145.20
[5.717]
A
135.00
[5.315]
35.05
[1.380]
INSIDE
HEIGHT
111.00
[4.370]
B
B
121.20
[4.772]
115.00
[4.528]
INSIDE
WIDTH
5.60
[.220]
2.00
[.079]
A
TOP VIEW
39.30
[1.547]
SECTION A-A
END VIEW
126.00
[4.961]
Enclosures can be Factory Modified ( Milling, Drilling, Printing etc.)
Contact Factory
mjm@hammondmfg.com for quotes
Solid models of this enclosure available in STEP or IGES.
(Part number and text placement/orientation on our products are subject to change,
we do not recommend using them as a locating reference for modification purposes)
35.20
[1.386]
2.25
[.089]
4X 6-32 UNC
0.08
0.45
NOTE
Purchased assembly includes box, lid and 4 cover screws.
Box and lid are made from Diecast Aluminum Alloy.
Silicone Gasket supplied with liquid resistant enclosure.
139.00
[5.472]
INSIDE LENGTH
116.70
[4.594]
140.70
[5.539]
102.00
[4.016]
Recommended Torque: 50-55 cN.m [71-78 ozf.in]
Recommended Torque with Gasket : 25-30 cN.m [36-43 ozf.in]
SECTION B-B
SIDE VIEW
137.07
[5.396]
PART NUMBERS
1590XX Enclosure
1590XX
Natural Finish Enclosure
1590XXBK
Black Textured Enclosure
1590XX Liquid Resistant Enclosure (Silicone Gasket)
1590W XX
Natural Finish Enclosure
1590WXXBK
Black Textured Enclosure
ACCESSORIES
121.78
[4.794]
4X
4.10
[.161]
4.10
[.161]
INSIDE BOX
Liquid Resistant Cover Screws
Stainless Steel Cover Screw s (Pkg 100)
[6-32 x 1/2" W ith O-Ring]
Black Stainless Steel Cover Screw s (Pkg 100)
[6-32 x 1/2" With O-Ring]
1590W MS100
1590WMS100BK
112.78
[4.440]
4.21
[.166]
97.70
[3.846]
Standard Cover Screws
Plated Cover Screw s (Pkg 100)
[6-32 x 1/2"]
Black Cover Screw s (Pkg 100)
[6-32 x 1/2"]
1590MS100
1590MS100BK
INSIDE LID
1.50
[.059]
Dimensions:
mm
[inches]
1590XX
www.hammondmfg.com
®
