PS (ADP4)/PF (ADP1)
High precision
pressure sensor
(without amp.)
PS/PF PRESSURE
SENSOR
TYPICAL APPLICATIONS
(Please evaluate under actual conditions
before using.)
• Industrial use (pressure switches
and pneumatic devices, etc.)
• Medical use (blood pressure
monitors, compressed air pressure
measurement, air beds, etc.)
• Other pneumatically operated
pressure devices
FEATURES
1. Ultra-miniature size (for PS
pressure sensor)
2. High-level precision and linearity
3. Impressive line-up of models
• Taking their place alongside the
standard 5kΩ bridge resistance models
are those with a 3.3kΩ resistance which
is optimally suited to 5V drive circuits.
• Economy model (no glass base) gives
outstanding value for consumer
appliances
40 kPa (0.4 kgf/cm
2
) and 49 kPa (0.5 kgf/
cm
2
) units are also available.
PS pressure sensor
PF pressure sensor
RoHS compliant
ORDERING INFORMATION
ADP
<Product name>
1: PF pressure sensor
4: PS pressure sensor
<Terminal profile and direction>
1: DIP terminal (Direction opposite the
pressure inlet direction)
2: DIP terminal (Pressure inlet direction)
<Rated pressure>
0: 4.9 kPa
2: 34.3 kPa
3: 49.0 kPa
4: 98.1 kPa
5: 196.1 kPa
6: 343.2 kPa
7: 490.3 kPa
8: 833.6 kPa
9: 980.7 kPa
A: 40.0 kPa
<Type>
1: Standard type (With glass base)
2: Economy type (Without glass base)
<Bridge resistance>
Nil: PF 5kΩ
0: PS 5kΩ
3: 3.3kΩ
Note: Some part numbers may not be available depending on the combination.
Please refer to the Table of Product Types.
ASCTB86E 201407-T1
PS (ADP4)/PF (ADP1)
TYPES
1. DIP terminal
Brige resistance
5kΩ
Terminal
Part No.
PS pressure sensor
3.3kΩ
5kΩ
PF pressure sensor
3.3kΩ
Pressure
DIP terminal:
Direction
opposite the
pressure inlet
direction
4.9kPa
34.3kPa
49.0kPa
ADP41010
ADP41210
ADP41310
ADP41410
ADP41510
ADP41610
ADP41710
ADP41810
ADP41910
—
DIP terminal:
Pressure inlet
direction
DIP terminal:
Direction
opposite the
pressure inlet
direction
—
—
—
ADP41413
—
—
—
—
ADP41913
ADP41A23
DIP terminal:
Pressure inlet
direction
DIP terminal:
Direction
opposite the
pressure inlet
direction
ADP1101
ADP1121
ADP1131
ADP1141
ADP1151
ADP1161
ADP1171
ADP1181
ADP1191
—
DIP terminal:
Pressure inlet
direction
DIP terminal:
Direction
opposite the
pressure inlet
direction
—
—
—
—
—
—
—
—
—
ADP11A23
DIP terminal:
Pressure inlet
direction
ADP42010
ADP42210
ADP42310
ADP42410
ADP42510
ADP42610
ADP42710
ADP42810
ADP42910
—
—
—
—
ADP42413
—
—
—
—
ADP42913
ADP42A23
ADP1201
ADP1221
ADP1231
ADP1241
ADP1251
ADP1261
ADP1271
ADP1281
ADP1291
—
—
—
—
—
—
—
—
—
—
ADP12A23
Standard type
(with glass
base)
98.1kPa
196.1kPa
343.2kPa
490.3kPa
833.6kPa
980.7kPa
Economy type
(without glass
base)
40.0kPa
Standard packing: Carton: 100 pcs.; Case: 1,000 pcs.
RATING
Type
Type of pressure
Pressure medium
Rated pressure
Unit: kPa
Max. applied pressure
Bridge resistance
Ambient temperature
Storage temperature
Standard temperature
Temperature compensation
range
Drive current
(constant current)
Output span voltage
Offset voltage
Linearity
Pressure hysteresis
Offset voltage-temperature
characteristics*
4
Sensitivity-temperature
characteristics*
4
Notes: *1.
*2.
*3.
*4.
*5.
