Iris Cube->4*4 serial RGB dot matrix, can be expanded in series

Overview

Warning: The BOM is automatically generated and may not match the actual situation. Please do not use the BOM table to place orders directly. Everything is subject to the PCB package and schematic values.

Multiple light panels can be connected in series

Seven thousandths brightness. The control board below is [Iris Cube->Arduino MEGA2560 Iris Edition REV 1.3]

The brightness in the demonstration video is only turned on 1%, which is enough for me to read and write. If it is fully turned on, it will be very dazzling and I can only throw it away to make a street lamp.
