω
100Ω
10
2
100Ω
V
CC
= 10V
Ta = 25˚C
10
–1
1
10
10
10
–2
V
CC
= 10V
Ta = 25˚C
1
10
Collector photo current
I
CE(L)
(mA)
Collector photo current
I
CE(L)
(mA)
2
