USB Type-C Audio Adapter Accessory Mode Reference Design

TIDA-00565

Overview

The USB Type-C™ Audio Adapter Accessory Mode Reference Design provides a solution for transmitting analog audio over the USB Type-C interface. This reference design demonstrates how to use the USB Type-C standard audio adapter accessory mode to transmit analog audio to system peripherals while still transmitting USB data through the same USB Type-C connector.

characteristic

● Supports analog audio via USB Type-C connector
● Low total harmonic distortion (THD) = <-85 dB (0.005%) at 1 Vpp
● Replace the larger 3.5mm audio jack with a smaller Type-C connector
● Protect microcontrollers from negative voltage fluctuations in analog audio
● Support USB power delivery
