3M™ Mini Serial Attached SCSI (miniSAS) Connector/Shell
Vertical Receptacle/Vertical Shell
8A36/8B36 Series
• 6 Gb/s input/output connector for server
applications
• Surfacemount termination on receptacle
• Multiple tail types available for board assembly
on shell guide
• Multiple pin lengths for a range of board
thicknesses on shell guide
• Multiple backshell polorization options for
cable assemblies on shell guide
• Meets SFF-8086 Specification
• Meets SAS Specification, SAS-1.1
• See Regulatory Information Appendix (RIA)
for chemical compliance information
Date Modified: February 23, 2007
TS-2218-01
Sheet 1 of 6
Physical
Insulation
Material:
High Temperature Thermoplastic
Flammability:
UL 94V-0
Color:
Black
Contact
Material:
Copper Alloy
Plating
Underplating:
50 µ" [ 1.27 µm ] Nickel
Wiping Area:
30 µ" [ 0.76 µm ] Gold
Solder Tails:
100 µ" [ 2.54 µm ] Matte Tin
Backshell
Material:
Stainless Steel
Wiping Area:
30 µ" 0.76 µm ] Nickel on tails only
Electrical
Connector
Current Rating:
Per Contact: 0.5 A
300 V
DC
min. for 1 minute
Insulation Resistance:
10
3
MΩ min.
Withstanding Voltage:
Environmental
Operating Temperature:
-20°C
to +85°C
3
Interconnect Solutions
http://www.3M.com/interconnects/
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
3M™ Mini Serial Attached SCSI (miniSAS) Connector/Shell
Vertical Receptacle/Vertical Shell
Receptacle Component
8A36/8B36 Series
1 6 .0 0
[0 .6 3 0 ]
1 5 .8 0
[0 .6 2 2 ]
7 .0 0
6 .6 0
[0 .2 7 6 ] [0 .2 6 0 ]
2 X 1 .4 0 ± 0 .0 5
[Ø 0 .0 5 5 ± 0 .0 0 2 ]
3 6 X 0 .2 0
[0 .0 0 8 ]
6 .6 0
[0 .2 6 0 ]
7 .0 0
[0 .2 7 6 ]
3 4 X 0 .8 0
[0 .0 3 1 ]
1 7 .4 0
[0 .6 8 5 ]
3 .7 0 ± 0 .0 8
[0 .1 4 6 ± 0 .0 0 3 ]
0 .9 8
[0 .0 3 9 ]
3 5 X 0 .4 0
[0 .0 1 6 ]
1 4 .0 0
[0 .5 5 1 ]
2 .9 1 ± 0 .1 3
[0 .1 1 5 ± 0 .0 0 5 ]
6 .0 0
[0 .2 3 6 ]
mm
[inch]
Tolerance Unless Noted
.0
.00
.000
± .05
mm ± .25 ± .15
[ ] Dimensions for Reference
Only
TS-2218-01
Sheet 2 of 6
3
Interconnect Solutions
http://www.3M.com/interconnects/
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
3M™ Mini Serial Attached SCSI (miniSAS) Connector/Shell
Vertical Receptacle/Vertical Shell
8A36/8B36 Series
Receptacle PC Board Layout
1 3 .6 0
[0 .5 3 5 ]
3 6 X 0 .3 5 ± 0 .0 3
[0 .0 1 4 ± 0 .0 0 1 ]
0 .0 5
3 6 X 1 .8 0 ± 0 .0 3
[0 .0 7 1 ± 0 .0 0 1 ]
0 .0 5