Standard type (With glass base)
Gauge pressure
Air*
2
833.6
980.7
1.5 times the rated pressure
Economy type
(Without glass
base)
4.9
34.3 to 343.2
Twice the rated pressure
490.3
5000±1000Ω
98.1*
3
980.7*
3
Twice the rated
1.5 times the
pressure
rated pressure
3300±700Ω
–20 to 100°C
–4 to 212°F
(no freezing or condensation)
–40 to 120°C
–40 to 248°F
(no freezing or condensation)
25°C
77°F
0 to 50°C
32 to 122°F
1.5 mA DC
40±20 mV
±0.7%FS
±0.6%FS
±15%FS
±10%FS
±0.3%FS
±0.2%FS
100±40 mV
±20
mV
±0.5%FS
±0.6%FS
±0.4%FS
±5.0%FS
±2.5%FS
30°C
86°F
0 to 60°C
32 to 140°F
1.0 mA DC
65±25 mV
±1.0%FS
±1.0%FS
±3.5%FS
40.0
Twice the rated
pressure
3300±600Ω
–5 to +50°C
+23 to +122°F
–20 to +70°C
–4 to +158°F
25°C
77°F
5 to 45°C
41 to 113°F
1.5 mA DC
43.5±22.5 mV
±15
mV
±0.3%FS
±0.7%FS
±10%FS
±1.3%FS
Unless otherwise specified, measurements were taken with a drive current of
±0.01
mA and humidity ranging from 25% to 85%.
Please consult us if a pressure medium other than air is to be used.
For PS pressure sensor only
This is the regulation which applies within the compensation temperature range.
Please consult us if the intended use involves a negative pressure.
ASCTB86E 201407-T1
PS (ADP4)/PF (ADP1)
REFERENCE DATA
[PS pressure sensor]
1. Characteristics data
1.-(1) Output characteristics
ADP41913
Drive current: 1.0 mA; temperature: 30°C
86°F
60
1.-(2) Offset voltage – temperature
characteristics
ADP41913
Drive current: 1.0 mA; rating
±3.5%FS
Offset voltage – temperature characteristics (%FS)
4
1.-(3) Sensitivity – temperature characteristics
ADP41913
Drive current: 1.0 mA; rating
±2.5%FS
4
Sensitivity – temperature characteristics (%FS)
3
50
Output voltage (mV)
3
40
2
2
30
1
1
20
0
0
10
–1
–1
0
0
980.7/2
Pressure, kPa
980.7
–2
0
+32
30
+86
Temperature,
°C
°F
60
+140
–2
0
+32
30
+86
Temperature,
°C
°F
60
+140
2. Pressure cycle range (0 to rated pressure)
Tested sample: ADP41913, temperature: 100°C
212°F,
No. of cycle: 1×10
6
Offset voltage range
3
Output span voltage range
3
1
Output span voltage range (%FS)
2
2
Even after testing for 1 million times,
the variations in the offset voltage and
output span voltage are minimal.
Offset voltage range (%FS)
1
0
0
–1
–1
–2
–2
–3
0
5×10
5
Pressure cycle, cycle
1×10
6
–3
0
5×10
5
Pressure cycle, cycle
1×10
6
[PF pressure sensor]
1. Characteristics data
1-(1) Output characteristics
ADP1141
Drive current: 1.5 mA; temperature: 25°C
77°F
100
Offset voltage – temperature characteristics (%FS)
80
60
40
20
0
–20
–40
1-(2) Offset voltage – temperature
characteristics
ADP1141
Drive current: 1.5 mA; rating
±5%FS
4
3
1-(3) Sensitivity – temperature characteristics
ADP1141
Drive current: 1.5 mA; rating
±2.5%FS
4
Sensitivity – temperature characteristics (%FS)
3
Output voltage (mV)
2
2
1
1
0
0
–1
–1
0
49
Pressure, kPa
98.1
–2
0
32
25
47
Temperature,
°C
°F
50
122
–2
0
32
25
47
Temperature,
°C
°F
50
122
ASCTB86E 201407-T1
PS (ADP4)/PF (ADP1)
2. Pressure cycle range (0 to rated pressure)
Tested sample: ADP1131, temperature: 25°C
77°F
Offset voltage range
2
Output span voltage range
2
1
Output span voltage range (%FS)
Even after testing for 1 million times,
the variations in the offset voltage and
output span voltage are minimal.
