Electrical / Environmental
•
Operating Temperature Range
• Ambient Temperature, Maximum
-40°C to +125°C
85°C
Vertical Mount Inductors
HM17A
S
RoH
liant
mp
Co
Schematic
*(1,2)
Note : Part number ends with * is 4 terminal hook up
*(3,4)
Outline Dimensions (mm)
Top View
Side View
Bottom View
Case Size
A
106
10.0
108
10.0
1010
10.0
B
6.0
8.0
10.0
C
3.5
3.5
3.5
D
5.0
5.0
5.0
D1
4.0
4.0
4.0
E
0.7
0.7
0.7
Packaging
Standard:
Boxes
Capacity = 100 Units
Carton
Capacity = 6000 Units
20
Last Updated : 12 May 2011
MAGNETIC COMPONENTS SELECTOR GUIDE 2009/10 EDITION
We reserve the right to change specifications without prior notice.
www.bitechnologies.com
Specifications @ 25°C
Inductance
Part
Number
HM17A-106100LF
HM17A-106120LF
HM17A-106150LF
HM17A-106180LF
HM17A-106220LF
HM17A-106270LF
HM17A-106330LF
HM17A-106390LF
HM17A-106470LF
HM17A-106560LF
HM17A-106680LF
HM17A-106820LF
HM17A-106101LF
HM17A-106121LF
HM17A-106151LF
HM17A-106181LF
HM17A-106221LF
HM17A-106271LF
HM17A-106331LF
HM17A-106391LF
HM17A-106471LF
HM17A-106561LF
HM17A-106681LF
HM17A-106821LF
HM17A-106102LF
HM17A-108100LF*
HM17A-108120LF*
HM17A-108150LF*
HM17A-108180LF
HM17A-108220LF
HM17A-108270LF
HM17A-108330LF
HM17A-108390LF
HM17A-108470LF
HM17A-108560LF
HM17A-108680LF
HM17A-108820LF
HM17A-108101LF
Lo
Tol.
(1)
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 10%
Inductance
Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
100
100
1
1
1
1
1
1
1
1
1
1
1
1
1
100
100
100
100
100
100
100
100
100
100
100
100
1
I
rated
(Adc)
3.60
3.30
2.90
2.70
2.40
2.20
2.00
1.80
1.70
1.50
1.40
1.30
1.30
1.20
1.00
0.84
0.76
0.69
0.62
0.57
0.52
0.48
0.43
0.40
0.36
4.50
4.10
3.70
3.40
3.10
2.80
2.50
2.30
2.10
1.90
1.70
1.60
1.40
(2)
(µ
H)
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
10
12
15
18
22
27
33
39
47
56
68
82
100
(
%)
DCR
(
W)
Max.
0.040
0.044
0.058
0.064
0.088
0.100
0.110
0.140
0.160
0.190
0.220
0.290
0.320
0.380
0.500
0.560
0.780
0.920
1.100
1.300
1.500
1.900
2.200
2.600
3.200
0.027
0.031
0.036
0.049
0.055
0.062
0.078
0.087
0.099
0.130
0.140
0.160
0.210
Part
Lo
Number
(µ
H)
HM17A-108121LF
120
HM17A-108151LF
150
HM17A-108181LF
180
HM17A-108221LF
220
HM17A-108271LF
270
HM17A-108331LF
330
HM17A-108391LF
390
HM17A-108471LF
470
HM17A-108561LF
560
HM17A-108681LF
680
HM17A-108821LF
820
HM17A-108102LF
1000
HM17A-1010100LF* 10
HM17A-1010120LF* 12
HM17A-1010150LF* 15
HM17A-1010180LF* 18
HM17A-1010220LF* 22
HM17A-1010270LF* 27
HM17A-1010330LF* 33
HM17A-1010390LF
39
HM17A-1010470LF
47
HM17A-1010560LF
56
HM17A-1010680LF
68
HM17A-1010820LF
82
HM17A-1010101LF 100
HM17A-1010121LF 120
HM17A-1010151LF 150
HM17A-1010181LF 180
HM17A-1010221LF 220
HM17A-1010271LF 270
HM17A-1010331LF 330
HM17A-1010391LF 390
HM17A-1010471LF 470
HM17A-1010561LF 560
HM17A-1010681LF 680
HM17A-1010821LF 820
HM17A-1010102LF 1000
Tol.
(1)
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
(
%)
Test
Freq.
(kHz)
1
1
1
1
1
1
1
1
1
1
1
1
100
100
100
100
100
100
100
100
100
100
100
100
1
1
1
1
1
1
1
1
1
1
1
1
1
I
rated
(Adc)
1.30
1.20
1.10
0.96
0.87
0.79
0.72
0.66
0.60
0.55
0.50
0.45
5.30
4.90
4.40
4.00
3.60
3.30
2.90
2.70
2.50
2.30
2.10
1.90
1.70
1.50
1.40
1.30
1.10
1.00
0.93
0.86
0.78
0.71
0.65
0.59
0.53
(2)
DCR
(
W)
Max.
0.240
0.320
0.350
0.450
0.610
0.690
0.780
1.000
1.200
1.400
1.800
2.100
0.022
0.023
0.026
0.033
0.037
0.048
0.055
0.073
0.083
0.092
0.120
0.140
0.160
0.200
0.230
0.310
0.340
0.400
0.520
0.650
0.710
1.000
1.100
1.300
1.700
Notes:
(1) Tolerance : 10 ~ 82μH ± 20% (M), 100 ~ 1000 μH ±10% (K).
(2) I
rated
is the DC current at which inductance will be decreased by approximately 10% from its initial (zero DC) value.
Ordering Information
HM17A - 106
Model Series
Case Size:
106, 108, 1010
100
LF
Lead-Free
Inductance Code:
First 2 digits are significant. Last digit
denotes the number of trailing zeros.
www.bitechnologies.com
2009/10 EDITION MAGNETIC COMPONENTS SELECTOR GUIDE
21
We reserve the right to change specifications without prior notice.