A B
A B
7 .0 0
[0 .2 7 6 ]
6 .6 0
[0 .2 6 0 ]
8 .0 0
[0 .3 1 5 ]
B
A
2 .9 5
[0 .1 1 6 ]
2 .9 5
[0 .1 1 6 ]
3 4 X 0 .8 0
[0 .0 3 1 ]
6 .6 0
[0 .2 6 0 ]
1 3 .6 0
[0 .5 3 5 ]
1 6 .0 0
[0 .6 3 0 ]
B
mm
[inch]
Tolerance Unless Noted
.0
.00
.000
± .05
A
7 .0 0
[0 .2 7 6 ]
mm ± .25 ± .15
[ ] Dimensions for Reference
Only
Ordering Information
8A 36 - 1 0 3 0 - LJ
(RIA E1 & C1 Apply)
TS-2218-01
Sheet 3 of 6
3
Interconnect Solutions
http://www.3M.com/interconnects/
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
3M™ Mini Serial Attached SCSI (miniSAS) Connector/Shell
Vertical Receptacle/Vertical Shell
Shell Component
4 .0 1
[0 .1 5 8 ]
4 .0 0
[0 .1 5 7 ]
8A36/8B36 Series
1 2 .1 2
[0 .4 7 7 ]
1 1 .1 2
[0 .4 3 8 ]
4 .0 0
[0 .1 5 7 ]
4 .0 1
[0 .1 5 8 ]
8 .7 2
[0 .3 4 3 ]
2 0 .1 8
[0 .7 9 5 ]
X*
1 7 .8 0
[0 .7 0 1 ]
1 9 .6 5
[0 .7 7 4 ]
4 .0 3
[0 .1 5 9 ]
2 .0 3
[0 .0 8 0 ]
6 .0 3
[0 .2 3 7 ]
S M T TYPE
K IN K T Y P E
x*
1 2 .1 2
[0 .4 7 7 ]
1 1 .1 2
[0 .4 3 8 ]
2 .0 3
[0 .0 8 0 ]
6 .0 3
[0 .2 3 8 ]
8 .7 2
[0 .3 4 3 ]
2 0 .1 8
[0 .7 9 5 ]
mm
[inch]
X*
1 7 .8 0
[0 .7 0 1 ]
6 .0 3
[0 .2 3 7 ]
9 .2 7
[0 .3 6 5 ]
2 .0 3
[0 .0 8 0 ]
4 .0 3
[0 .1 5 9 ]
1 0 .2 7
[0 .4 0 4 ]
Tolerance Unless Noted
.0
.00
.000
± .05
mm ± .25 ± .15
D IP A N D K IN K T Y P E
[ ] Dimensions for Reference
Only
TS-2218-01
Sheet 4 of 6
3
Interconnect Solutions
http://www.3M.com/interconnects/
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
3M™ Mini Serial Attached SCSI (miniSAS) Connector/Shell
Vertical Receptacle/Vertical Shell
8A36/8B36 Series
Shell Component PC Board Layout (SMT)
0.25 TYP
[0.010]
8.90
[0.350]
2.00
[0.079]
0.50 TYP
[0.020]
3.05
[0.120]
0.54
[0.021]
B
6X 203
[0.080]
2X Ø 1.55±0.05
[Ø 0.061±0.002]
2.96
[0.117]
5.05
[0.199]
1.05
[0.041]
7.49±0.13
[0.295±0.005]
A
A
2.00
[0.079]
3.46
[0.136]
6X 1.20
[0.047]
16.00
[0.630]
17.80
[0.701]
20.80±0.13
[0.819±0.005]
3X Ø 1.08±0.03
[Ø 0.043±0.001]
AN N U LAR R IN G
FO R PLATED
TH R U H O LE
3X Ø 0.80±0.05
[Ø 0.031±0.002]
0.05
A B
6X 1.50
[0.059]
B
4.03
[0.159]
5.28±0.13
[0.208±0.005]
SM T TYPE
mm
[inch]
Tolerance Unless Noted
.0
.00
.000
± .05
mm ± .25 ± .15
[ ] Dimensions for Reference
Only
TS-2218-01
Sheet 5 of 6
3
Interconnect Solutions
http://www.3M.com/interconnects/
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