Offset voltage range (%FS)
1
0
0
–1
–1
–2
0
1×10
5
5×10
5
1×10
6
–2
0
1×10
5
5×10
5
1×10
6
Pressure cycle, cycle
Pressure cycle, cycle
Evaluation test
Classification
Tested item
Storage at high temperature
Storage at low temperature
Environmental
characteristics
Humidity
Temperature cycle
Endurance
characteristics
High temperature/high humidity
operation
Vibration resistance
Mechanical
characteristics
Tested condition
Temperature: Left in a 120°C
248°F
constant temperature bath
Time: 1,000 hrs.
Temperature: Left in a –40°C
–40°F
constant temperature bath
Time: 1,000 hrs.
Temperature/humidity: Left at 40°C
104°F,
90% RH
Time: 1,000 hrs.
Temperature: –40°C to 120°C
–40°F to 248°F
1 cycle: 30 Min.
Times of cycle: 100
Temperature/humidity: 40°C
104°F,
90% RH
Operation times: 10
6
, rated voltage applied
Double amplitude: 1.5 mm
.059 inch
Vibration: 10 to 55 Hz
Applied vibration direction: X, Y, Z 3 directions
Times: 2 hrs each
Dropping height: 75 cm
29.528 inch
Times: 2 times
Pulling strength: 9.8 N {1 kgf}, 10 sec.
Bending strength: 4.9 N {0.5 kgf}, left and right 90° 1 time
Temperature: 230°C
446°F
Time: 5 sec.
Temperature: 260°C
500°F
Time: 10 sec.
Result
Passed
Passed
Passed
Passed
Passed
Passed
Dropping resistance
Terminal strength
Passed
Passed
Passed
Passed
Soldering
resistance
Soldered in DIP soldering bath
Temperature
Note: For details other than listed above, please consult us.
ASCTB86E 201407-T1
PS (ADP4)/PF (ADP1)
DIMENSIONS
(mm
inch)
CAD Data
7.2
.283
The CAD data of the products with a
CAD Data
mark can be downloaded from: http://industrial.panasonic.com/ac/e/
[PS pressure sensor]
1. Terminal direction: DIP terminal Direction opposite the pressure inlet direction ADP41
Recommended PC board pattern
(BOTTOM VIEW)
6-0.9 dia.
6-.035 dia.
Pressure inlet hole
1.1 dia.
.043 dia.
7.2
.283
7.5
.295
4 dia.
.157 dia.
2.5 dia.
.098 dia.
4
.157
5
.197
3.5
.138
4.6
.181
0.5
.020
2.5
.098
1
Atmospheric pressure
inlet hole
JAPAN
2
3
+Input 1
R
2
8.2 Max.
.323 Max.
R 0.2
R .008
2.5
.098
2.5
.098
Terminal connection diagram
2 +Output
R
1
3
4
R
3
R
4
6 is no connection
5 –Output
–Input
2.5
.098
0.25
.010
9.5
.374
Terminal No.
1
Name
Power supply (+)
Output (+)
Power supply (–)
Power supply (–)
Output (–)
No connection
6
5
4
General tolerance:
±0.3
±.012
2
3
4
5
6
Note: Leave terminal 6 unconnected.
2. Terminal direction: DIP terminal Pressure inlet direction ADP42
CAD Data
7.2
.283
5d
.197
ia.
dia.
Recommended PC board pattern
(BOTTOM VIEW)
6-0.9 dia.
6-.035 dia.
Pressure inlet hole
1.1 dia.
.043 dia.
7.2
.283
9.5
.374
4 dia.
.157 dia.
7.5
.295
2.5
.098
2.5
.098
0.5
.020
4
5
.157 .197
3.5
.138
0.25
.010
2.5 dia.
.098 dia.
R 0.2
R .008
2.5
.098
2.5
.098
3.7
.164
Terminal connection diagram
2 +Output
Atmospheric pressure
inlet hole
1
2
3
JAPAN
8.2 Max.
.323 Max.
+Input 1
R
2
R
1
3
4
–Input
R
3
R
4
6 is no connection
5 –Output
6
5
4
General tolerance:
±0.3
±.012
Terminal No.
1
2
3
4
5
6
Name
Power supply (+)
Output (+)
Power supply (–)
Power supply (–)
Output (–)
No connection
Note: Leave terminal 6 unconnected.
ASCTB86E 201407-T1
京公网安备 11010802033920号
EEWORLD
