72
Contacts
3719-1
Circuit Pattern:
Contacts:
Width/Thick:
Height:
16-Pin DIP Capacity:
Material:
Wire-Wrap Terminals:
Wire-Wrap Socket Pins:
Solder Connector:
Extender:
Rec. Card Cage:
Wire-Wrap Connector:
Hole Diameter:
Prototyping Boards
(Plugbords™)
VECTORBORD
®
4.5" x 6.5"
Contacts Only
36/72 @ .100" Ctrs,
Ni/Gold
6.50"/.062"
4.50"
50
CEM-1
T44, T46, T49, T68
R32
R636-2
3690-4
Series 13
R636-1
.042"
• Unrestricted component
placement over entire board
surface
• Layout paper and instructions
included
• Row and column legends
provided
3719-6
Circuit Pattern:
Contacts:
Width/Thick:
Height:
16-Pin DIP Capacity:
Material:
Wire-Wrap Terminals:
Wire-Wrap Socket Pins:
Solder Connector:
Extender:
Rec. Card Cage:
Wire-Wrap Connector:
Hole Diameter:
4.5" x 6.5"
Pad-Per-Hole
36/72 @ .100" Ctrs,
Ni/Gold
6.50"/.062"
4.50"
40
FR4 Epoxy Glass
T44, T46, T49, T68
R32
R636-2
3690-4
Series 13
R644-1
.042"
• 0.080" diameter, isolated solder
pad around holes, plated-thru
holes
• Low resistance, etched
peripheral bus pattern
• Pad and bus surfaces solder-
coated for user convenience
• Convenient, easy-to-read hole
marking legend on board
surface
• Layout paper and instructions
included
4066-4
Circuit Pattern:
6.5"
Contacts:
Width/Thick:
Height:
16-Pin DIP Capacity:
Material:
Wire-Wrap Terminals:
Wire-Wrap Socket Pins:
Solder Connector:
Extender:
Rec. Card Cage:
Wire-Wrap Connector:
Hole Diameter:
4.5" x
Ground Plane/
Interleaved Buses
36/72 @ .100" Ctrs,
Ni/Gold
6.50"/.062"
4.50"
34
CEM-1
T44, T46, T49, T68
R32
R636-2
3690-4
Series 13
R636-1
.042"
• Overall ground plane on wiring
side; etched, interleaved zig-zag
bus pattern on component side
provides three bus lines for ECL
circuitry
• 0.085" etched clearance area
around each hole on ground
plane side
• Bus and plane surfaces solder-
coated for user convenience
• Layout paper and instructions
included
Products
3719-4
Circuit Pattern:
Contacts:
Width/Thick:
Height:
16-Pin DIP Capacity:
Material:
Wire-Wrap Terminals:
Wire-Wrap Socket Pins:
Solder Connector:
Extender:
Rec. Card Cage:
Wire-Wrap Connector:
Hole Diameter:
4.5" x 9.6"
Contacts Only
36/72 @ .100" Ctrs,
Ni/Gold
9.60"/0.62"
• Unrestricted component place-
4.50"
ment over entire board surface
• Row and column legends
90
provided
CEM-1
• Layout paper and instructions
T44, T46, T49, T68
included
R32
R636-2
3690-2
Series 14
R636-1
.042"
11115 Vanowen St., North Hollywood, CA 91605 Phone(818)985-8208 Fax(818)985-7708
Toll-Free (800) 423-5659
Web site: http://www.vectorelect.com
ELECTRONIC COMPANY
