STM32 Nucleo low voltage brushed DC motor driver expansion board based on STSPIN250

X-NUCLEO-IHM13A1

Overview

The X-NUCLEO-IHM13A1 expansion board for STM32 Nucleo is based on the STSPIN250 low voltage brush DC motor driver.

It provides an affordable and easy-to-use solution for the implementation of portable motor driving applications such as thermal printers, robotics and toys.
The X-NUCLEO-IHM13A1 is compatible with the Arduino UNO R3 connector and most STM32 Nucleo boards.

Main features

Low voltage range from 1.8 V to 10 V
Current up to 2.6 A r.m.s.
Current control with adjustable off-time
Full overcurrent and short circuit protection
Thermal shutdown
Compatible with Arduino UNO R3 connector
Compatible with STM32 Nucleo boards
RoHS compliant
