0.46
11.8
0.26
6.7
0.06
1.4
0.45
11.4
0.05
1.4
0.093
2.35
0.097
2.5
#12-48 NS THREAD
SECTION A-A
1.05
26.5
0.53
13.5
0.12
3.0
A
0.29
7.4
0.125
3.18
REF
0.26
6.6
NOTES:
1. MATERIALS:
TIP, BODY, AND COUPLING RING - COPPER ALLOY, NICKEL PLATED
CLAMP - COPPER ALLOY, TIN PLATED
INSULATION - THERMOPLASTIC, DARK GRAY
HANDLE - ANODIZED ALUMINUM, SEE TABLE FOR COLOR
2. COUPLING RING HAS A #10-48 NS-2B THREAD. 0.050 MINIMUM
THREAD PROJECTION OF JACK FOR PROPER LOCK.
3. HANDLE IS SHIPPED UNASSEMBLED.
4. THIS PRODUCT IS RoHS COMPLIANT.
A
REV
PART NUMBER
853X
858X
883X
HANDLE COLOR
BLACK
RED
CLEAR ANODIZED
A
CUSTOMER DRAWING
THIS DRAWING DESCRIBES A DESIGN CONSIDERED PROPRIETARY IN NATURE, DEVELOPED AND MANUFACTURED
BY SWITCHCRAFT INC. AND IS RELEASED ON A CONFIDENTIAL BASIS FOR IDENTIFICATION PURPOSES ONLY.
UNLESS OTHERWISE SPECIFIED
1. ALL DIMENSIONS IN INCHES [mm]
- TWO PLACE DECIMALS
- THREE PLACE DECIMALS
0.02
[0.5]
SIZE
FINISH
WIDTH
MULT
LBS/M
MATERIAL
SPEC No.
TEMPER
0.005 [0.13]
SPEC No.
FIRST USED ON
DATE DRAWN
BY
CHKD
SCALE
6:1
26062
ECO NUMBER
06-28-06
DATE
TO
BY
TJK
APVD
01-24-08
AH
AH
01-24-08
TJK
01-24-08
PART No.
APVD
SHEET
1
OF
1
REV
REVISIONS
DO NOT SCALE DRAWING
NAME
2 CONDUCTOR, LOCKING
MICRO-PLUG ASSEMBLY, RoHS
853X, 858X, 883X
A
SolidWorks CAD File
B
